Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ |
||||
---|---|---|---|---|---|---|---|---|---|
+3 |
VDS6074A | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 70MHz; Ch: 4; 10Mpts; 1Gsps; 40V; ≤5ns Type of oscilloscope: PC connected oscilloscope Band: 70MHz Number of channels: 4 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit; 12bit; 14bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤5ns Input sensitivity: 2mV/div...5V/div Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC кількість в упаковці: 1 шт |
на замовлення 1 шт: термін постачання 7-14 дні (днів) |
|
||||
+8 |
VDS6102 | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V; 8bit Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 2 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Additional functions: function generator Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform) Waveforms: impulse; ramp; rectangular; sinus |
товар відсутній |
|||||
+8 |
VDS6102 | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V; 8bit Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 2 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Additional functions: function generator Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform) Waveforms: impulse; ramp; rectangular; sinus кількість в упаковці: 1 шт |
товар відсутній |
|||||
+3 |
VDS6102A | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 2 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit; 12bit; 14bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Additional functions: function generator Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform) Waveforms: impulse; ramp; rectangular; sinus |
на замовлення 1 шт: термін постачання 21-30 дні (днів) |
|
||||
+3 |
VDS6102A | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 2 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit; 12bit; 14bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Additional functions: function generator Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform) Waveforms: impulse; ramp; rectangular; sinus кількість в упаковці: 1 шт |
на замовлення 1 шт: термін постачання 7-14 дні (днів) |
|
||||
+6 |
VDS6104 | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V; 8bit Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 4 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
||||
+6 |
VDS6104 | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V; 8bit Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 4 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
||||
+3 |
VDS6104A | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 4 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit; 12bit; 14bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
||||
+3 |
VDS6104A | OWON |
Category: PC connected oscilloscopes Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V Type of oscilloscope: PC connected oscilloscope Band: 100MHz Number of channels: 4 Memory record length: 10Mpts Sampling: 1Gsps Max. input voltage: 40V Trigger: falling-edge; pulse; rising-edge; slope; video signal Trigger modes: automatic; normal; single Input coupling: AC, DC, GND Vertical resolution: 8bit; 12bit; 14bit Dimensions: 190x120x18mm Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual Interface: LAN; USB 2.0 host; USB C Input impedance: 1MΩ/15pF Rise time: ≤3.5ns Input sensitivity: 2mV/div...5V/div Measuring instrument features: supports SCPI Software: LabVIEW Supply voltage: 5...15V DC кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
||||
+4 |
XDG2035 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 35MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 35MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...35MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 |
на замовлення 5 шт: термін постачання 21-30 дні (днів) |
|
||||
+4 |
XDG2035 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 35MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 35MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...35MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 кількість в упаковці: 1 шт |
на замовлення 5 шт: термін постачання 7-14 дні (днів) |
|
||||
+4 |
XDG2060 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 60MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 60MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 |
на замовлення 3 шт: термін постачання 21-30 дні (днів) |
|
||||
+4 |
XDG2060 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 60MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 60MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 кількість в упаковці: 1 шт |
на замовлення 3 шт: термін постачання 7-14 дні (днів) |
|
||||
+4 |
XDG2080 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 80MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 80MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...80MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
||||
+4 |
XDG2080 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 80MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 80MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...80MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
||||
+4 |
XDG2100 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 100MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 100MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...100MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
||||
+4 |
XDG2100 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 100MHz; LCD 7"; 800x480; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 100MHz Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...100MHz (sinus waveform) Kind of display used: LCD 7" Display resolution: 800x480 Number of channels: 2 Memory record length: 10Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; RS232; USB Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 500Msps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC-BNC cable; mains cable; USB cable Software: LabVIEW Manufacturer series: XDG2000 кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
||||
+8 |
XDG3102 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 100MHz; LCD 8"; 800x600; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 100MHz Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...100MHz (sinus waveform) Kind of display used: LCD 8" Display resolution: 800x600 Number of channels: 2 Memory record length: 1Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; USB device; USB Host Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 1,25Gsps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC cable; mains cable; USB cable Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Software: LabVIEW Manufacturer series: XDG3000 |
на замовлення 1 шт: термін постачання 21-30 дні (днів) |
|
||||
+8 |
XDG3102 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 100MHz; LCD 8"; 800x600; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 100MHz Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...100MHz (sinus waveform) Kind of display used: LCD 8" Display resolution: 800x600 Number of channels: 2 Memory record length: 1Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; USB device; USB Host Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 1,25Gsps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC cable; mains cable; USB cable Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Software: LabVIEW Manufacturer series: XDG3000 кількість в упаковці: 1 шт |
на замовлення 1 шт: термін постачання 7-14 дні (днів) |
|
||||
+3 |
XDG3162 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 160MHz; LCD 8"; 800x600; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 160MHz Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...80MHz (harmonic waveform); 1µHz...160MHz (sinus waveform) Kind of display used: LCD 8" Display resolution: 800x600 Number of channels: 2 Memory record length: 1Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; USB device; USB Host Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 1,25Gsps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC cable; mains cable; USB cable Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Software: LabVIEW Manufacturer series: XDG3000 |
на замовлення 1 шт: термін постачання 21-30 дні (днів) |
|
||||
+3 |
XDG3162 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 160MHz; LCD 8"; 800x600; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 160MHz Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...80MHz (harmonic waveform); 1µHz...160MHz (sinus waveform) Kind of display used: LCD 8" Display resolution: 800x600 Number of channels: 2 Memory record length: 1Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; USB device; USB Host Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 1,25Gsps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC cable; mains cable; USB cable Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Software: LabVIEW Manufacturer series: XDG3000 кількість в упаковці: 1 шт |
на замовлення 1 шт: термін постачання 7-14 дні (днів) |
|
||||
+4 |
XDG3202 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 200MHz; LCD 8"; 800x600; Ch: 2 Number of channels: 2 Sampling: 1,25Gsps Memory record length: 1Mpts Kind of display used: LCD 8" Vertical resolution: 14bit Interface: LAN; USB device; USB Host Manufacturer series: XDG3000 Additional functions: frequency meter Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...100MHz (harmonic waveform); 1µHz...200MHz (sinus waveform) Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Maximum waveform frequency: 200MHz Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Standard equipment: BNC cable; mains cable; USB cable Plug variant: EU Dimensions: 340x177x90mm Software: LabVIEW Display resolution: 800x600 Type of generator: arbitrary, function |
товар відсутній |
|||||
+4 |
XDG3202 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 200MHz; LCD 8"; 800x600; Ch: 2 Number of channels: 2 Sampling: 1,25Gsps Memory record length: 1Mpts Kind of display used: LCD 8" Vertical resolution: 14bit Interface: LAN; USB device; USB Host Manufacturer series: XDG3000 Additional functions: frequency meter Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...100MHz (harmonic waveform); 1µHz...200MHz (sinus waveform) Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Maximum waveform frequency: 200MHz Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Standard equipment: BNC cable; mains cable; USB cable Plug variant: EU Dimensions: 340x177x90mm Software: LabVIEW Display resolution: 800x600 Type of generator: arbitrary, function кількість в упаковці: 1 шт |
товар відсутній |
|||||
+7 |
XDG3252 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 250MHz; LCD 8"; 800x600; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 250MHz Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...125MHz (harmonic waveform); 1µHz...250MHz (sinus waveform) Kind of display used: LCD 8" Display resolution: 800x600 Number of channels: 2 Memory record length: 1Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; USB device; USB Host Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 1,25Gsps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC cable; mains cable; USB cable Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Software: LabVIEW Manufacturer series: XDG3000 |
на замовлення 1 шт: термін постачання 21-30 дні (днів) |
|
||||
+7 |
XDG3252 | OWON |
Category: Generators and Frequency Meters Description: Generator: arbitrary, function; 250MHz; LCD 8"; 800x600; Ch: 2 Type of generator: arbitrary, function Maximum waveform frequency: 250MHz Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...125MHz (harmonic waveform); 1µHz...250MHz (sinus waveform) Kind of display used: LCD 8" Display resolution: 800x600 Number of channels: 2 Memory record length: 1Mpts Vertical resolution: 14bit Dimensions: 340x177x90mm Interface: LAN; USB device; USB Host Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus Sampling: 1,25Gsps Plug variant: EU Additional functions: frequency meter Standard equipment: BNC cable; mains cable; USB cable Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI Software: LabVIEW Manufacturer series: XDG3000 кількість в упаковці: 1 шт |
на замовлення 1 шт: термін постачання 7-14 дні (днів) |
|
||||
+8 |
XDM2041 | OWON |
Category: Benchtop digital multimeters Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 65x/s; 10÷60MHz Type of meter: benchtop multimeter Measuring instrument features: autoranging; HOLD function; MIN/MAX/AVG function; operates with thermocouple types: K; operates with thermocouple types: PT100 Kind of display used: LCD 4,5" Display resolution: 480x320 Sampling: 65x/s DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV DC voltage measuring accuracy: ±(0.025% + 5% range) AC voltage measuring range: 500mV...750V AC voltage measuring accuracy: ±(0.5% + 30% range) AC current measuring range: 500µA; 0.5A; 5A; 10A DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A DC current measuring accuracy: ±(0.15% + 20% range) AC current measuring accuracy: ±(0.5% + 20% range) True effective value measurement: True RMS AC Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ Resistance measuring accuracy: ±(0.1%+5% range) Capacitance measuring range: 50nF...50mF Capacitance measuring accuracy: ±(2.5%+ 5% range) Frequency measuring range: 10...60MHz Frequency measuring accuracy: ±(0.2% + 8% range) Diode test: 3V Continuity test: <1kΩ Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.) Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature Interface: RS232 Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010 Dimensions (W x H x D): 235x110x295mm Display parameters: 5,5 digit Supply voltage: 90...240V AC |
на замовлення 50 шт: термін постачання 21-30 дні (днів) |
|
||||
+8 |
XDM2041 | OWON |
Category: Benchtop digital multimeters Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 65x/s; 10÷60MHz Type of meter: benchtop multimeter Measuring instrument features: autoranging; HOLD function; MIN/MAX/AVG function; operates with thermocouple types: K; operates with thermocouple types: PT100 Kind of display used: LCD 4,5" Display resolution: 480x320 Sampling: 65x/s DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV DC voltage measuring accuracy: ±(0.025% + 5% range) AC voltage measuring range: 500mV...750V AC voltage measuring accuracy: ±(0.5% + 30% range) AC current measuring range: 500µA; 0.5A; 5A; 10A DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A DC current measuring accuracy: ±(0.15% + 20% range) AC current measuring accuracy: ±(0.5% + 20% range) True effective value measurement: True RMS AC Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ Resistance measuring accuracy: ±(0.1%+5% range) Capacitance measuring range: 50nF...50mF Capacitance measuring accuracy: ±(2.5%+ 5% range) Frequency measuring range: 10...60MHz Frequency measuring accuracy: ±(0.2% + 8% range) Diode test: 3V Continuity test: <1kΩ Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.) Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature Interface: RS232 Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010 Dimensions (W x H x D): 235x110x295mm Display parameters: 5,5 digit Supply voltage: 90...240V AC кількість в упаковці: 1 шт |
на замовлення 50 шт: термін постачання 7-14 дні (днів) |
|
||||
+3 |
XDM3041 | OWON |
Category: Benchtop digital multimeters Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 150x/s; 20÷1MHz Type of meter: benchtop multimeter Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function Kind of display used: LCD 4,5" Display resolution: 480x320 Sampling: 150x/s DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV DC voltage measuring accuracy: ±(0.02% + 0.01% range) AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V AC voltage measuring accuracy: ±(0.2% + 0.06% range) AC current measuring range: 60mA; 600mA; 6A; 10A DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A DC current measuring accuracy: ±(0.06% + 0.02% range) AC current measuring accuracy: ±(0.5% + 0.1% range) True effective value measurement: True RMS AC Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ Resistance measuring accuracy: ±(0.03%+0.01% range) Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF Capacitance measuring accuracy: ±(1%+ 0.5% range) Frequency measuring range: 20...1MHz Frequency measuring accuracy: ±(0.01% + 0.003% range) Diode test: 3V Continuity test: <1kΩ Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature Interface: LAN; RS232; USB Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010 Dimensions (W x H x D): 235x110x295mm Display parameters: 4,5 digit Supply voltage: 90...240V AC |
на замовлення 1 шт: термін постачання 21-30 дні (днів) |
|
||||
+3 |
XDM3041 | OWON |
Category: Benchtop digital multimeters Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 150x/s; 20÷1MHz Type of meter: benchtop multimeter Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function Kind of display used: LCD 4,5" Display resolution: 480x320 Sampling: 150x/s DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV DC voltage measuring accuracy: ±(0.02% + 0.01% range) AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V AC voltage measuring accuracy: ±(0.2% + 0.06% range) AC current measuring range: 60mA; 600mA; 6A; 10A DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A DC current measuring accuracy: ±(0.06% + 0.02% range) AC current measuring accuracy: ±(0.5% + 0.1% range) True effective value measurement: True RMS AC Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ Resistance measuring accuracy: ±(0.03%+0.01% range) Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF Capacitance measuring accuracy: ±(1%+ 0.5% range) Frequency measuring range: 20...1MHz Frequency measuring accuracy: ±(0.01% + 0.003% range) Diode test: 3V Continuity test: <1kΩ Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature Interface: LAN; RS232; USB Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010 Dimensions (W x H x D): 235x110x295mm Display parameters: 4,5 digit Supply voltage: 90...240V AC кількість в упаковці: 1 шт |
на замовлення 1 шт: термін постачання 7-14 дні (днів) |
|
||||
+5 |
XDM3051 | OWON |
Category: Benchtop digital multimeters Description: Benchtop multimeter; LCD 4"; Sampling: 150x/s; True RMS AC Type of meter: benchtop multimeter Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function Kind of display used: LCD 4" Sampling: 150x/s DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV DC voltage measuring accuracy: ±(0.015% + 0.004% range) AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V AC voltage measuring accuracy: ±(0.2% + 0.05% range) AC current measuring range: 20mA; 200mA; 2A; 10A DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A DC current measuring accuracy: ±(0.055% + 0.005% range) AC current measuring accuracy: ±(0.5% + 0.1% range) True effective value measurement: True RMS AC Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ Resistance measuring accuracy: ±(0.02%+0.003% range) Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF Capacitance measuring accuracy: ±(1%+ 0.5% range) Frequency measuring range: 20...1MHz Frequency measuring accuracy: ±(0.01% + 0.003% range) Diode test: 2V Continuity test: <2kΩ Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature Interface: LAN; RS232; USB Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010 Dimensions (W x H x D): 235x110x295mm Display parameters: 5,5 digit Supply voltage: 90...240V AC |
на замовлення 12 шт: термін постачання 21-30 дні (днів) |
|
||||
+5 |
XDM3051 | OWON |
Category: Benchtop digital multimeters Description: Benchtop multimeter; LCD 4"; Sampling: 150x/s; True RMS AC Type of meter: benchtop multimeter Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function Kind of display used: LCD 4" Sampling: 150x/s DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV DC voltage measuring accuracy: ±(0.015% + 0.004% range) AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V AC voltage measuring accuracy: ±(0.2% + 0.05% range) AC current measuring range: 20mA; 200mA; 2A; 10A DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A DC current measuring accuracy: ±(0.055% + 0.005% range) AC current measuring accuracy: ±(0.5% + 0.1% range) True effective value measurement: True RMS AC Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ Resistance measuring accuracy: ±(0.02%+0.003% range) Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF Capacitance measuring accuracy: ±(1%+ 0.5% range) Frequency measuring range: 20...1MHz Frequency measuring accuracy: ±(0.01% + 0.003% range) Diode test: 2V Continuity test: <2kΩ Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature Interface: LAN; RS232; USB Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010 Dimensions (W x H x D): 235x110x295mm Display parameters: 5,5 digit Supply voltage: 90...240V AC кількість в упаковці: 1 шт |
на замовлення 12 шт: термін постачання 7-14 дні (днів) |
|
||||
XDS SOFT BAG | OWON |
Category: Accessories for Oscilloscopes - Others Description: Bag; XDS; 380x210x90mm Type of test accessories: bag Manufacturer series: XDS Body dimensions: 380x210x90mm Related items: XDS3062A; XDS3064AE; XDS3064E; XDS3102; XDS3102A; XDS3104AE; XDS3104E; XDS3202; XDS3202A; XDS3202E; XDS3204AE; XDS3204E; XDS3302 |
товар відсутній |
||||||
XDS3062A | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 2 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Supply voltage: 100...240V AC |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3062A | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 2 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3062A/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 2 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Supply voltage: 100...240V AC |
на замовлення 4 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3062A/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 2 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 4 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3064AE | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 14bit Input coupling: AC, DC, GND Interface: LAN; USB Manufacturer series: XDS Rise time: ≤5.8ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3064AE | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 14bit Input coupling: AC, DC, GND Interface: LAN; USB Manufacturer series: XDS Rise time: ≤5.8ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3064AE/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 14bit Input coupling: AC, DC, GND Interface: LAN; USB Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC |
товар відсутній |
||||||
XDS3064AE/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 14bit Input coupling: AC, DC, GND Interface: LAN; USB Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
товар відсутній |
||||||
XDS3064E | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.8ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC |
на замовлення 3 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3064E | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.8ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 3 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3064E/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC |
на замовлення 5 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3064E/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS Type of oscilloscope: digital Number of channels: 4 Band: 60MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 400V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤5.85ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 5 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3102 | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Power consumption: 24W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Supply voltage: 100...240V AC |
на замовлення 9 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3102 | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Power consumption: 24W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 9 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3102/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Power consumption: 24W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Supply voltage: 100...240V AC |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3102A | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3102A | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3102A/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC |
на замовлення 3 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3102A/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 12bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Power consumption: 15W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Touchpad: yes Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 3 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3102/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Type of oscilloscope: digital Number of channels: 2 Band: 100MHz Sampling: 1Gsps Memory record length: 40Mpts Kind of display used: LCD TFT 8" Trigger modes: automatic; normal; single Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Time base: 2n...1ks/div Max. input voltage: 300V Vertical resolution: 8bit Input coupling: AC, DC, GND Interface: LAN; USB; VGA Manufacturer series: XDS Rise time: ≤3.5ns Input impedance: 1MΩ/15pF Input sensitivity: 1mV/div...10V/div Additional functions: frequency meter Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Power consumption: 24W Body dimensions: 340x177x90mm Related items: XDS-SOFTBAG Software: LabVIEW Measurement memory: 100 Connector: VGA + AV Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 Display resolution: 800x600 Supply voltage: 100...240V AC кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3104AE | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 14bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div |
на замовлення 5 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3104AE | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 14bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div кількість в упаковці: 1 шт |
на замовлення 5 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3104AE/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 14bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 |
на замовлення 2 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3104AE/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 14bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 кількість в упаковці: 1 шт |
на замовлення 2 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3104E | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB; VGA Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 8bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div |
на замовлення 7 шт: термін постачання 21-30 дні (днів) |
|
|||||
XDS3104E | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB; VGA Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 8bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div кількість в упаковці: 1 шт |
на замовлення 7 шт: термін постачання 7-14 дні (днів) |
|
|||||
XDS3104E/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB; VGA Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 8bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 |
товар відсутній |
||||||
XDS3104E/B | OWON |
Category: Digital Oscilloscopes Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8" Band: 100MHz Max. input voltage: 400V Manufacturer series: XDS Input impedance: 1MΩ/15pF Power supply: rechargeable battery Li-Ion 3,7V x1 Plug variant: EU Number of channels: 4 Rise time: ≤3.5ns Body dimensions: 340x177x90mm Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual Related items: XDS-SOFTBAG Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART Software: LabVIEW Interface: LAN; USB; VGA Memory record length: 40Mpts Touchpad: yes Connector: VGA + AV Kind of display used: LCD TFT 8" Supply voltage: 100...240V AC Measurement memory: 100 Display resolution: 800x600 Additional functions: frequency meter Sampling: 1Gsps Type of oscilloscope: digital Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Vertical resolution: 8bit Trigger modes: automatic; normal; single Input sensitivity: 1mV/div...10V/div Time base: 2n...1ks/div Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1 кількість в упаковці: 1 шт |
товар відсутній |
VDS6074A |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 70MHz; Ch: 4; 10Mpts; 1Gsps; 40V; ≤5ns
Type of oscilloscope: PC connected oscilloscope
Band: 70MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
кількість в упаковці: 1 шт
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 70MHz; Ch: 4; 10Mpts; 1Gsps; 40V; ≤5ns
Type of oscilloscope: PC connected oscilloscope
Band: 70MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
кількість в упаковці: 1 шт
на замовлення 1 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 40294.46 грн |
VDS6102 |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
товар відсутній
VDS6102 |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
кількість в упаковці: 1 шт
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
кількість в упаковці: 1 шт
товар відсутній
VDS6102A |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
на замовлення 1 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 23143.48 грн |
VDS6102A |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
кількість в упаковці: 1 шт
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 2; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 2
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; BNC cable; mains cable; test probe x2; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Additional functions: function generator
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Waveform frequency range: 0,1Hz...5MHz (sinus waveform); 0,1Hz...10kHz (pulse waveform); 0,1Hz...10kHz (ramp waveform); 0,1Hz...200kHz (rectangular waveform)
Waveforms: impulse; ramp; rectangular; sinus
кількість в упаковці: 1 шт
на замовлення 1 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 27772.18 грн |
VDS6104 |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 24824.23 грн |
VDS6104 |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
кількість в упаковці: 1 шт
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V; 8bit
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 29789.08 грн |
VDS6104A |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 35673.66 грн |
VDS6104A |
Виробник: OWON
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
кількість в упаковці: 1 шт
Category: PC connected oscilloscopes
Description: PC connected oscilloscope; 100MHz; Ch: 4; 10Mpts; 1Gsps; 40V
Type of oscilloscope: PC connected oscilloscope
Band: 100MHz
Number of channels: 4
Memory record length: 10Mpts
Sampling: 1Gsps
Max. input voltage: 40V
Trigger: falling-edge; pulse; rising-edge; slope; video signal
Trigger modes: automatic; normal; single
Input coupling: AC, DC, GND
Vertical resolution: 8bit; 12bit; 14bit
Dimensions: 190x120x18mm
Standard equipment: adapter AC-DC; test probe x4; USB cable; user's manual
Interface: LAN; USB 2.0 host; USB C
Input impedance: 1MΩ/15pF
Rise time: ≤3.5ns
Input sensitivity: 2mV/div...5V/div
Measuring instrument features: supports SCPI
Software: LabVIEW
Supply voltage: 5...15V DC
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 42808.39 грн |
XDG2035 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 35MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 35MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...35MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 35MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 35MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...35MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
на замовлення 5 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 23985.02 грн |
XDG2035 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 35MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 35MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...35MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 35MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 35MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...35MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
на замовлення 5 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 28782.02 грн |
XDG2060 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
на замовлення 3 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 31156.29 грн |
XDG2060 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...60MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
на замовлення 3 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 37387.55 грн |
XDG2080 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...80MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...80MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 32203.76 грн |
XDG2080 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...80MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...80MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 38644.52 грн |
XDG2100 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 37570.41 грн |
XDG2100 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 7"; 800x480; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...30MHz (rectangular waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 7"
Display resolution: 800x480
Number of channels: 2
Memory record length: 10Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; RS232; USB
Kind of modulation: AM; ASK; BPSK; DSB-AM; FM; FSK; OSK; PM; PSK; PWM; QPSK; SUM
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 500Msps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC-BNC cable; mains cable; USB cable
Software: LabVIEW
Manufacturer series: XDG2000
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 45084.5 грн |
XDG3102 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
на замовлення 1 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 47722.3 грн |
XDG3102 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 100MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 100MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...100MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
кількість в упаковці: 1 шт
на замовлення 1 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 57266.76 грн |
XDG3162 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 160MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 160MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...80MHz (harmonic waveform); 1µHz...160MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 160MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 160MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...80MHz (harmonic waveform); 1µHz...160MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
на замовлення 1 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 54731.77 грн |
XDG3162 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 160MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 160MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...80MHz (harmonic waveform); 1µHz...160MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 160MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 160MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...80MHz (harmonic waveform); 1µHz...160MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
кількість в упаковці: 1 шт
на замовлення 1 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 65678.12 грн |
XDG3202 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 200MHz; LCD 8"; 800x600; Ch: 2
Number of channels: 2
Sampling: 1,25Gsps
Memory record length: 1Mpts
Kind of display used: LCD 8"
Vertical resolution: 14bit
Interface: LAN; USB device; USB Host
Manufacturer series: XDG3000
Additional functions: frequency meter
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...100MHz (harmonic waveform); 1µHz...200MHz (sinus waveform)
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Maximum waveform frequency: 200MHz
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Standard equipment: BNC cable; mains cable; USB cable
Plug variant: EU
Dimensions: 340x177x90mm
Software: LabVIEW
Display resolution: 800x600
Type of generator: arbitrary, function
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 200MHz; LCD 8"; 800x600; Ch: 2
Number of channels: 2
Sampling: 1,25Gsps
Memory record length: 1Mpts
Kind of display used: LCD 8"
Vertical resolution: 14bit
Interface: LAN; USB device; USB Host
Manufacturer series: XDG3000
Additional functions: frequency meter
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...100MHz (harmonic waveform); 1µHz...200MHz (sinus waveform)
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Maximum waveform frequency: 200MHz
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Standard equipment: BNC cable; mains cable; USB cable
Plug variant: EU
Dimensions: 340x177x90mm
Software: LabVIEW
Display resolution: 800x600
Type of generator: arbitrary, function
товар відсутній
XDG3202 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 200MHz; LCD 8"; 800x600; Ch: 2
Number of channels: 2
Sampling: 1,25Gsps
Memory record length: 1Mpts
Kind of display used: LCD 8"
Vertical resolution: 14bit
Interface: LAN; USB device; USB Host
Manufacturer series: XDG3000
Additional functions: frequency meter
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...100MHz (harmonic waveform); 1µHz...200MHz (sinus waveform)
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Maximum waveform frequency: 200MHz
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Standard equipment: BNC cable; mains cable; USB cable
Plug variant: EU
Dimensions: 340x177x90mm
Software: LabVIEW
Display resolution: 800x600
Type of generator: arbitrary, function
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 200MHz; LCD 8"; 800x600; Ch: 2
Number of channels: 2
Sampling: 1,25Gsps
Memory record length: 1Mpts
Kind of display used: LCD 8"
Vertical resolution: 14bit
Interface: LAN; USB device; USB Host
Manufacturer series: XDG3000
Additional functions: frequency meter
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...100MHz (harmonic waveform); 1µHz...200MHz (sinus waveform)
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Maximum waveform frequency: 200MHz
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Standard equipment: BNC cable; mains cable; USB cable
Plug variant: EU
Dimensions: 340x177x90mm
Software: LabVIEW
Display resolution: 800x600
Type of generator: arbitrary, function
кількість в упаковці: 1 шт
товар відсутній
XDG3252 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 250MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 250MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...125MHz (harmonic waveform); 1µHz...250MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 250MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 250MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...125MHz (harmonic waveform); 1µHz...250MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
на замовлення 1 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 79329.17 грн |
XDG3252 |
Виробник: OWON
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 250MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 250MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...125MHz (harmonic waveform); 1µHz...250MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
кількість в упаковці: 1 шт
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 250MHz; LCD 8"; 800x600; Ch: 2
Type of generator: arbitrary, function
Maximum waveform frequency: 250MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...25MHz (pulse waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (rectangular waveform); 1µHz...125MHz (harmonic waveform); 1µHz...250MHz (sinus waveform)
Kind of display used: LCD 8"
Display resolution: 800x600
Number of channels: 2
Memory record length: 1Mpts
Vertical resolution: 14bit
Dimensions: 340x177x90mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; burst; FM; FSK; OSK; PM; PSK; PWM; sweep
Waveforms: arbitrary; harmonic; impulse; noise; rectangular; sinus
Sampling: 1,25Gsps
Plug variant: EU
Additional functions: frequency meter
Standard equipment: BNC cable; mains cable; USB cable
Measuring instrument features: Direct Digital Synthesized (DDS) technology; supports SCPI
Software: LabVIEW
Manufacturer series: XDG3000
кількість в упаковці: 1 шт
на замовлення 1 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 95195 грн |
XDM2041 |
Виробник: OWON
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 65x/s; 10÷60MHz
Type of meter: benchtop multimeter
Measuring instrument features: autoranging; HOLD function; MIN/MAX/AVG function; operates with thermocouple types: K; operates with thermocouple types: PT100
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 65x/s
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
DC voltage measuring accuracy: ±(0.025% + 5% range)
AC voltage measuring range: 500mV...750V
AC voltage measuring accuracy: ±(0.5% + 30% range)
AC current measuring range: 500µA; 0.5A; 5A; 10A
DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A
DC current measuring accuracy: ±(0.15% + 20% range)
AC current measuring accuracy: ±(0.5% + 20% range)
True effective value measurement: True RMS AC
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ
Resistance measuring accuracy: ±(0.1%+5% range)
Capacitance measuring range: 50nF...50mF
Capacitance measuring accuracy: ±(2.5%+ 5% range)
Frequency measuring range: 10...60MHz
Frequency measuring accuracy: ±(0.2% + 8% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.)
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: RS232
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 65x/s; 10÷60MHz
Type of meter: benchtop multimeter
Measuring instrument features: autoranging; HOLD function; MIN/MAX/AVG function; operates with thermocouple types: K; operates with thermocouple types: PT100
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 65x/s
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
DC voltage measuring accuracy: ±(0.025% + 5% range)
AC voltage measuring range: 500mV...750V
AC voltage measuring accuracy: ±(0.5% + 30% range)
AC current measuring range: 500µA; 0.5A; 5A; 10A
DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A
DC current measuring accuracy: ±(0.15% + 20% range)
AC current measuring accuracy: ±(0.5% + 20% range)
True effective value measurement: True RMS AC
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ
Resistance measuring accuracy: ±(0.1%+5% range)
Capacitance measuring range: 50nF...50mF
Capacitance measuring accuracy: ±(2.5%+ 5% range)
Frequency measuring range: 10...60MHz
Frequency measuring accuracy: ±(0.2% + 8% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.)
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: RS232
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
на замовлення 50 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 10907.49 грн |
XDM2041 |
Виробник: OWON
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 65x/s; 10÷60MHz
Type of meter: benchtop multimeter
Measuring instrument features: autoranging; HOLD function; MIN/MAX/AVG function; operates with thermocouple types: K; operates with thermocouple types: PT100
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 65x/s
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
DC voltage measuring accuracy: ±(0.025% + 5% range)
AC voltage measuring range: 500mV...750V
AC voltage measuring accuracy: ±(0.5% + 30% range)
AC current measuring range: 500µA; 0.5A; 5A; 10A
DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A
DC current measuring accuracy: ±(0.15% + 20% range)
AC current measuring accuracy: ±(0.5% + 20% range)
True effective value measurement: True RMS AC
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ
Resistance measuring accuracy: ±(0.1%+5% range)
Capacitance measuring range: 50nF...50mF
Capacitance measuring accuracy: ±(2.5%+ 5% range)
Frequency measuring range: 10...60MHz
Frequency measuring accuracy: ±(0.2% + 8% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.)
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: RS232
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
кількість в упаковці: 1 шт
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 65x/s; 10÷60MHz
Type of meter: benchtop multimeter
Measuring instrument features: autoranging; HOLD function; MIN/MAX/AVG function; operates with thermocouple types: K; operates with thermocouple types: PT100
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 65x/s
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
DC voltage measuring accuracy: ±(0.025% + 5% range)
AC voltage measuring range: 500mV...750V
AC voltage measuring accuracy: ±(0.5% + 30% range)
AC current measuring range: 500µA; 0.5A; 5A; 10A
DC current measuring range: 0.5mA; 5mA; 50mA; 500mA; 5A; 10A
DC current measuring accuracy: ±(0.15% + 20% range)
AC current measuring accuracy: ±(0.5% + 20% range)
True effective value measurement: True RMS AC
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 50MΩ
Resistance measuring accuracy: ±(0.1%+5% range)
Capacitance measuring range: 50nF...50mF
Capacitance measuring accuracy: ±(2.5%+ 5% range)
Frequency measuring range: 10...60MHz
Frequency measuring accuracy: ±(0.2% + 8% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.)
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: RS232
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
кількість в упаковці: 1 шт
на замовлення 50 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 13088.99 грн |
XDM3041 |
Виробник: OWON
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 150x/s; 20÷1MHz
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 150x/s
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.02% + 0.01% range)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.06% range)
AC current measuring range: 60mA; 600mA; 6A; 10A
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(0.06% + 0.02% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ
Resistance measuring accuracy: ±(0.03%+0.01% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 4,5 digit
Supply voltage: 90...240V AC
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 150x/s; 20÷1MHz
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 150x/s
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.02% + 0.01% range)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.06% range)
AC current measuring range: 60mA; 600mA; 6A; 10A
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(0.06% + 0.02% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ
Resistance measuring accuracy: ±(0.03%+0.01% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 4,5 digit
Supply voltage: 90...240V AC
на замовлення 1 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 24094.95 грн |
XDM3041 |
Виробник: OWON
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 150x/s; 20÷1MHz
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 150x/s
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.02% + 0.01% range)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.06% range)
AC current measuring range: 60mA; 600mA; 6A; 10A
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(0.06% + 0.02% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ
Resistance measuring accuracy: ±(0.03%+0.01% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 4,5 digit
Supply voltage: 90...240V AC
кількість в упаковці: 1 шт
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4,5"; 480x320; Sampling: 150x/s; 20÷1MHz
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4,5"
Display resolution: 480x320
Sampling: 150x/s
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.02% + 0.01% range)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.06% range)
AC current measuring range: 60mA; 600mA; 6A; 10A
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(0.06% + 0.02% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ; 100MΩ
Resistance measuring accuracy: ±(0.03%+0.01% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 3V
Continuity test: <1kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 4,5 digit
Supply voltage: 90...240V AC
кількість в упаковці: 1 шт
на замовлення 1 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 28913.94 грн |
XDM3051 |
Виробник: OWON
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4"; Sampling: 150x/s; True RMS AC
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4"
Sampling: 150x/s
DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV
DC voltage measuring accuracy: ±(0.015% + 0.004% range)
AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.05% range)
AC current measuring range: 20mA; 200mA; 2A; 10A
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A
DC current measuring accuracy: ±(0.055% + 0.005% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.02%+0.003% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 2V
Continuity test: <2kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4"; Sampling: 150x/s; True RMS AC
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4"
Sampling: 150x/s
DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV
DC voltage measuring accuracy: ±(0.015% + 0.004% range)
AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.05% range)
AC current measuring range: 20mA; 200mA; 2A; 10A
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A
DC current measuring accuracy: ±(0.055% + 0.005% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.02%+0.003% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 2V
Continuity test: <2kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
на замовлення 12 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 28956.83 грн |
XDM3051 |
Виробник: OWON
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4"; Sampling: 150x/s; True RMS AC
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4"
Sampling: 150x/s
DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV
DC voltage measuring accuracy: ±(0.015% + 0.004% range)
AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.05% range)
AC current measuring range: 20mA; 200mA; 2A; 10A
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A
DC current measuring accuracy: ±(0.055% + 0.005% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.02%+0.003% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 2V
Continuity test: <2kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
кількість в упаковці: 1 шт
Category: Benchtop digital multimeters
Description: Benchtop multimeter; LCD 4"; Sampling: 150x/s; True RMS AC
Type of meter: benchtop multimeter
Measuring instrument features: data visualization Min, Max, live, historical data and trending charts; MIN/MAX/AVG function; operates with thermocouple types: J, K, T, E, R, S, B, N; Pass/Fail function
Kind of display used: LCD 4"
Sampling: 150x/s
DC voltage measuring range: 200mV; 2V; 20V; 200V; 1kV
DC voltage measuring accuracy: ±(0.015% + 0.004% range)
AC voltage measuring range: 200mV; 2V; 20V; 200V; 750V
AC voltage measuring accuracy: ±(0.2% + 0.05% range)
AC current measuring range: 20mA; 200mA; 2A; 10A
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA; 2A; 10A
DC current measuring accuracy: ±(0.055% + 0.005% range)
AC current measuring accuracy: ±(0.5% + 0.1% range)
True effective value measurement: True RMS AC
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.02%+0.003% range)
Capacitance measuring range: 2nF; 20nF; 200nF; 2µF; 200µF; 10mF
Capacitance measuring accuracy: ±(1%+ 0.5% range)
Frequency measuring range: 20...1MHz
Frequency measuring accuracy: ±(0.01% + 0.003% range)
Diode test: 2V
Continuity test: <2kΩ
Standard equipment: 2 crocodile clips; fuse; mains cable; test leads ( 2pcs.); USB cable
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance (2-wire); resistance (4-wire); temperature
Interface: LAN; RS232; USB
Conform to the norm: CAT II 600V; CAT II 1000V; EN 61010
Dimensions (W x H x D): 235x110x295mm
Display parameters: 5,5 digit
Supply voltage: 90...240V AC
кількість в упаковці: 1 шт
на замовлення 12 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 34748.2 грн |
XDS SOFT BAG |
Виробник: OWON
Category: Accessories for Oscilloscopes - Others
Description: Bag; XDS; 380x210x90mm
Type of test accessories: bag
Manufacturer series: XDS
Body dimensions: 380x210x90mm
Related items: XDS3062A; XDS3064AE; XDS3064E; XDS3102; XDS3102A; XDS3104AE; XDS3104E; XDS3202; XDS3202A; XDS3202E; XDS3204AE; XDS3204E; XDS3302
Category: Accessories for Oscilloscopes - Others
Description: Bag; XDS; 380x210x90mm
Type of test accessories: bag
Manufacturer series: XDS
Body dimensions: 380x210x90mm
Related items: XDS3062A; XDS3064AE; XDS3064E; XDS3102; XDS3102A; XDS3104AE; XDS3104E; XDS3202; XDS3202A; XDS3202E; XDS3204AE; XDS3204E; XDS3302
товар відсутній
XDS3062A |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 28123.04 грн |
XDS3062A |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 33747.64 грн |
3+ | 32140.14 грн |
XDS3062A/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
на замовлення 4 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 31686.61 грн |
4+ | 29071.03 грн |
XDS3062A/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 2
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 4 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 38023.93 грн |
4+ | 36226.97 грн |
XDS3064AE |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 43339.64 грн |
XDS3064AE |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 52007.57 грн |
3+ | 49506.94 грн |
XDS3064AE/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
товар відсутній
XDS3064AE/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 14bit
Input coupling: AC, DC, GND
Interface: LAN; USB
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
товар відсутній
XDS3064E |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
на замовлення 3 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 30058.5 грн |
3+ | 27242.18 грн |
XDS3064E |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.8ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 3 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 36070.2 грн |
3+ | 33947.95 грн |
XDS3064E/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
на замовлення 5 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 33496.65 грн |
4+ | 30710.09 грн |
XDS3064E/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 60MHz; 1Gsps; 40Mpts; LCD TFT 8"; XDS
Type of oscilloscope: digital
Number of channels: 4
Band: 60MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤5.85ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 5 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 40195.98 грн |
4+ | 38269.49 грн |
XDS3102 |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
на замовлення 9 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 27880.72 грн |
XDS3102 |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 9 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 33456.86 грн |
XDS3102/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 32456.92 грн |
XDS3102A |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 48001.01 грн |
XDS3102A |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 57601.21 грн |
3+ | 54850.64 грн |
XDS3102A/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
на замовлення 3 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 50582.14 грн |
3+ | 46349.45 грн |
XDS3102A/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 15W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Touchpad: yes
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 3 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 60698.56 грн |
3+ | 57758.54 грн |
XDS3102/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 40Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Time base: 2n...1ks/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: LAN; USB; VGA
Manufacturer series: XDS
Rise time: ≤3.5ns
Input impedance: 1MΩ/15pF
Input sensitivity: 1mV/div...10V/div
Additional functions: frequency meter
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Power consumption: 24W
Body dimensions: 340x177x90mm
Related items: XDS-SOFTBAG
Software: LabVIEW
Measurement memory: 100
Connector: VGA + AV
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Display resolution: 800x600
Supply voltage: 100...240V AC
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 38948.31 грн |
3+ | 37091.46 грн |
XDS3104AE |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
на замовлення 5 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 53572.81 грн |
4+ | 49091.28 грн |
XDS3104AE |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
кількість в упаковці: 1 шт
на замовлення 5 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 64287.37 грн |
4+ | 61175.29 грн |
XDS3104AE/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
на замовлення 2 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 53980.81 грн |
XDS3104AE/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 14bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
кількість в упаковці: 1 шт
на замовлення 2 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 64776.97 грн |
3+ | 61645.6 грн |
XDS3104E |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
на замовлення 7 шт:
термін постачання 21-30 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 40342 грн |
4+ | 36960.08 грн |
XDS3104E |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
кількість в упаковці: 1 шт
на замовлення 7 шт:
термін постачання 7-14 дні (днів)Кількість | Ціна без ПДВ |
---|---|
1+ | 48410.4 грн |
4+ | 46057.94 грн |
XDS3104E/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
товар відсутній
XDS3104E/B |
Виробник: OWON
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
кількість в упаковці: 1 шт
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 40Mpts; LCD TFT 8"
Band: 100MHz
Max. input voltage: 400V
Manufacturer series: XDS
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 3,7V x1
Plug variant: EU
Number of channels: 4
Rise time: ≤3.5ns
Body dimensions: 340x177x90mm
Standard equipment: mains cable; oscilloscope probe (1 per channel); trimmer; USB cable; user's manual
Related items: XDS-SOFTBAG
Measuring instrument features: AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; measurements by means of cursors; protocols analyse: I2C, CAN, SPI, RS232/UART
Software: LabVIEW
Interface: LAN; USB; VGA
Memory record length: 40Mpts
Touchpad: yes
Connector: VGA + AV
Kind of display used: LCD TFT 8"
Supply voltage: 100...240V AC
Measurement memory: 100
Display resolution: 800x600
Additional functions: frequency meter
Sampling: 1Gsps
Type of oscilloscope: digital
Trigger: CAN; falling-edge; I2C; logic; Nth Edge; pulse; rising-edge; RS232/UART; runt; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Input sensitivity: 1mV/div...10V/div
Time base: 2n...1ks/div
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
кількість в упаковці: 1 шт
товар відсутній
