Продукція > BELDEN > Всі товари виробника BELDEN (9018) > Сторінка 141 з 151

Обрати Сторінку:   [  << Попередня Сторінка ]  1 15 30 45 60 75 90 105 120 135 136 137 138 139 140 141 142 143 144 145 146 150 151  [ Наступна Сторінка >> ]
Фото Назва Виробник Інформація Доступність
Ціна
83049 008100 83049 008100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E4B4DFA620A0D6&compId=83049_EN.pdf?ci_sign=7f1bb3a782ca41a9344157025fea4d9842f22491 Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 22AWG; TFE; grey; 250V; 30m; 1x22AWG; 100ft
Type of wire: assembly
Insulation colour: grey
Conform to the norm: MIL-W-16878/6 (Type ET); UL 1371; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 105°C
Cable external diameter: 1.07mm
Number of cores: 1
Cable structure: 1x22AWG
Core diameter: 22AWG
Package contents: 30m
Rated voltage: 250V
Package contents - ft: 100ft
Shield structure: unshielded
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+187.64 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83049 009100 83049 009100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E4B4DFA620A0D6&compId=83049_EN.pdf?ci_sign=7f1bb3a782ca41a9344157025fea4d9842f22491 Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 22AWG; TFE; white; 250V; 30m; 1x22AWG; 100ft
Type of wire: assembly
Insulation colour: white
Conform to the norm: MIL-W-16878/6 (Type ET); UL 1371; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 105°C
Cable external diameter: 1.07mm
Number of cores: 1
Cable structure: 1x22AWG
Core diameter: 22AWG
Package contents: 305m
Rated voltage: 250V
Package contents - ft: 1000ft
Shield structure: unshielded
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+187.64 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
19509 B59250 19509 B59250 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA6E4AF0583F8A0D3&compId=19509.B59250.PDF?ci_sign=019cbf573f5d77512e2bc037bf4d828cb6d6ffa1 Category: Power Cords
Description: Wire; 3x18AWG; stranded; Cu; PVC; black; 300V; 76m; 18AWG; 250ft
Conform to the norm: UL SJTOW
Core marking: colours without colour repetition + ground wire
Kind of core: Cu
Type of wire: mains
CPR standard: no classification
Earth core: yellow-green
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -35...105°C
Cable external diameter: 8mm
Number of cores: 3
Cable structure: 3x18AWG
Core diameter: 18AWG
Package contents: 76m
Package contents - ft: 250ft
Rated voltage: 300V
Shield structure: unshielded
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
5100FE.00152 5100FE.00152 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3993B95473660D6&compId=5100FE_EN.pdf?ci_sign=2e2955dfd4ef7becd0eaf76e36bba43a62c4069b Category: Multicore Cables - Shielded
Description: Wire; 2x14AWG; shielded,Al-PET foil; PVC; chrome; 300V; 152m; 500ft
Shield structure: Al-PET foil; shielded
Insulation colour: chrome
Type of wire: control cable
Conform to the norm: UL 1666
Kind of core: Cu
CPR standard: Eca
Cable application: indoor
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 22AWG
Operating temperature: -20...75°C
Cable external diameter: 5.64mm
Number of cores: 2
Cable structure: 2x14AWG
Core diameter: 14AWG
Package contents: 152m
Package contents - ft: 500ft
Rated voltage: 300V
на замовлення 302 шт:
термін постачання 21-30 дні (днів)
2+377.87 грн
50+277.35 грн
100+248.57 грн
152+219.00 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
CA00730.00C01 CA00730.00C01 BELDEN pVersion=0046&contRep=ZT&docId=005056AB752F1ED5A8E4E513F0B731CC&compId=CA00730.pdf?ci_sign=010be97a57e663c07b1f2955646565d9106668f7 Category: RJ45 Cables
Description: Patch cord; SF/UTP; Cat: 5e; RJ45 plug,both sides; stranded; Cu; 1m
Insulation colour: green
Kind of core: Cu
Kind of material: no flame propagation
Wire insulation material: FRNC
Cable application: PROFINET
Resistance to: mechanical stesses; most of chemical compounds; most of oils; most of solvents; UV rays
Type of connection cable: patch cord
Kind of wire: SF/UTP
Core structure: stranded
Operating temperature: -40...80°C
Cable external diameter: 6.5mm
Cable length: 1m
No. of pairs: 2
Cable structure: 2x2x22AWG
Number of cores: 4
Core diameter: 22AWG
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Cable/adapter structure: both sides; RJ45 plug
Ethernet category: Cat 5e
товару немає в наявності
В кошику  од. на суму  грн.
CA00730.00C03 CA00730.00C03 BELDEN pVersion=0046&contRep=ZT&docId=005056AB752F1ED5A8E4E513F0B731CC&compId=CA00730.pdf?ci_sign=010be97a57e663c07b1f2955646565d9106668f7 Category: RJ45 Cables
Description: Patch cord; SF/UTP; Cat: 5e; RJ45 plug,both sides; stranded; Cu; 3m
Cable structure: 2x2x22AWG
Core structure: stranded
Kind of core: Cu
Number of cores: 4
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Wire insulation material: FRNC
Insulation colour: green
Operating temperature: -40...80°C
Cable external diameter: 6.5mm
Ethernet category: Cat 5e
Kind of wire: SF/UTP
Resistance to: mechanical stesses; most of chemical compounds; most of oils; most of solvents; UV rays
Kind of material: no flame propagation
Type of connection cable: patch cord
Cable application: PROFINET
No. of pairs: 2
Cable length: 3m
Core diameter: 22AWG
Cable/adapter structure: both sides; RJ45 plug
на замовлення 19 шт:
термін постачання 21-30 дні (днів)
1+2517.71 грн
5+2104.49 грн
10+1870.30 грн
В кошику  од. на суму  грн.
CA00730.00C05 CA00730.00C05 BELDEN pVersion=0046&contRep=ZT&docId=005056AB752F1ED5A8E4E513F0B731CC&compId=CA00730.pdf?ci_sign=010be97a57e663c07b1f2955646565d9106668f7 Category: RJ45 Cables
Description: Patch cord; SF/UTP; Cat: 5e; RJ45 plug,both sides; stranded; Cu; 5m
Cable structure: 2x2x22AWG
Core structure: stranded
Kind of core: Cu
Number of cores: 4
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Wire insulation material: FRNC
Insulation colour: green
Operating temperature: -40...80°C
Cable external diameter: 6.5mm
Ethernet category: Cat 5e
Kind of wire: SF/UTP
Resistance to: mechanical stesses; most of chemical compounds; most of oils; most of solvents; UV rays
Kind of material: no flame propagation
Type of connection cable: patch cord
Cable application: PROFINET
No. of pairs: 2
Cable length: 5m
Core diameter: 22AWG
Cable/adapter structure: both sides; RJ45 plug
на замовлення 8 шт:
термін постачання 21-30 дні (днів)
1+3072.04 грн
5+2567.27 грн
В кошику  од. на суму  грн.
11872A 0081000 11872A 0081000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AB7065EC0D5&compId=11872A.0101000.pdf?ci_sign=d8ea24a94064248006886fdfa0b955107e7dd0d0 Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet; 6; wire; Cu; PVC; grey
Rated voltage: 300V
Operating temperature: -10...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable outside dimensions: 12.06x6.73mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Insulation colour: grey
товару немає в наявності
В кошику  од. на суму  грн.
11872A 0101000 11872A 0101000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AB7065EC0D5&compId=11872A.0101000.pdf?ci_sign=d8ea24a94064248006886fdfa0b955107e7dd0d0 Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet; 6; wire; Cu; PVC; black
Rated voltage: 300V
Operating temperature: -10...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable outside dimensions: 12.06x6.73mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
8505 003100 8505 003100 BELDEN 8505.pdf Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; PVC; orange; 600V; 30m; 100ft
Wire insulation material: PVC
Core structure: stranded
Operating temperature: -40...105°C
Cable external diameter: 0.99mm
Number of cores: 1
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: orange
Conform to the norm: MIL-W-16878/1 (Type B)
Kind of core: Cu; tinned
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
30+27.89 грн
60+23.34 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
7958A 0101000 7958A 0101000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA6E4B004B4CFE0D3&compId=7958A.0101000.PDF?ci_sign=9128125c2251eeb00d07faa3b2275aab8b4f1678 Category: Industrial Ethernet Cables
Description: Wire; F/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Ethernet category: Cat 5e
Cable application: indoor; industrial Ethernet; outdoor
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Kind of wire: F/UTP
Wire insulation material: PVC
Core structure: wire
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
Conform to the norm: UL 1666; UL 21047
Operating temperature: -40...75°C
Cable external diameter: 6.99mm
No. of pairs: 4
Number of cores: 8
Cable structure: 4x2x24AWG
Core diameter: 24AWG
Rated voltage: 0.6kV
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
7958A 0061000 7958A 0061000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB50F7AC12E0D5&compId=7958A.0061000.pdf?ci_sign=ddbb47196e2e6cfc6ce1b1c475d1a76e99f3f7f7 Category: Industrial Ethernet Cables
Description: Wire; F/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Ethernet category: Cat 5e
Cable application: indoor; industrial Ethernet; outdoor
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Kind of wire: F/UTP
Wire insulation material: PVC
Core structure: wire
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
Conform to the norm: UL 1666; UL 21047
Operating temperature: -40...75°C
Cable external diameter: 6.99mm
No. of pairs: 4
Number of cores: 8
Cable structure: 4x2x24AWG
Core diameter: 24AWG
Rated voltage: 0.6kV
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded
Insulation colour: blue
товару немає в наявності
В кошику  од. на суму  грн.
7958A 1NH1000 7958A 1NH1000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB50F7AC14A0D5&compId=7958A.1NH1000.pdf?ci_sign=50304c28d9e86870a4033a7163c63ec09ac2ce1a Category: Industrial Ethernet Cables
Description: Wire; F/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Ethernet category: Cat 5e
Cable application: indoor; industrial Ethernet; outdoor
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Kind of wire: F/UTP
Wire insulation material: PVC
Core structure: wire
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
Conform to the norm: UL 1666; UL 21047
Operating temperature: -40...75°C
Cable external diameter: 6.99mm
No. of pairs: 4
Number of cores: 8
Cable structure: 4x2x24AWG
Core diameter: 24AWG
Rated voltage: 0.6kV
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded
Insulation colour: turquoise
товару немає в наявності
В кошику  од. на суму  грн.
39118 010100 39118 010100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE89C0259FA61680D5&compId=39118.pdf?ci_sign=4755ab8ef7dae3d7023e20c663979c9e140297fe Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 18AWG; PPO; black; 600V; 30m; 100ft
Insulation colour: black
Kind of core: Cu; tinned
Wire insulation material: PPO
CPR standard: no classification
Core structure: stranded
Conform to the norm: UL 11028; VW-1
Operating temperature: -40...105°C
Cable external diameter: 1.75mm
Number of cores: 1
Core diameter: 18AWG
Package contents: 305m
Package contents - ft: 1000ft
Rated voltage: 0.6kV
Type of wire: assembly
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
30+86.08 грн
60+75.93 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
39126 010100 39126 010100 BELDEN 39126.pdf Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; PPO; black; 600V; 30m; 100ft
CPR standard: no classification
Wire insulation material: PPO
Core structure: stranded
Operating temperature: -40...105°C
Cable external diameter: 1.09mm
Number of cores: 1
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: black
Conform to the norm: UL 11028; VW-1
Kind of core: Cu; tinned
на замовлення 120 шт:
термін постачання 21-30 дні (днів)
30+57.33 грн
60+47.88 грн
120+42.60 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
9510.00305 9510.00305 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E1FFCEE27A60D6&compId=9510_EN.pdf?ci_sign=0cf970367cf2f2070950f980853b2519d85d6204 Category: Serial Bus Cables
Description: Wire; 10x2x24AWG; RS232; stranded; Cu; shielded,Al-PET foil; 305m
Insulation colour: chrome
Core marking: colours with colour repetition
Kind of core: Cu; tinned
CPR standard: Eca
Kind of material: flame retardant; no flame propagation
Conform to the norm: UL 1685; UL 2464
Cable application: indoor; RS232
Information: The UL Label and Mark on full factory packaging only
Earth core: none
Wire insulation material: PVC
Core structure: stranded
Ground: tinned copper strand 24AWG
Cable features: twisted pair conductors
Operating temperature: -30...80°C
Cable external diameter: 9.35mm
Number of cores: 20
Cable structure: 10x2x24AWG
No. of pairs: 10
Core diameter: 24AWG
Package contents: 305m
Package contents - ft: 1000ft
Rated voltage: 300V
Shield structure: Al-PET foil; shielded
Type of wire: data transmission
на замовлення 176 шт:
термін постачання 21-30 дні (днів)
1+1005.36 грн
50+739.33 грн
100+661.80 грн
В кошику  од. на суму  грн.
8219 010U500 8219 010U500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF9AF0826C5E4280D6&compId=8219_EN.pdf?ci_sign=d5a607efc1b6dca9cf0ccf0300e6c55202631fa6 Category: Coaxial Cables
Description: Wire: coaxial; RG58; 1x20AWG; stranded; Cu; PVC; black; 152m; 500ft
Kind of wire: RG58
Type of wire: coaxial
Resistance to: flame; UV rays
Kind of core: Cu; tinned
Cable application: GPS; indoor; outdoor
Conform to the norm: UL 1354; UL 1685
CPR standard: no classification
Wire insulation material: PVC
Shield structure: shielded; tinned copper braid
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -40...80°C
Cable external diameter: 4.9mm
Number of cores: 1
Cable structure: 1x20AWG
Core diameter: 20AWG
Wave impedance: 54Ω
Package contents: 152m
Rated voltage: 300V
Package contents - ft: 500ft
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
7930A 0101000 7930A 0101000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4FBC8D9F80D5&compId=7930A.0101000.pdf?ci_sign=cebd68add393d7d54e2f0b3a023219ba0b5f8f60 Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; stranded
Type of wire: data transmission
Kind of wire: U/UTP
Cable structure: 4x2x24AWG
Cable application: indoor; industrial Ethernet; outdoor
Ethernet category: Cat 5e
Core structure: stranded
Kind of core: Cu
Number of cores: 8
No. of pairs: 4
Core diameter: 24AWG
Shield structure: unshielded
Wire insulation material: PVC
Insulation colour: black
Operating temperature: -40...75°C
Cable external diameter: 6.1mm
CPR standard: Eca
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Information: The UL Label and Mark on full factory packaging only
Rated voltage: 300V
Package contents: 305m
Resistance to: UV rays
на замовлення 233 шт:
термін постачання 21-30 дні (днів)
3+214.33 грн
8+119.89 грн
22+113.50 грн
Мінімальне замовлення: 3
В кошику  од. на суму  грн.
7934A 0101000 7934A 0101000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4FBC57FB00D5&compId=7934A.0101000.pdf?ci_sign=8d1028502de3c11531e1825597bd359a256e51ae Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Type of wire: data transmission
Kind of wire: U/UTP
Cable structure: 4x2x24AWG
Cable application: indoor; industrial Ethernet; outdoor
Ethernet category: Cat 5e
Core structure: wire
Kind of core: Cu
Number of cores: 8
No. of pairs: 4
Core diameter: 24AWG
Shield structure: unshielded
Wire insulation material: PE
Insulation colour: black
Operating temperature: -40...75°C
Cable external diameter: 5.84mm
CPR standard: Fca
Cable features: gel filled
Kind of material: halogen free
Package contents - ft: 1000ft
Rated voltage: 300V
Package contents: 305m
на замовлення 305 шт:
термін постачання 21-30 дні (днів)
2+253.06 грн
7+141.47 грн
19+134.28 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
9985 008100 9985 008100 BELDEN 9985.pdf Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; PVC; grey; 300V; 30m; 100ft
CPR standard: no classification
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 80°C
Cable external diameter: 0.99mm
Number of cores: 1
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 300V
Type of wire: assembly
Insulation colour: grey
Conform to the norm: UL 1061; VW-1
Kind of core: Cu; tinned
на замовлення 150 шт:
термін постачання 21-30 дні (днів)
30+29.44 грн
60+24.62 грн
120+21.90 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
H155A00.00B100 H155A00.00B100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E200D66FFBA0D6&compId=H155A00_EN.pdf?ci_sign=384e7c8d3aceec8f332da41c6314942ba5164c0d Category: Coaxial Cables
Description: Wire: coaxial; H155,RG58; 1x16AWG; stranded; Cu; PVC; grey; 100m
Type of wire: coaxial
Kind of core: Cu
CPR standard: Eca
Kind of wire: H155; RG58
Wire insulation material: PVC
Core structure: stranded
Resistance to: to weather conditions
Operating temperature: -15...70°C
Cable external diameter: 5.4mm
Number of cores: 1
Cable structure: 1x16AWG
Core diameter: 16AWG
Wave impedance: 50Ω
Package contents: 100m
Package contents - ft: 328ft
Cable application: 2.4 GHz antenna installations; outdoor
Shield structure: Al-PET-Al foil; shielded twofold; tinned copper braid
Insulation colour: grey
товару немає в наявності
В кошику  од. на суму  грн.
8170 060500 8170 060500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E23BD58329A0D6&compId=8170_EN.pdf?ci_sign=cd45ad59dcf7edb88e7e17c392ba3ae19ce7bebb Category: Serial Bus Cables
Description: Wire; stranded; Cu; Insulation: PVC; chrome; RS232,RS422; 152m; 300V
Shield structure: Al-PET foil; pairs shielded with Al-PET foil; shielded threefold; tinned copper braid
Insulation colour: chrome
Kind of core: Cu; tinned
Type of wire: data transmission
CPR standard: Eca
Wire insulation material: PVC
Cable application: RS232; RS422
Core structure: stranded
Cable features: twisted pair conductors
Operating temperature: -40...60°C
Core section: 0.22mm2
Cable external diameter: 14.83mm
No. of pairs: 10
Number of cores: 20
Core diameter: 24AWG
Package contents: 152m
Package contents - ft: 500ft
Wave impedance: 100Ω
Rated voltage: 300V
товару немає в наявності
В кошику  од. на суму  грн.
8170 060100 8170 060100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E23BD58329A0D6&compId=8170_EN.pdf?ci_sign=cd45ad59dcf7edb88e7e17c392ba3ae19ce7bebb Category: Serial Bus Cables
Description: Wire; 10x2x24AWG; stranded; Cu; Insulation: PVC; chrome; 30m; 300V
Shield structure: Al-PET foil; pairs shielded with Al-PET foil; shielded threefold; tinned copper braid
Insulation colour: chrome
Kind of core: Cu; tinned
Type of wire: data transmission
Conform to the norm: UL 1685; UL 2493
CPR standard: Eca
Wire insulation material: PVC
Cable application: RS232; RS422
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable features: twisted pair conductors
Operating temperature: -40...60°C
Core section: 0.22mm2
Cable external diameter: 14.83mm
No. of pairs: 10
Cable structure: 10x2x24AWG
Number of cores: 20
Core diameter: 24AWG
Package contents: 30m
Package contents - ft: 100ft
Wave impedance: 100Ω
Rated voltage: 300V
товару немає в наявності
В кошику  од. на суму  грн.
8170 060500 8170 060500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E23BD58329A0D6&compId=8170_EN.pdf?ci_sign=cd45ad59dcf7edb88e7e17c392ba3ae19ce7bebb Category: Serial Bus Cables
Description: Wire; 10x2x24AWG; stranded; Cu; Insulation: PVC; chrome; 152m; 300V
Shield structure: Al-PET foil; pairs shielded with Al-PET foil; shielded threefold; tinned copper braid
Insulation colour: chrome
Kind of core: Cu; tinned
Type of wire: data transmission
Conform to the norm: UL 1685; UL 2493
CPR standard: Eca
Wire insulation material: PVC
Cable application: RS232; RS422
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable features: twisted pair conductors
Operating temperature: -40...60°C
Core section: 0.22mm2
Cable external diameter: 14.83mm
No. of pairs: 10
Cable structure: 10x2x24AWG
Number of cores: 20
Core diameter: 24AWG
Package contents: 152m
Package contents - ft: 500ft
Wave impedance: 100Ω
Rated voltage: 300V
товару немає в наявності
В кошику  од. на суму  грн.
8155 0601000 8155 0601000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E21E3C30AAE0D6&compId=8155_EN.pdf?ci_sign=4149474bfe72748bfe47feda5fe8115f91a23d73 Category: Serial Bus Cables
Description: Wire; 28x2x28AWG; RS232,RS485; stranded; Cu; Insulation: PVC; 305m
Rated voltage: 30V
Operating temperature: -30...80°C
Wire insulation material: PVC
Cable application: RS232; RS485
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable features: twisted pair conductors
Conform to the norm: UL 1685; UL 2919
Cable external diameter: 14.35mm
No. of pairs: 28
Core diameter: 28AWG
Cable structure: 28x2x28AWG
Number of cores: 56
Wave impedance: 120Ω
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Insulation colour: chrome
Core marking: colours with colour repetition
Kind of core: Cu; tinned
Type of wire: data transmission
CPR standard: Eca
Earth core: none
товару немає в наявності
В кошику  од. на суму  грн.
83007 002100 83007 002100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; red; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: red
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+222.94 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 006100 83007 006100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; light blue; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: light blue
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+222.94 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 009100 83007 009100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; white; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: white
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 150 шт:
термін постачання 21-30 дні (днів)
30+222.94 грн
60+186.23 грн
120+165.45 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 001100 83007 001100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; brown; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: brown
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 90 шт:
термін постачання 21-30 дні (днів)
30+197.97 грн
60+165.45 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 005100 83007 005100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; dark green; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: dark green
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+222.94 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 008100 83007 008100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; grey; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: grey
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
30+222.94 грн
60+186.23 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
8917 013100 8917 013100 BELDEN 8917.0011000.PDF Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 16AWG; PVC; dark blue; 600V; 30m; 1x16AWG; 100ft
Insulation colour: dark blue
CPR standard: no classification
Wire insulation material: PVC
Type of wire: assembly
Core structure: stranded
Shield structure: unshielded
Operating temperature: -25...105°C
Cable external diameter: 3.12mm
Number of cores: 1
Cable structure: 1x16AWG
Core diameter: 16AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1015; UL 1230; VW-1
Rated voltage: 0.6kV
Kind of core: Cu; tinned
на замовлення 90 шт:
термін постачання 21-30 дні (днів)
30+129.97 грн
60+108.70 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
8307 060500 8307 060500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA8CF891F231240C7&compId=8307.pdf?ci_sign=6ef3bf39d872177c0086092807ec52084d7eea30 Category: Serial Bus Cables
Description: Wire; 7x2x22AWG; RS232; stranded; Cu; Insulation: PVC; chrome; 152m
Rated voltage: 300V
Operating temperature: -30...80°C
Insulation colour: chrome
Type of wire: data transmission
Conform to the norm: UL 1685; UL 2464
Kind of core: Cu; tinned
CPR standard: Eca
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable external diameter: 8.84mm
Number of cores: 14
Cable structure: 7x2x22AWG
No. of pairs: 7
Core diameter: 22AWG
Package contents: 152m
Package contents - ft: 500ft
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Cable application: indoor; RS232
товару немає в наявності
В кошику  од. на суму  грн.
83002 008100 83002 008100 BELDEN 83002.001100.pdf Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; TFE; grey; 600V; 30m; 1x26AWG; 100ft
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 0.94mm
Number of cores: 1
Cable structure: 1x26AWG
Stranded core structure: 7/34AWG
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: grey
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
30+88.66 грн
60+74.33 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
3085A 5601000 3085A 5601000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4BB6F83D40D5&compId=3085A.5601000.pdf?ci_sign=ae91a35b9239cbdf56afa4db0ec54e6e08ad3060 Category: Serial Bus Cables
Description: Wire; 1x2x22AWG,1x2x24AWG; DeviceBus,DeviceNet; stranded; Cu
Insulation colour: yellow
Wire insulation material: CPE
Kind of core: Cu; tinned
Type of wire: data transmission
Cable application: DeviceBus; DeviceNet
CPR standard: Eca
Kind of material: no flame propagation
Shield structure: pairs shielded with Al-PET foil; shielded twofold; tinned copper braid
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Conform to the norm: UL 1685
Resistance to: UV rays
Operating temperature: -20...75°C
Cable external diameter: 7.11mm
Cable structure: 1x2x22AWG; 1x2x24AWG
No. of pairs: 2
Number of cores: 4
Rated voltage: 300V
Core diameter: 22AWG; 24AWG
Package contents: 305m
Wave impedance: 120Ω
Package contents - ft: 1000ft
товару немає в наявності
В кошику  од. на суму  грн.
83002 003100 83002 003100 BELDEN 83002.001100.pdf Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; TFE; orange; 600V; 30m; 1x26AWG; 100ft
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 0.94mm
Number of cores: 1
Cable structure: 1x26AWG
Stranded core structure: 7/34AWG
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: orange
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
на замовлення 270 шт:
термін постачання 21-30 дні (днів)
30+88.66 грн
60+74.33 грн
120+65.54 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
9980 010100 9980 010100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB5DCA78F479640D6&compId=9980_EN.pdf?ci_sign=3ff4a6585b5dc95651c4022929a9b269cd969a2b Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 16AWG; PVC; black; 300V; 30m; 100ft
Type of wire: assembly
Insulation colour: black
Kind of core: Cu; tinned
Conform to the norm: UL 1061; VW-1
CPR standard: no classification
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 80°C
Cable external diameter: 1.98mm
Number of cores: 1
Core diameter: 16AWG
Package contents: 30m
Rated voltage: 300V
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+129.97 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
121872A 0101000 121872A 0101000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AE8478AE0D5&compId=121872A.J221000.pdf?ci_sign=198e192556baf8b6717f43820818bbed45316e3e Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet,outdoor; 6; wire; Cu
Rated voltage: 300V
Operating temperature: -40...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet; outdoor
Resistance to: most of oils; rodents; UV rays
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable external diameter: 18.4mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1685
Cable features: aluminium armouring
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
121872A 0081000 121872A 0081000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AE8478AE0D5&compId=121872A.J221000.pdf?ci_sign=198e192556baf8b6717f43820818bbed45316e3e Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet,outdoor; 6; wire; Cu
Rated voltage: 300V
Operating temperature: -40...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet; outdoor
Resistance to: most of oils; rodents; UV rays
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable external diameter: 18.4mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1685
Cable features: aluminium armouring
Insulation colour: grey
товару немає в наявності
В кошику  од. на суму  грн.
121872A J221000 121872A J221000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AE8478AE0D5&compId=121872A.J221000.pdf?ci_sign=198e192556baf8b6717f43820818bbed45316e3e Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet,outdoor; 6; wire; Cu
Rated voltage: 300V
Operating temperature: -40...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet; outdoor
Resistance to: most of oils; rodents; UV rays
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable external diameter: 18.4mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1685
Cable features: aluminium armouring
Insulation colour: dark blue
товару немає в наявності
В кошику  од. на суму  грн.
83041 0061000 83041 0061000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E48BD43DDCC0D6&compId=83041_EN.pdf?ci_sign=d8b3f1cbf15410f54b3b4992031b0dba722abea4 Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 32AWG; TFE; light blue; 250V; 305m; 1x32AWG
Rated voltage: 250V
Conform to the norm: MIL-W-16878/6 (Type ET); UL 1371; VW-1
Insulation colour: light blue
CPR standard: no classification
Core structure: stranded
Wire insulation material: TFE
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: max. 105°C
Cable external diameter: 0.56mm
Number of cores: 1
Cable structure: 1x32AWG
Core diameter: 32AWG
Package contents: 305m
Package contents - ft: 1000ft
Type of wire: assembly
Kind of core: Cu; silver plated
товару немає в наявності
В кошику  од. на суму  грн.
3106DB 0101000 3106DB 0101000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4C4BB9C060D5&compId=3106DB.0101000.pdf?ci_sign=6ebe73a8e3e0a5b6b96d69ccc835c54f94ce1301 Category: Serial Bus Cables
Description: Wire; 1x3x22AWG; RS485,outdoor; stranded; Cu; Insulation: CPE; 305m
Operating temperature: -20...60°C
Wire insulation material: CPE
Kind of core: Cu; tinned
Type of wire: data transmission
Resistance to: flame; most of oils; UV rays
Kind of material: flame retardant; no flame propagation
Cable application: indoor; outdoor; RS485
CPR standard: no classification
Earth core: none
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 22AWG
Cable features: twisted pair conductors
Conform to the norm: UL 1277; UL 1685
Cable external diameter: 9.12mm
No. of pairs: 1
Cable structure: 1x3x22AWG
Number of cores: 2
Core diameter: 22AWG
Rated voltage: 300V
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Insulation colour: black
Core marking: colours with colour repetition
товару немає в наявності
В кошику  од. на суму  грн.
3GDCY-K100 3GDCY-K100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BFBDA1B0CBBBC143&compId=MachFlex350CY.pdf?ci_sign=029785a5c7f41b687d6ae77ef357a270042e5596 Category: Multicore Cables - Shielded
Description: Wire; MACHFLEX 350CY; 3G1.5mm2; shielded,tinned copper braid
Type of wire: control cable
Kind of wire: MACHFLEX 350CY
Cable structure: 3G1.5mm2
Core structure: stranded
Kind of core: Cu
Number of cores: 3
Core section: 1.5mm2
Core marking: black, numbered + ground wire
Shield structure: shielded; tinned copper braid
Wire insulation material: PVC
Insulation colour: transparent
Rated voltage: 300V; 500V
Kind of material: no flame propagation
Operating temperature: -15...70°C
Resistance to: most of chemical compounds; most of oils; UV rays
Cable application: assembly line tools; control for machines; industrial applications; industrial tools; production line tools
Package contents: 100m
Flexibility class: 5
Kind of package: reel
Cable external diameter: 9.3mm
CPR standard: no classification
Earth core: yellow-green
Package contents - ft: 328ft
товару немає в наявності
В кошику  од. на суму  грн.
C3GDCY-K100 C3GDCY-K100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BF8C925E693A6143&compId=MachFlex375CY.pdf?ci_sign=ecacd6122dbf5193c99c735173d639239ade5ec8 Category: Multicore Cables - Shielded
Description: Wire; MACHFLEX 375CY; 3G1.5mm2; shielded,tinned copper braid
Type of wire: control cable
Kind of wire: MACHFLEX 375CY
Cable structure: 3G1.5mm2
Core structure: stranded
Kind of core: Cu
Number of cores: 3
Core section: 1.5mm2
Core marking: colours without colour repetition + ground wire
Shield structure: shielded; tinned copper braid
Wire insulation material: PVC
Insulation colour: transparent
Rated voltage: 300V; 500V
Kind of material: no flame propagation
Operating temperature: -5...70°C
Resistance to: most of chemical compounds; most of oils; UV rays
Cable application: assembly line tools; control for machines; industrial applications; industrial tools; production line tools
Package contents: 100m
Flexibility class: 5
Kind of package: reel
Cable external diameter: 8.8mm
CPR standard: no classification
Earth core: yellow-green
Package contents - ft: 328ft
на замовлення 521 шт:
термін постачання 21-30 дні (днів)
2+331.39 грн
5+193.42 грн
14+183.03 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
83320E 009100 83320E 009100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E4D2BDA87F00D6&compId=83320E_EN.pdf?ci_sign=b4de52a0ec70a5834efe509aa773923c82bbbea8 Category: Heat resistant cables
Description: Wire; 2x20AWG; stranded; Cu; TFE; white; -65÷200°C; 600V; CPR: Eca
Core marking: colours without colour repetition
Type of wire: control cable
Kind of core: Cu; silver plated
CPR standard: Eca
Shield structure: shielded; silver plated copper braid
Core structure: stranded
Wire insulation material: TFE
Insulation colour: white
Operating temperature: -65...200°C
Cable external diameter: 4.04mm
Number of cores: 2
Cable structure: 2x20AWG
Core diameter: 20AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Conform to the norm: MIL-W-16878/4 (Type E); NEMA HP3
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
30+1330.73 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
5200UE 0021000 5200UE 0021000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; red; CPR: Eca
Cable application: alarm instalations; indoor
Shield structure: unshielded
Insulation colour: red
Type of wire: control cable
Kind of core: Cu
Conform to the norm: FT4; IEC 60332-1-2; UL 1666
CPR standard: Eca
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -20...75°C
Cable external diameter: 4.57mm
Number of cores: 2
Cable structure: 2x16AWG
Core diameter: 16AWG
Rated voltage: 300V
Package contents: 305m
Package contents - ft: 1000ft
на замовлення 286 шт:
термін постачання 21-30 дні (днів)
3+210.02 грн
50+155.06 грн
100+138.27 грн
Мінімальне замовлення: 3
В кошику  од. на суму  грн.
4200UE.00100 4200UE.00100 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F1A13350C0D2&compId=4200UE.pdf?ci_sign=93ffa1e89085e19ca5b257b51a6e0c270d8c1aeb Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 100m; Cu; stranded; grey; CPR: Eca; 328ft
Shield structure: unshielded
Cable application: indoor
Type of wire: control cable
Insulation colour: grey
Kind of core: Cu
CPR standard: Eca
Kind of material: halogen free; no flame propagation
Wire insulation material: LSZH
Core structure: stranded
Operating temperature: -20...70°C
Cable external diameter: 4.6mm
Cable structure: 2x16AWG
Number of cores: 2
Core diameter: 16AWG
Package contents: 100m
Package contents - ft: 328ft
на замовлення 43 шт:
термін постачання 21-30 дні (днів)
2+226.38 грн
25+166.25 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
5200UE 008500 5200UE 008500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 152m; Cu; stranded; grey; CPR: Eca
Cable application: alarm instalations; indoor
Shield structure: unshielded
Insulation colour: grey
Type of wire: control cable
Kind of core: Cu
Conform to the norm: FT4; IEC 60332-1-2; UL 1666
CPR standard: Eca
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -20...75°C
Cable external diameter: 4.57mm
Number of cores: 2
Cable structure: 2x16AWG
Core diameter: 16AWG
Rated voltage: 300V
Package contents: 152m
Package contents - ft: 500ft
на замовлення 83 шт:
термін постачання 21-30 дні (днів)
3+204.86 грн
50+150.26 грн
Мінімальне замовлення: 3
В кошику  од. на суму  грн.
8719 060500 8719 060500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E1FDE6463620D6&compId=8719_EN.pdf?ci_sign=63433e59c42d0cc2741528c03019d08af7f29c23 Category: Serial Bus Cables
Description: Wire; 2x16AWG; stranded; Cu; shielded,Al-PET foil; Insulation: PVC
Type of wire: data transmission
Cable structure: 2x16AWG
Cable application: indoor
Core structure: stranded
Kind of core: Cu; tinned
Number of cores: 2
Core diameter: 16AWG
Shield structure: Al-PET foil; shielded
Wire insulation material: PVC
Insulation colour: chrome
Operating temperature: -20...80°C
Package contents: 152m
CPR standard: Eca
Cable external diameter: 7.95mm
Rated voltage: 0.6kV
Earth core: none
Package contents - ft: 500ft
Conform to the norm: UL 1685; UL 20253
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 18AWG
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
1+466.53 грн
В кошику  од. на суму  грн.
4200FE.00500 4200FE.00500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F557E31460D2&compId=4200FE.pdf?ci_sign=c35aa029147c3b3ddeacfaa63c099f32adcda306 Category: Multicore Cables - Shielded
Description: Wire; 2x16AWG; shielded,Al-PET foil; LSZH; grey; 500m; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: Al-PET foil; shielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Eca
Cable external diameter: 4.7mm
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Cable application: indoor
Ground: tinned copper strand 24AWG
товару немає в наявності
В кошику  од. на суму  грн.
4200UE.01500 4200UE.01500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F1A13350C0D2&compId=4200UE.pdf?ci_sign=93ffa1e89085e19ca5b257b51a6e0c270d8c1aeb Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 500m; Cu; stranded; white; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: white
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Eca
Cable external diameter: 4.6mm
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
5200FE.00152 5200FE.00152 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1C0F472D3C0D2&compId=5200FE.pdf?ci_sign=5b593fe59f37d7f820e916714cdb247574207145 Category: Multicore Cables - Shielded
Description: Wire; 2x16AWG; shielded,Al-PET foil; PVC; chrome; 300V; 152m; 500ft
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: chrome
Shield structure: Al-PET foil; shielded
Wire insulation material: PVC
Package contents: 152m
Number of cores: 2
Operating temperature: -20...75°C
CPR standard: Eca
Cable external diameter: 4.78mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 500ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
товару немає в наявності
В кошику  од. на суму  грн.
4200ULW.00305 4200ULW.00305 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB39A0815EBEFC0D6&compId=4200ULW_EN.pdf?ci_sign=b78d77588cc85a0449c6d82a794729862f1e31bf Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; grey; CPR: Cca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 305m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Cca
Cable external diameter: 5.6mm
Rated voltage: 300V
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1000ft
Cable application: indoor
товару немає в наявності
В кошику  од. на суму  грн.
4200ULW.00500 4200ULW.00500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB39A0815EBEFC0D6&compId=4200ULW_EN.pdf?ci_sign=b78d77588cc85a0449c6d82a794729862f1e31bf Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 500m; Cu; stranded; grey; CPR: Cca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Cca
Cable external diameter: 5.6mm
Rated voltage: 300V
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Cable application: indoor
товару немає в наявності
В кошику  од. на суму  грн.
5200UE.00305 5200UE.00305 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; chrome; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: chrome
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: -20...75°C
CPR standard: Eca
Cable external diameter: 4.57mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
6200UE 8771000 6200UE 8771000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBCE52FED95AE20D6&compId=6200UE.pdf?ci_sign=4249fa0926d5394dd6b4fcbd9cfe97bdd1bb36c9 Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; grey; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: 0...75°C
CPR standard: Eca
Cable external diameter: 4.47mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 910
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
4200UE.00500 4200UE.00500 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F1A13350C0D2&compId=4200UE.pdf?ci_sign=93ffa1e89085e19ca5b257b51a6e0c270d8c1aeb Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 500m; Cu; stranded; grey; CPR: Eca; 1640ft
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Eca
Cable external diameter: 4.6mm
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
5200UE 009U1000 5200UE 009U1000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; white; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: white
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: -20...75°C
CPR standard: Eca
Cable external diameter: 4.57mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
6200UE 0091000 6200UE 0091000 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBCE52FED95AE20D6&compId=6200UE.pdf?ci_sign=4249fa0926d5394dd6b4fcbd9cfe97bdd1bb36c9 Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; white; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: white
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: 0...75°C
CPR standard: Eca
Cable external diameter: 4.47mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 910
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
8719.01305 8719.01305 BELDEN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E1FDE6463620D6&compId=8719_EN.pdf?ci_sign=63433e59c42d0cc2741528c03019d08af7f29c23 Category: Serial Bus Cables
Description: Wire; 2x16AWG; stranded; Cu; shielded,Al-PET foil; Insulation: PVC
Type of wire: data transmission
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu; tinned
Insulation colour: chrome
Shield structure: Al-PET foil; shielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: -20...80°C
CPR standard: Eca
Cable external diameter: 7.95mm
Rated voltage: 0.6kV
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 1685; UL 20253
Cable application: indoor
Earth core: none
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 18AWG
товару немає в наявності
В кошику  од. на суму  грн.
83049 008100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E4B4DFA620A0D6&compId=83049_EN.pdf?ci_sign=7f1bb3a782ca41a9344157025fea4d9842f22491
83049 008100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 22AWG; TFE; grey; 250V; 30m; 1x22AWG; 100ft
Type of wire: assembly
Insulation colour: grey
Conform to the norm: MIL-W-16878/6 (Type ET); UL 1371; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 105°C
Cable external diameter: 1.07mm
Number of cores: 1
Cable structure: 1x22AWG
Core diameter: 22AWG
Package contents: 30m
Rated voltage: 250V
Package contents - ft: 100ft
Shield structure: unshielded
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+187.64 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83049 009100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E4B4DFA620A0D6&compId=83049_EN.pdf?ci_sign=7f1bb3a782ca41a9344157025fea4d9842f22491
83049 009100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 22AWG; TFE; white; 250V; 30m; 1x22AWG; 100ft
Type of wire: assembly
Insulation colour: white
Conform to the norm: MIL-W-16878/6 (Type ET); UL 1371; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 105°C
Cable external diameter: 1.07mm
Number of cores: 1
Cable structure: 1x22AWG
Core diameter: 22AWG
Package contents: 305m
Rated voltage: 250V
Package contents - ft: 1000ft
Shield structure: unshielded
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+187.64 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
19509 B59250 pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA6E4AF0583F8A0D3&compId=19509.B59250.PDF?ci_sign=019cbf573f5d77512e2bc037bf4d828cb6d6ffa1
19509 B59250
Виробник: BELDEN
Category: Power Cords
Description: Wire; 3x18AWG; stranded; Cu; PVC; black; 300V; 76m; 18AWG; 250ft
Conform to the norm: UL SJTOW
Core marking: colours without colour repetition + ground wire
Kind of core: Cu
Type of wire: mains
CPR standard: no classification
Earth core: yellow-green
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -35...105°C
Cable external diameter: 8mm
Number of cores: 3
Cable structure: 3x18AWG
Core diameter: 18AWG
Package contents: 76m
Package contents - ft: 250ft
Rated voltage: 300V
Shield structure: unshielded
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
5100FE.00152 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3993B95473660D6&compId=5100FE_EN.pdf?ci_sign=2e2955dfd4ef7becd0eaf76e36bba43a62c4069b
5100FE.00152
Виробник: BELDEN
Category: Multicore Cables - Shielded
Description: Wire; 2x14AWG; shielded,Al-PET foil; PVC; chrome; 300V; 152m; 500ft
Shield structure: Al-PET foil; shielded
Insulation colour: chrome
Type of wire: control cable
Conform to the norm: UL 1666
Kind of core: Cu
CPR standard: Eca
Cable application: indoor
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 22AWG
Operating temperature: -20...75°C
Cable external diameter: 5.64mm
Number of cores: 2
Cable structure: 2x14AWG
Core diameter: 14AWG
Package contents: 152m
Package contents - ft: 500ft
Rated voltage: 300V
на замовлення 302 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
2+377.87 грн
50+277.35 грн
100+248.57 грн
152+219.00 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
CA00730.00C01 pVersion=0046&contRep=ZT&docId=005056AB752F1ED5A8E4E513F0B731CC&compId=CA00730.pdf?ci_sign=010be97a57e663c07b1f2955646565d9106668f7
CA00730.00C01
Виробник: BELDEN
Category: RJ45 Cables
Description: Patch cord; SF/UTP; Cat: 5e; RJ45 plug,both sides; stranded; Cu; 1m
Insulation colour: green
Kind of core: Cu
Kind of material: no flame propagation
Wire insulation material: FRNC
Cable application: PROFINET
Resistance to: mechanical stesses; most of chemical compounds; most of oils; most of solvents; UV rays
Type of connection cable: patch cord
Kind of wire: SF/UTP
Core structure: stranded
Operating temperature: -40...80°C
Cable external diameter: 6.5mm
Cable length: 1m
No. of pairs: 2
Cable structure: 2x2x22AWG
Number of cores: 4
Core diameter: 22AWG
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Cable/adapter structure: both sides; RJ45 plug
Ethernet category: Cat 5e
товару немає в наявності
В кошику  од. на суму  грн.
CA00730.00C03 pVersion=0046&contRep=ZT&docId=005056AB752F1ED5A8E4E513F0B731CC&compId=CA00730.pdf?ci_sign=010be97a57e663c07b1f2955646565d9106668f7
CA00730.00C03
Виробник: BELDEN
Category: RJ45 Cables
Description: Patch cord; SF/UTP; Cat: 5e; RJ45 plug,both sides; stranded; Cu; 3m
Cable structure: 2x2x22AWG
Core structure: stranded
Kind of core: Cu
Number of cores: 4
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Wire insulation material: FRNC
Insulation colour: green
Operating temperature: -40...80°C
Cable external diameter: 6.5mm
Ethernet category: Cat 5e
Kind of wire: SF/UTP
Resistance to: mechanical stesses; most of chemical compounds; most of oils; most of solvents; UV rays
Kind of material: no flame propagation
Type of connection cable: patch cord
Cable application: PROFINET
No. of pairs: 2
Cable length: 3m
Core diameter: 22AWG
Cable/adapter structure: both sides; RJ45 plug
на замовлення 19 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
1+2517.71 грн
5+2104.49 грн
10+1870.30 грн
В кошику  од. на суму  грн.
CA00730.00C05 pVersion=0046&contRep=ZT&docId=005056AB752F1ED5A8E4E513F0B731CC&compId=CA00730.pdf?ci_sign=010be97a57e663c07b1f2955646565d9106668f7
CA00730.00C05
Виробник: BELDEN
Category: RJ45 Cables
Description: Patch cord; SF/UTP; Cat: 5e; RJ45 plug,both sides; stranded; Cu; 5m
Cable structure: 2x2x22AWG
Core structure: stranded
Kind of core: Cu
Number of cores: 4
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Wire insulation material: FRNC
Insulation colour: green
Operating temperature: -40...80°C
Cable external diameter: 6.5mm
Ethernet category: Cat 5e
Kind of wire: SF/UTP
Resistance to: mechanical stesses; most of chemical compounds; most of oils; most of solvents; UV rays
Kind of material: no flame propagation
Type of connection cable: patch cord
Cable application: PROFINET
No. of pairs: 2
Cable length: 5m
Core diameter: 22AWG
Cable/adapter structure: both sides; RJ45 plug
на замовлення 8 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
1+3072.04 грн
5+2567.27 грн
В кошику  од. на суму  грн.
11872A 0081000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AB7065EC0D5&compId=11872A.0101000.pdf?ci_sign=d8ea24a94064248006886fdfa0b955107e7dd0d0
11872A 0081000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet; 6; wire; Cu; PVC; grey
Rated voltage: 300V
Operating temperature: -10...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable outside dimensions: 12.06x6.73mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Insulation colour: grey
товару немає в наявності
В кошику  од. на суму  грн.
11872A 0101000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AB7065EC0D5&compId=11872A.0101000.pdf?ci_sign=d8ea24a94064248006886fdfa0b955107e7dd0d0
11872A 0101000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet; 6; wire; Cu; PVC; black
Rated voltage: 300V
Operating temperature: -10...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable outside dimensions: 12.06x6.73mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
8505 003100 8505.pdf
8505 003100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; PVC; orange; 600V; 30m; 100ft
Wire insulation material: PVC
Core structure: stranded
Operating temperature: -40...105°C
Cable external diameter: 0.99mm
Number of cores: 1
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: orange
Conform to the norm: MIL-W-16878/1 (Type B)
Kind of core: Cu; tinned
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+27.89 грн
60+23.34 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
7958A 0101000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA6E4B004B4CFE0D3&compId=7958A.0101000.PDF?ci_sign=9128125c2251eeb00d07faa3b2275aab8b4f1678
7958A 0101000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; F/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Ethernet category: Cat 5e
Cable application: indoor; industrial Ethernet; outdoor
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Kind of wire: F/UTP
Wire insulation material: PVC
Core structure: wire
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
Conform to the norm: UL 1666; UL 21047
Operating temperature: -40...75°C
Cable external diameter: 6.99mm
No. of pairs: 4
Number of cores: 8
Cable structure: 4x2x24AWG
Core diameter: 24AWG
Rated voltage: 0.6kV
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
7958A 0061000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB50F7AC12E0D5&compId=7958A.0061000.pdf?ci_sign=ddbb47196e2e6cfc6ce1b1c475d1a76e99f3f7f7
7958A 0061000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; F/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Ethernet category: Cat 5e
Cable application: indoor; industrial Ethernet; outdoor
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Kind of wire: F/UTP
Wire insulation material: PVC
Core structure: wire
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
Conform to the norm: UL 1666; UL 21047
Operating temperature: -40...75°C
Cable external diameter: 6.99mm
No. of pairs: 4
Number of cores: 8
Cable structure: 4x2x24AWG
Core diameter: 24AWG
Rated voltage: 0.6kV
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded
Insulation colour: blue
товару немає в наявності
В кошику  од. на суму  грн.
7958A 1NH1000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB50F7AC14A0D5&compId=7958A.1NH1000.pdf?ci_sign=50304c28d9e86870a4033a7163c63ec09ac2ce1a
7958A 1NH1000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; F/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Ethernet category: Cat 5e
Cable application: indoor; industrial Ethernet; outdoor
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Kind of wire: F/UTP
Wire insulation material: PVC
Core structure: wire
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
Conform to the norm: UL 1666; UL 21047
Operating temperature: -40...75°C
Cable external diameter: 6.99mm
No. of pairs: 4
Number of cores: 8
Cable structure: 4x2x24AWG
Core diameter: 24AWG
Rated voltage: 0.6kV
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded
Insulation colour: turquoise
товару немає в наявності
В кошику  од. на суму  грн.
39118 010100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE89C0259FA61680D5&compId=39118.pdf?ci_sign=4755ab8ef7dae3d7023e20c663979c9e140297fe
39118 010100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 18AWG; PPO; black; 600V; 30m; 100ft
Insulation colour: black
Kind of core: Cu; tinned
Wire insulation material: PPO
CPR standard: no classification
Core structure: stranded
Conform to the norm: UL 11028; VW-1
Operating temperature: -40...105°C
Cable external diameter: 1.75mm
Number of cores: 1
Core diameter: 18AWG
Package contents: 305m
Package contents - ft: 1000ft
Rated voltage: 0.6kV
Type of wire: assembly
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+86.08 грн
60+75.93 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
39126 010100 39126.pdf
39126 010100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; PPO; black; 600V; 30m; 100ft
CPR standard: no classification
Wire insulation material: PPO
Core structure: stranded
Operating temperature: -40...105°C
Cable external diameter: 1.09mm
Number of cores: 1
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: black
Conform to the norm: UL 11028; VW-1
Kind of core: Cu; tinned
на замовлення 120 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+57.33 грн
60+47.88 грн
120+42.60 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
9510.00305 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E1FFCEE27A60D6&compId=9510_EN.pdf?ci_sign=0cf970367cf2f2070950f980853b2519d85d6204
9510.00305
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 10x2x24AWG; RS232; stranded; Cu; shielded,Al-PET foil; 305m
Insulation colour: chrome
Core marking: colours with colour repetition
Kind of core: Cu; tinned
CPR standard: Eca
Kind of material: flame retardant; no flame propagation
Conform to the norm: UL 1685; UL 2464
Cable application: indoor; RS232
Information: The UL Label and Mark on full factory packaging only
Earth core: none
Wire insulation material: PVC
Core structure: stranded
Ground: tinned copper strand 24AWG
Cable features: twisted pair conductors
Operating temperature: -30...80°C
Cable external diameter: 9.35mm
Number of cores: 20
Cable structure: 10x2x24AWG
No. of pairs: 10
Core diameter: 24AWG
Package contents: 305m
Package contents - ft: 1000ft
Rated voltage: 300V
Shield structure: Al-PET foil; shielded
Type of wire: data transmission
на замовлення 176 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
1+1005.36 грн
50+739.33 грн
100+661.80 грн
В кошику  од. на суму  грн.
8219 010U500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF9AF0826C5E4280D6&compId=8219_EN.pdf?ci_sign=d5a607efc1b6dca9cf0ccf0300e6c55202631fa6
8219 010U500
Виробник: BELDEN
Category: Coaxial Cables
Description: Wire: coaxial; RG58; 1x20AWG; stranded; Cu; PVC; black; 152m; 500ft
Kind of wire: RG58
Type of wire: coaxial
Resistance to: flame; UV rays
Kind of core: Cu; tinned
Cable application: GPS; indoor; outdoor
Conform to the norm: UL 1354; UL 1685
CPR standard: no classification
Wire insulation material: PVC
Shield structure: shielded; tinned copper braid
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -40...80°C
Cable external diameter: 4.9mm
Number of cores: 1
Cable structure: 1x20AWG
Core diameter: 20AWG
Wave impedance: 54Ω
Package contents: 152m
Rated voltage: 300V
Package contents - ft: 500ft
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
7930A 0101000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4FBC8D9F80D5&compId=7930A.0101000.pdf?ci_sign=cebd68add393d7d54e2f0b3a023219ba0b5f8f60
7930A 0101000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; stranded
Type of wire: data transmission
Kind of wire: U/UTP
Cable structure: 4x2x24AWG
Cable application: indoor; industrial Ethernet; outdoor
Ethernet category: Cat 5e
Core structure: stranded
Kind of core: Cu
Number of cores: 8
No. of pairs: 4
Core diameter: 24AWG
Shield structure: unshielded
Wire insulation material: PVC
Insulation colour: black
Operating temperature: -40...75°C
Cable external diameter: 6.1mm
CPR standard: Eca
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Information: The UL Label and Mark on full factory packaging only
Rated voltage: 300V
Package contents: 305m
Resistance to: UV rays
на замовлення 233 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
3+214.33 грн
8+119.89 грн
22+113.50 грн
Мінімальне замовлення: 3
В кошику  од. на суму  грн.
7934A 0101000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4FBC57FB00D5&compId=7934A.0101000.pdf?ci_sign=8d1028502de3c11531e1825597bd359a256e51ae
7934A 0101000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x24AWG; industrial Ethernet,outdoor; 5e; wire; Cu
Type of wire: data transmission
Kind of wire: U/UTP
Cable structure: 4x2x24AWG
Cable application: indoor; industrial Ethernet; outdoor
Ethernet category: Cat 5e
Core structure: wire
Kind of core: Cu
Number of cores: 8
No. of pairs: 4
Core diameter: 24AWG
Shield structure: unshielded
Wire insulation material: PE
Insulation colour: black
Operating temperature: -40...75°C
Cable external diameter: 5.84mm
CPR standard: Fca
Cable features: gel filled
Kind of material: halogen free
Package contents - ft: 1000ft
Rated voltage: 300V
Package contents: 305m
на замовлення 305 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
2+253.06 грн
7+141.47 грн
19+134.28 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
9985 008100 9985.pdf
9985 008100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; PVC; grey; 300V; 30m; 100ft
CPR standard: no classification
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 80°C
Cable external diameter: 0.99mm
Number of cores: 1
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 300V
Type of wire: assembly
Insulation colour: grey
Conform to the norm: UL 1061; VW-1
Kind of core: Cu; tinned
на замовлення 150 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+29.44 грн
60+24.62 грн
120+21.90 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
H155A00.00B100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E200D66FFBA0D6&compId=H155A00_EN.pdf?ci_sign=384e7c8d3aceec8f332da41c6314942ba5164c0d
H155A00.00B100
Виробник: BELDEN
Category: Coaxial Cables
Description: Wire: coaxial; H155,RG58; 1x16AWG; stranded; Cu; PVC; grey; 100m
Type of wire: coaxial
Kind of core: Cu
CPR standard: Eca
Kind of wire: H155; RG58
Wire insulation material: PVC
Core structure: stranded
Resistance to: to weather conditions
Operating temperature: -15...70°C
Cable external diameter: 5.4mm
Number of cores: 1
Cable structure: 1x16AWG
Core diameter: 16AWG
Wave impedance: 50Ω
Package contents: 100m
Package contents - ft: 328ft
Cable application: 2.4 GHz antenna installations; outdoor
Shield structure: Al-PET-Al foil; shielded twofold; tinned copper braid
Insulation colour: grey
товару немає в наявності
В кошику  од. на суму  грн.
8170 060500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E23BD58329A0D6&compId=8170_EN.pdf?ci_sign=cd45ad59dcf7edb88e7e17c392ba3ae19ce7bebb
8170 060500
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; stranded; Cu; Insulation: PVC; chrome; RS232,RS422; 152m; 300V
Shield structure: Al-PET foil; pairs shielded with Al-PET foil; shielded threefold; tinned copper braid
Insulation colour: chrome
Kind of core: Cu; tinned
Type of wire: data transmission
CPR standard: Eca
Wire insulation material: PVC
Cable application: RS232; RS422
Core structure: stranded
Cable features: twisted pair conductors
Operating temperature: -40...60°C
Core section: 0.22mm2
Cable external diameter: 14.83mm
No. of pairs: 10
Number of cores: 20
Core diameter: 24AWG
Package contents: 152m
Package contents - ft: 500ft
Wave impedance: 100Ω
Rated voltage: 300V
товару немає в наявності
В кошику  од. на суму  грн.
8170 060100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E23BD58329A0D6&compId=8170_EN.pdf?ci_sign=cd45ad59dcf7edb88e7e17c392ba3ae19ce7bebb
8170 060100
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 10x2x24AWG; stranded; Cu; Insulation: PVC; chrome; 30m; 300V
Shield structure: Al-PET foil; pairs shielded with Al-PET foil; shielded threefold; tinned copper braid
Insulation colour: chrome
Kind of core: Cu; tinned
Type of wire: data transmission
Conform to the norm: UL 1685; UL 2493
CPR standard: Eca
Wire insulation material: PVC
Cable application: RS232; RS422
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable features: twisted pair conductors
Operating temperature: -40...60°C
Core section: 0.22mm2
Cable external diameter: 14.83mm
No. of pairs: 10
Cable structure: 10x2x24AWG
Number of cores: 20
Core diameter: 24AWG
Package contents: 30m
Package contents - ft: 100ft
Wave impedance: 100Ω
Rated voltage: 300V
товару немає в наявності
В кошику  од. на суму  грн.
8170 060500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E23BD58329A0D6&compId=8170_EN.pdf?ci_sign=cd45ad59dcf7edb88e7e17c392ba3ae19ce7bebb
8170 060500
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 10x2x24AWG; stranded; Cu; Insulation: PVC; chrome; 152m; 300V
Shield structure: Al-PET foil; pairs shielded with Al-PET foil; shielded threefold; tinned copper braid
Insulation colour: chrome
Kind of core: Cu; tinned
Type of wire: data transmission
Conform to the norm: UL 1685; UL 2493
CPR standard: Eca
Wire insulation material: PVC
Cable application: RS232; RS422
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable features: twisted pair conductors
Operating temperature: -40...60°C
Core section: 0.22mm2
Cable external diameter: 14.83mm
No. of pairs: 10
Cable structure: 10x2x24AWG
Number of cores: 20
Core diameter: 24AWG
Package contents: 152m
Package contents - ft: 500ft
Wave impedance: 100Ω
Rated voltage: 300V
товару немає в наявності
В кошику  од. на суму  грн.
8155 0601000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E21E3C30AAE0D6&compId=8155_EN.pdf?ci_sign=4149474bfe72748bfe47feda5fe8115f91a23d73
8155 0601000
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 28x2x28AWG; RS232,RS485; stranded; Cu; Insulation: PVC; 305m
Rated voltage: 30V
Operating temperature: -30...80°C
Wire insulation material: PVC
Cable application: RS232; RS485
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable features: twisted pair conductors
Conform to the norm: UL 1685; UL 2919
Cable external diameter: 14.35mm
No. of pairs: 28
Core diameter: 28AWG
Cable structure: 28x2x28AWG
Number of cores: 56
Wave impedance: 120Ω
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Insulation colour: chrome
Core marking: colours with colour repetition
Kind of core: Cu; tinned
Type of wire: data transmission
CPR standard: Eca
Earth core: none
товару немає в наявності
В кошику  од. на суму  грн.
83007 002100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca
83007 002100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; red; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: red
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+222.94 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 006100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca
83007 006100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; light blue; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: light blue
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+222.94 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 009100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca
83007 009100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; white; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: white
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 150 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+222.94 грн
60+186.23 грн
120+165.45 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 001100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca
83007 001100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; brown; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: brown
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 90 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+197.97 грн
60+165.45 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 005100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca
83007 005100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; dark green; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: dark green
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+222.94 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
83007 008100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E2DD34EF54C0D6&compId=83007_EN.pdf?ci_sign=fcf826ed5bd18771263f726ad22ff9dd1cbcd2ca
83007 008100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 20AWG; TFE; grey; 600V; 30m; 1x20AWG; 100ft
Type of wire: assembly
Insulation colour: grey
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 1.4mm
Number of cores: 1
Cable structure: 1x20AWG
Stranded core structure: 19/32AWG
Core diameter: 20AWG
Package contents: 30m
Rated voltage: 0.6kV
Package contents - ft: 100ft
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+222.94 грн
60+186.23 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
8917 013100 8917.0011000.PDF
8917 013100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 16AWG; PVC; dark blue; 600V; 30m; 1x16AWG; 100ft
Insulation colour: dark blue
CPR standard: no classification
Wire insulation material: PVC
Type of wire: assembly
Core structure: stranded
Shield structure: unshielded
Operating temperature: -25...105°C
Cable external diameter: 3.12mm
Number of cores: 1
Cable structure: 1x16AWG
Core diameter: 16AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1015; UL 1230; VW-1
Rated voltage: 0.6kV
Kind of core: Cu; tinned
на замовлення 90 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+129.97 грн
60+108.70 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
8307 060500 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA8CF891F231240C7&compId=8307.pdf?ci_sign=6ef3bf39d872177c0086092807ec52084d7eea30
8307 060500
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 7x2x22AWG; RS232; stranded; Cu; Insulation: PVC; chrome; 152m
Rated voltage: 300V
Operating temperature: -30...80°C
Insulation colour: chrome
Type of wire: data transmission
Conform to the norm: UL 1685; UL 2464
Kind of core: Cu; tinned
CPR standard: Eca
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Cable external diameter: 8.84mm
Number of cores: 14
Cable structure: 7x2x22AWG
No. of pairs: 7
Core diameter: 22AWG
Package contents: 152m
Package contents - ft: 500ft
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Cable application: indoor; RS232
товару немає в наявності
В кошику  од. на суму  грн.
83002 008100 83002.001100.pdf
83002 008100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; TFE; grey; 600V; 30m; 1x26AWG; 100ft
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 0.94mm
Number of cores: 1
Cable structure: 1x26AWG
Stranded core structure: 7/34AWG
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: grey
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
на замовлення 60 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+88.66 грн
60+74.33 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
3085A 5601000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4BB6F83D40D5&compId=3085A.5601000.pdf?ci_sign=ae91a35b9239cbdf56afa4db0ec54e6e08ad3060
3085A 5601000
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 1x2x22AWG,1x2x24AWG; DeviceBus,DeviceNet; stranded; Cu
Insulation colour: yellow
Wire insulation material: CPE
Kind of core: Cu; tinned
Type of wire: data transmission
Cable application: DeviceBus; DeviceNet
CPR standard: Eca
Kind of material: no flame propagation
Shield structure: pairs shielded with Al-PET foil; shielded twofold; tinned copper braid
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Conform to the norm: UL 1685
Resistance to: UV rays
Operating temperature: -20...75°C
Cable external diameter: 7.11mm
Cable structure: 1x2x22AWG; 1x2x24AWG
No. of pairs: 2
Number of cores: 4
Rated voltage: 300V
Core diameter: 22AWG; 24AWG
Package contents: 305m
Wave impedance: 120Ω
Package contents - ft: 1000ft
товару немає в наявності
В кошику  од. на суму  грн.
83002 003100 83002.001100.pdf
83002 003100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 26AWG; TFE; orange; 600V; 30m; 1x26AWG; 100ft
CPR standard: no classification
Wire insulation material: TFE
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: -70...200°C
Cable external diameter: 0.94mm
Number of cores: 1
Cable structure: 1x26AWG
Stranded core structure: 7/34AWG
Core diameter: 26AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Type of wire: assembly
Insulation colour: orange
Conform to the norm: MIL-W-16878/4; UL 1213; VW-1
Kind of core: Cu; silver plated
на замовлення 270 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+88.66 грн
60+74.33 грн
120+65.54 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
9980 010100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB5DCA78F479640D6&compId=9980_EN.pdf?ci_sign=3ff4a6585b5dc95651c4022929a9b269cd969a2b
9980 010100
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 16AWG; PVC; black; 300V; 30m; 100ft
Type of wire: assembly
Insulation colour: black
Kind of core: Cu; tinned
Conform to the norm: UL 1061; VW-1
CPR standard: no classification
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: max. 80°C
Cable external diameter: 1.98mm
Number of cores: 1
Core diameter: 16AWG
Package contents: 30m
Rated voltage: 300V
Package contents - ft: 100ft
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+129.97 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
121872A 0101000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AE8478AE0D5&compId=121872A.J221000.pdf?ci_sign=198e192556baf8b6717f43820818bbed45316e3e
121872A 0101000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet,outdoor; 6; wire; Cu
Rated voltage: 300V
Operating temperature: -40...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet; outdoor
Resistance to: most of oils; rodents; UV rays
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable external diameter: 18.4mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1685
Cable features: aluminium armouring
Insulation colour: black
товару немає в наявності
В кошику  од. на суму  грн.
121872A 0081000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AE8478AE0D5&compId=121872A.J221000.pdf?ci_sign=198e192556baf8b6717f43820818bbed45316e3e
121872A 0081000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet,outdoor; 6; wire; Cu
Rated voltage: 300V
Operating temperature: -40...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet; outdoor
Resistance to: most of oils; rodents; UV rays
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable external diameter: 18.4mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1685
Cable features: aluminium armouring
Insulation colour: grey
товару немає в наявності
В кошику  од. на суму  грн.
121872A J221000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4AE8478AE0D5&compId=121872A.J221000.pdf?ci_sign=198e192556baf8b6717f43820818bbed45316e3e
121872A J221000
Виробник: BELDEN
Category: Industrial Ethernet Cables
Description: Wire; U/UTP; 4x2x23AWG; industrial Ethernet,outdoor; 6; wire; Cu
Rated voltage: 300V
Operating temperature: -40...75°C
Ethernet category: Cat 6
Kind of core: Cu
Type of wire: data transmission
CPR standard: Eca
Cable application: indoor; industrial Ethernet; outdoor
Resistance to: most of oils; rodents; UV rays
Wire insulation material: PVC
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Kind of wire: U/UTP
Core structure: wire
Cable external diameter: 18.4mm
No. of pairs: 4
Cable structure: 4x2x23AWG
Number of cores: 8
Core diameter: 23AWG
Package contents: 305m
Package contents - ft: 1000ft
Conform to the norm: UL 1685
Cable features: aluminium armouring
Insulation colour: dark blue
товару немає в наявності
В кошику  од. на суму  грн.
83041 0061000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E48BD43DDCC0D6&compId=83041_EN.pdf?ci_sign=d8b3f1cbf15410f54b3b4992031b0dba722abea4
83041 0061000
Виробник: BELDEN
Category: Single Core Cable - Strand
Description: Wire; stranded; Cu; 32AWG; TFE; light blue; 250V; 305m; 1x32AWG
Rated voltage: 250V
Conform to the norm: MIL-W-16878/6 (Type ET); UL 1371; VW-1
Insulation colour: light blue
CPR standard: no classification
Core structure: stranded
Wire insulation material: TFE
Information: The UL Label and Mark on full factory packaging only
Shield structure: unshielded
Operating temperature: max. 105°C
Cable external diameter: 0.56mm
Number of cores: 1
Cable structure: 1x32AWG
Core diameter: 32AWG
Package contents: 305m
Package contents - ft: 1000ft
Type of wire: assembly
Kind of core: Cu; silver plated
товару немає в наявності
В кошику  од. на суму  грн.
3106DB 0101000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE8DEB4C4BB9C060D5&compId=3106DB.0101000.pdf?ci_sign=6ebe73a8e3e0a5b6b96d69ccc835c54f94ce1301
3106DB 0101000
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 1x3x22AWG; RS485,outdoor; stranded; Cu; Insulation: CPE; 305m
Operating temperature: -20...60°C
Wire insulation material: CPE
Kind of core: Cu; tinned
Type of wire: data transmission
Resistance to: flame; most of oils; UV rays
Kind of material: flame retardant; no flame propagation
Cable application: indoor; outdoor; RS485
CPR standard: no classification
Earth core: none
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 22AWG
Cable features: twisted pair conductors
Conform to the norm: UL 1277; UL 1685
Cable external diameter: 9.12mm
No. of pairs: 1
Cable structure: 1x3x22AWG
Number of cores: 2
Core diameter: 22AWG
Rated voltage: 300V
Package contents: 305m
Package contents - ft: 1000ft
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Insulation colour: black
Core marking: colours with colour repetition
товару немає в наявності
В кошику  од. на суму  грн.
3GDCY-K100 pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BFBDA1B0CBBBC143&compId=MachFlex350CY.pdf?ci_sign=029785a5c7f41b687d6ae77ef357a270042e5596
3GDCY-K100
Виробник: BELDEN
Category: Multicore Cables - Shielded
Description: Wire; MACHFLEX 350CY; 3G1.5mm2; shielded,tinned copper braid
Type of wire: control cable
Kind of wire: MACHFLEX 350CY
Cable structure: 3G1.5mm2
Core structure: stranded
Kind of core: Cu
Number of cores: 3
Core section: 1.5mm2
Core marking: black, numbered + ground wire
Shield structure: shielded; tinned copper braid
Wire insulation material: PVC
Insulation colour: transparent
Rated voltage: 300V; 500V
Kind of material: no flame propagation
Operating temperature: -15...70°C
Resistance to: most of chemical compounds; most of oils; UV rays
Cable application: assembly line tools; control for machines; industrial applications; industrial tools; production line tools
Package contents: 100m
Flexibility class: 5
Kind of package: reel
Cable external diameter: 9.3mm
CPR standard: no classification
Earth core: yellow-green
Package contents - ft: 328ft
товару немає в наявності
В кошику  од. на суму  грн.
C3GDCY-K100 pVersion=0046&contRep=ZT&docId=005056AB0ED61ED8BF8C925E693A6143&compId=MachFlex375CY.pdf?ci_sign=ecacd6122dbf5193c99c735173d639239ade5ec8
C3GDCY-K100
Виробник: BELDEN
Category: Multicore Cables - Shielded
Description: Wire; MACHFLEX 375CY; 3G1.5mm2; shielded,tinned copper braid
Type of wire: control cable
Kind of wire: MACHFLEX 375CY
Cable structure: 3G1.5mm2
Core structure: stranded
Kind of core: Cu
Number of cores: 3
Core section: 1.5mm2
Core marking: colours without colour repetition + ground wire
Shield structure: shielded; tinned copper braid
Wire insulation material: PVC
Insulation colour: transparent
Rated voltage: 300V; 500V
Kind of material: no flame propagation
Operating temperature: -5...70°C
Resistance to: most of chemical compounds; most of oils; UV rays
Cable application: assembly line tools; control for machines; industrial applications; industrial tools; production line tools
Package contents: 100m
Flexibility class: 5
Kind of package: reel
Cable external diameter: 8.8mm
CPR standard: no classification
Earth core: yellow-green
Package contents - ft: 328ft
на замовлення 521 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
2+331.39 грн
5+193.42 грн
14+183.03 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
83320E 009100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E4D2BDA87F00D6&compId=83320E_EN.pdf?ci_sign=b4de52a0ec70a5834efe509aa773923c82bbbea8
83320E 009100
Виробник: BELDEN
Category: Heat resistant cables
Description: Wire; 2x20AWG; stranded; Cu; TFE; white; -65÷200°C; 600V; CPR: Eca
Core marking: colours without colour repetition
Type of wire: control cable
Kind of core: Cu; silver plated
CPR standard: Eca
Shield structure: shielded; silver plated copper braid
Core structure: stranded
Wire insulation material: TFE
Insulation colour: white
Operating temperature: -65...200°C
Cable external diameter: 4.04mm
Number of cores: 2
Cable structure: 2x20AWG
Core diameter: 20AWG
Package contents: 30m
Package contents - ft: 100ft
Rated voltage: 0.6kV
Conform to the norm: MIL-W-16878/4 (Type E); NEMA HP3
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
30+1330.73 грн
Мінімальне замовлення: 30
В кошику  од. на суму  грн.
5200UE 0021000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba
5200UE 0021000
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; red; CPR: Eca
Cable application: alarm instalations; indoor
Shield structure: unshielded
Insulation colour: red
Type of wire: control cable
Kind of core: Cu
Conform to the norm: FT4; IEC 60332-1-2; UL 1666
CPR standard: Eca
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -20...75°C
Cable external diameter: 4.57mm
Number of cores: 2
Cable structure: 2x16AWG
Core diameter: 16AWG
Rated voltage: 300V
Package contents: 305m
Package contents - ft: 1000ft
на замовлення 286 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
3+210.02 грн
50+155.06 грн
100+138.27 грн
Мінімальне замовлення: 3
В кошику  од. на суму  грн.
4200UE.00100 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F1A13350C0D2&compId=4200UE.pdf?ci_sign=93ffa1e89085e19ca5b257b51a6e0c270d8c1aeb
4200UE.00100
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 100m; Cu; stranded; grey; CPR: Eca; 328ft
Shield structure: unshielded
Cable application: indoor
Type of wire: control cable
Insulation colour: grey
Kind of core: Cu
CPR standard: Eca
Kind of material: halogen free; no flame propagation
Wire insulation material: LSZH
Core structure: stranded
Operating temperature: -20...70°C
Cable external diameter: 4.6mm
Cable structure: 2x16AWG
Number of cores: 2
Core diameter: 16AWG
Package contents: 100m
Package contents - ft: 328ft
на замовлення 43 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
2+226.38 грн
25+166.25 грн
Мінімальне замовлення: 2
В кошику  од. на суму  грн.
5200UE 008500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba
5200UE 008500
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 152m; Cu; stranded; grey; CPR: Eca
Cable application: alarm instalations; indoor
Shield structure: unshielded
Insulation colour: grey
Type of wire: control cable
Kind of core: Cu
Conform to the norm: FT4; IEC 60332-1-2; UL 1666
CPR standard: Eca
Wire insulation material: PVC
Core structure: stranded
Information: The UL Label and Mark on full factory packaging only
Operating temperature: -20...75°C
Cable external diameter: 4.57mm
Number of cores: 2
Cable structure: 2x16AWG
Core diameter: 16AWG
Rated voltage: 300V
Package contents: 152m
Package contents - ft: 500ft
на замовлення 83 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
3+204.86 грн
50+150.26 грн
Мінімальне замовлення: 3
В кошику  од. на суму  грн.
8719 060500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E1FDE6463620D6&compId=8719_EN.pdf?ci_sign=63433e59c42d0cc2741528c03019d08af7f29c23
8719 060500
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 2x16AWG; stranded; Cu; shielded,Al-PET foil; Insulation: PVC
Type of wire: data transmission
Cable structure: 2x16AWG
Cable application: indoor
Core structure: stranded
Kind of core: Cu; tinned
Number of cores: 2
Core diameter: 16AWG
Shield structure: Al-PET foil; shielded
Wire insulation material: PVC
Insulation colour: chrome
Operating temperature: -20...80°C
Package contents: 152m
CPR standard: Eca
Cable external diameter: 7.95mm
Rated voltage: 0.6kV
Earth core: none
Package contents - ft: 500ft
Conform to the norm: UL 1685; UL 20253
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 18AWG
на замовлення 30 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
1+466.53 грн
В кошику  од. на суму  грн.
4200FE.00500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F557E31460D2&compId=4200FE.pdf?ci_sign=c35aa029147c3b3ddeacfaa63c099f32adcda306
4200FE.00500
Виробник: BELDEN
Category: Multicore Cables - Shielded
Description: Wire; 2x16AWG; shielded,Al-PET foil; LSZH; grey; 500m; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: Al-PET foil; shielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Eca
Cable external diameter: 4.7mm
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Cable application: indoor
Ground: tinned copper strand 24AWG
товару немає в наявності
В кошику  од. на суму  грн.
4200UE.01500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F1A13350C0D2&compId=4200UE.pdf?ci_sign=93ffa1e89085e19ca5b257b51a6e0c270d8c1aeb
4200UE.01500
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 500m; Cu; stranded; white; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: white
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Eca
Cable external diameter: 4.6mm
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
5200FE.00152 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1C0F472D3C0D2&compId=5200FE.pdf?ci_sign=5b593fe59f37d7f820e916714cdb247574207145
5200FE.00152
Виробник: BELDEN
Category: Multicore Cables - Shielded
Description: Wire; 2x16AWG; shielded,Al-PET foil; PVC; chrome; 300V; 152m; 500ft
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: chrome
Shield structure: Al-PET foil; shielded
Wire insulation material: PVC
Package contents: 152m
Number of cores: 2
Operating temperature: -20...75°C
CPR standard: Eca
Cable external diameter: 4.78mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 500ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 24AWG
товару немає в наявності
В кошику  од. на суму  грн.
4200ULW.00305 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB39A0815EBEFC0D6&compId=4200ULW_EN.pdf?ci_sign=b78d77588cc85a0449c6d82a794729862f1e31bf
4200ULW.00305
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; grey; CPR: Cca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 305m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Cca
Cable external diameter: 5.6mm
Rated voltage: 300V
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1000ft
Cable application: indoor
товару немає в наявності
В кошику  од. на суму  грн.
4200ULW.00500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB39A0815EBEFC0D6&compId=4200ULW_EN.pdf?ci_sign=b78d77588cc85a0449c6d82a794729862f1e31bf
4200ULW.00500
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 500m; Cu; stranded; grey; CPR: Cca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Cca
Cable external diameter: 5.6mm
Rated voltage: 300V
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Cable application: indoor
товару немає в наявності
В кошику  од. на суму  грн.
5200UE.00305 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba
5200UE.00305
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; chrome; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: chrome
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: -20...75°C
CPR standard: Eca
Cable external diameter: 4.57mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
6200UE 8771000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBCE52FED95AE20D6&compId=6200UE.pdf?ci_sign=4249fa0926d5394dd6b4fcbd9cfe97bdd1bb36c9
6200UE 8771000
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; grey; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: 0...75°C
CPR standard: Eca
Cable external diameter: 4.47mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 910
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
4200UE.00500 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1F1A13350C0D2&compId=4200UE.pdf?ci_sign=93ffa1e89085e19ca5b257b51a6e0c270d8c1aeb
4200UE.00500
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 500m; Cu; stranded; grey; CPR: Eca; 1640ft
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: grey
Shield structure: unshielded
Wire insulation material: LSZH
Package contents: 500m
Number of cores: 2
Operating temperature: -20...70°C
CPR standard: Eca
Cable external diameter: 4.6mm
Core diameter: 16AWG
Kind of material: halogen free; no flame propagation
Package contents - ft: 1640ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
5200UE 009U1000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD80A1BD3484A880D2&compId=5200UE.pdf?ci_sign=b20ab992931c64f5724ba6fe09f96a93d6b87aba
5200UE 009U1000
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; white; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: white
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: -20...75°C
CPR standard: Eca
Cable external diameter: 4.57mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 1666
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
6200UE 0091000 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEBCE52FED95AE20D6&compId=6200UE.pdf?ci_sign=4249fa0926d5394dd6b4fcbd9cfe97bdd1bb36c9
6200UE 0091000
Виробник: BELDEN
Category: Multicore Cables - Unshielded
Description: Wire; 2x16AWG; unshielded; 300V; 305m; Cu; stranded; white; CPR: Eca
Type of wire: control cable
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu
Insulation colour: white
Shield structure: unshielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: 0...75°C
CPR standard: Eca
Cable external diameter: 4.47mm
Rated voltage: 300V
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 910
Cable application: indoor
Information: The UL Label and Mark on full factory packaging only
товару немає в наявності
В кошику  од. на суму  грн.
8719.01305 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEB3E1FDE6463620D6&compId=8719_EN.pdf?ci_sign=63433e59c42d0cc2741528c03019d08af7f29c23
8719.01305
Виробник: BELDEN
Category: Serial Bus Cables
Description: Wire; 2x16AWG; stranded; Cu; shielded,Al-PET foil; Insulation: PVC
Type of wire: data transmission
Cable structure: 2x16AWG
Core structure: stranded
Kind of core: Cu; tinned
Insulation colour: chrome
Shield structure: Al-PET foil; shielded
Wire insulation material: PVC
Package contents: 305m
Number of cores: 2
Operating temperature: -20...80°C
CPR standard: Eca
Cable external diameter: 7.95mm
Rated voltage: 0.6kV
Core diameter: 16AWG
Package contents - ft: 1000ft
Conform to the norm: UL 1685; UL 20253
Cable application: indoor
Earth core: none
Information: The UL Label and Mark on full factory packaging only
Ground: tinned copper strand 18AWG
товару немає в наявності
В кошику  од. на суму  грн.
Обрати Сторінку:   [  << Попередня Сторінка ]  1 15 30 45 60 75 90 105 120 135 136 137 138 139 140 141 142 143 144 145 146 150 151  [ Наступна Сторінка >> ]
