19:1 METAL GEARMOTOR 37DX68L 24V 64 CPR POLOLU
Виробник: POLOLU
Category: DC Motors
Description: Motor: DC; with gearbox; 24VDC; 3A; Shaft: D spring; 530rpm; 18.75: 1
Type of motor: DC
Kind of motor: with gearbox
Supply voltage: 24V DC
Max. operating current: 3A
Shaft surface: D spring
Nominal rot. speed measured after gear: 530rpm
Gear: 18.75:1
Shaft diameter: 6mm
Resolution: 64imp/revol.
Kind of sensor: encoder
Diameter: 37mm
Information: product is not a working device, but only component
Body dimensions: Ø37x68mm
Torque: max. 0.127Nm
кількість в упаковці: 1 шт
Category: DC Motors
Description: Motor: DC; with gearbox; 24VDC; 3A; Shaft: D spring; 530rpm; 18.75: 1
Type of motor: DC
Kind of motor: with gearbox
Supply voltage: 24V DC
Max. operating current: 3A
Shaft surface: D spring
Nominal rot. speed measured after gear: 530rpm
Gear: 18.75:1
Shaft diameter: 6mm
Resolution: 64imp/revol.
Kind of sensor: encoder
Diameter: 37mm
Information: product is not a working device, but only component
Body dimensions: Ø37x68mm
Torque: max. 0.127Nm
кількість в упаковці: 1 шт
товар відсутній
Відгуки про товар
Написати відгук
Технічний опис 19:1 METAL GEARMOTOR 37DX68L 24V 64 CPR POLOLU
Category: DC Motors, Description: Motor: DC; with gearbox; 24VDC; 3A; Shaft: D spring; 530rpm; 18.75: 1, Type of motor: DC, Kind of motor: with gearbox, Supply voltage: 24V DC, Max. operating current: 3A, Shaft surface: D spring, Nominal rot. speed measured after gear: 530rpm, Gear: 18.75:1, Shaft diameter: 6mm, Resolution: 64imp/revol., Kind of sensor: encoder, Diameter: 37mm, Information: product is not a working device, but only component, Body dimensions: Ø37x68mm, Torque: max. 0.127Nm, кількість в упаковці: 1 шт.
