PMD2408PMB1-A.(2).F.GN SUNON
Виробник: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 143m3/h; 55.2dBA; ball bearing
Cable length: 0.3m
Operating temperature: -10...70°C
Current rating: 0.4A
Operating voltage: 10...27.6V
Type of fan: DC
Fan dimensions: 80x80x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball bearing
Fan efficiency: 143m3/h
Static pressure: 18.8mm H2O
Noise level: 55.2dBA
Rotational rate/speed: 5700 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 9.6W
Wire size: 24AWG
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Supply voltage: 24V DC
Leads: lead x3
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 143m3/h; 55.2dBA; ball bearing
Cable length: 0.3m
Operating temperature: -10...70°C
Current rating: 0.4A
Operating voltage: 10...27.6V
Type of fan: DC
Fan dimensions: 80x80x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball bearing
Fan efficiency: 143m3/h
Static pressure: 18.8mm H2O
Noise level: 55.2dBA
Rotational rate/speed: 5700 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 9.6W
Wire size: 24AWG
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Supply voltage: 24V DC
Leads: lead x3
на замовлення 3717 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
1+ | 882.27 грн |
10+ | 754.38 грн |
50+ | 688.81 грн |
200+ | 623.24 грн |
Відгуки про товар
Написати відгук
Технічний опис PMD2408PMB1-A.(2).F.GN SUNON
Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 80x80x38mm; 143m3/h; 55.2dBA; ball bearing, Cable length: 0.3m, Operating temperature: -10...70°C, Current rating: 0.4A, Operating voltage: 10...27.6V, Type of fan: DC, Fan dimensions: 80x80x38mm, Fan motor: brushless DC, Impeller material: thermoplastic, Flammability rating: UL94V-0, Insulation class: A, Kind of Bearing: ball bearing, Fan efficiency: 143m3/h, Static pressure: 18.8mm H2O, Noise level: 55.2dBA, Rotational rate/speed: 5700 (±10%)rpm, Current and power consumption tolerance: ±15%, Power consumption: 9.6W, Wire size: 24AWG, Additional functions: autorestart, Signal output: F type, Kind of fan: axial, Min. insulation resistance: 10MΩ, Enclosure material: thermoplastic, Supply voltage: 24V DC, Leads: lead x3, кількість в упаковці: 1 шт.
Супутні товари PMD2408PMB1-A.(2).F.GN SUNON
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
+3 |
Кріплення для Вентиляторів та решіток, кліпса пластикова FSP-1 Код товару: 62414 |
Корпусні та встановлювальні вироби > Вентилятори та аксесуари Опис: Кріплення, ідеальні для Вентиляторів SUNON з розмірами від 60x60x25 мм дo Ø254x89 мм, монтажні отвори Ø4,5 мм |
у наявності: 280 шт
|
|
|||||||||
+1 |
Кріплення для Вентиляторів та решіток, кліпса пластикова FSP-2 Код товару: 26792 |
Корпусні та встановлювальні вироби > Вентилятори та аксесуари Опис: Кріплення, ідеальні для Вентиляторів SUNON з розмірами від 60x60x25 мм дo Ø254x89 мм, монтажні отвори Ø4,5 мм |
очікується:
500 шт
|
|
Інші пропозиції PMD2408PMB1-A.(2).F.GN за ціною від 747.89 грн до 1326.1 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
PMD2408PMB1-A.(2).F.GN | Виробник : SUNON |
Category: DC24V Fans Description: Fan: DC; axial; 24VDC; 80x80x38mm; 143m3/h; 55.2dBA; ball bearing Cable length: 0.3m Operating temperature: -10...70°C Current rating: 0.4A Operating voltage: 10...27.6V Type of fan: DC Fan dimensions: 80x80x38mm Fan motor: brushless DC Impeller material: thermoplastic Flammability rating: UL94V-0 Insulation class: A Kind of Bearing: ball bearing Fan efficiency: 143m3/h Static pressure: 18.8mm H2O Noise level: 55.2dBA Rotational rate/speed: 5700 (±10%)rpm Current and power consumption tolerance: ±15% Power consumption: 9.6W Wire size: 24AWG Additional functions: autorestart Signal output: F type Kind of fan: axial Min. insulation resistance: 10MΩ Enclosure material: thermoplastic Supply voltage: 24V DC Leads: lead x3 кількість в упаковці: 1 шт |
на замовлення 3717 шт: термін постачання 7-14 дні (днів) |
|
|||||||||||||||
PMD2408PMB1-A.(2).F.GN | Виробник : Sunon | PMD2408PMB1-A.(2).F.GN |
на замовлення 3721 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||||
Вентилятор 80x80x38, 24V, (PMD2408PMB1AF) Код товару: 86135 |
Виробник : Sunon |
Корпусні та встановлювальні вироби > Вентилятори та аксесуари Габаритні розміри, mm: 80x80x38 mm Напруга, В: 24 DC Об’єм повітря, м.куб/год.: 143 м³/год. Потужність, W: 9,6 Вт Шум, dB: 55,2 дБ Швидкість обертання, об/хв: 5700 об/хв Опис: Підшипник кульковий |
товар відсутній
|
