Виробник: IBO
Category: Industrial Armature
Description: Expansion vessel; 3/4"; IBO ITALY SOLAR; -10÷100°C; solar system
Application: solar system
Type of hydraulic accessories: expansion vessel
Operating temperature: -10...100°C
Diameter: 205mm
Height: 350mm
Pre-charge pressure: 2.5bar ±10%
Capacity: 8l
Thread: 3/4"
Manufacturer series: IBO ITALY SOLAR

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulator; NOVA MAX; 230VAC; IP44; Temp: 0÷40°C; 95%; 50Hz
Type of pump: circulator
Manufacturer series: NOVA MAX
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Medium temperature range: 2...110°C
Max. environment humidity: 95%
Insulation class: H
Conform to the norm: EN61000-6-1; EN61000-6-3
Number of operation modes: 16
Supply voltage frequency: 50Hz
Pump efficiency: 350l/min
Hydraulic connection: DN65
Power: 15...600W
Head: 12m
System pressure: max 1MPa
Installation length: 250mm
Sound Pressure: 43dBA
Energy Efficiency Index EEI: ≤0.23

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Type of hydraulic accessories: pump group
Kit contents: 3-way thermostatic valve with half-screw connection; Beta 2 25-60/180 pump; front and rear insulation; IBO Ster-D mixing valve actuator; return connector x1; shut-off valve with thermometer and half-connection: 2 pcs.
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Type of hydraulic accessories: pump group
Kit contents: 3-way thermostatic valve with half-screw connection; front and rear insulation; IBO Ster-D mixing valve actuator; Magi 2 25-60/180 pump; return connector x1; shut-off valve with thermometer and half-connection: 2 pcs.
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Type of hydraulic accessories: pump group
Kit contents: 3-way thermostatic valve with half-screw connection; Beta 2 25-60/180 pump; front and rear insulation; return connector x1; shut-off valve with thermometer and half-connection: 2 pcs.
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Type of hydraulic accessories: pump group
Kit contents: 3-way thermostatic valve with half-screw connection; front and rear insulation; Magi 2 25-60/180 pump; return connector x1; shut-off valve with thermometer and half-connection: 2 pcs.
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Type of hydraulic accessories: pump group
Kit contents: Beta 2 25-60/180 pump; front and rear insulation; return connector x1; shut-off valve with half union: 1 pc.; shut-off valve with thermometer and half-connection: 2 pcs.
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Type of hydraulic accessories: pump group
Kit contents: front and rear insulation; Magi 2 25-60/180 pump; return connector x1; shut-off valve with half union: 1 pc.; shut-off valve with thermometer and half-connection: 2 pcs.
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump group; 125mm
Kit contents: front and rear insulation; IVO 25-60/180 pump; return connector x1; shut-off valve with half union: 1 pc.; shut-off valve with thermometer and half-connection: 2 pcs.
Type of hydraulic accessories: pump group
Installation length: 125mm

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Type of pump: circulation
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...95°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 55l/min
Power: 38/53/71W
Head: 4m
System pressure: max 1MPa
Installation length: 180mm
Number of operation modes: 3
Hydraulic connection: 1 1/2 " / 1"
Manufacturer series: OHI

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Type of pump: circulation
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...95°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 57l/min
Power: 46/63/93W
Head: 5.6m
System pressure: max 1MPa
Installation length: 180mm
Number of operation modes: 3
Hydraulic connection: 1 1/2 " / 1"
Manufacturer series: OHI

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Type of pump: circulation
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...95°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 57l/min
Power: 46/63/93W
Head: 5.6m
System pressure: max 1MPa
Installation length: 130mm
Number of operation modes: 3
Hydraulic connection: 1 1/2 " / 1"
Manufacturer series: OHI

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Type of pump: circulation
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...95°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 115l/min
Power: 150/220/270W
Head: 8m
System pressure: max 1MPa
Installation length: 180mm
Number of operation modes: 3
Hydraulic connection: 1 1/2 " / 1"
Manufacturer series: OHI

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Type of pump: circulation
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...95°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 69l/min
Power: 46/63/93W
Head: 5.4m
System pressure: max 1MPa
Installation length: 180mm
Number of operation modes: 3
Hydraulic connection: 2" / 1 1/4"
Manufacturer series: OHI

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Type of pump: circulation
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...110°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 186l/min
Power: 150/220/270W
Head: 8m
System pressure: max 1MPa
Installation length: 200mm
Number of operation modes: 3
Hydraulic connection: DN40
Manufacturer series: OHI

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; OHI; 230VAC; IP44; Temp: 0÷40°C; 95%; Ins.class: F
Operating temperature: 0...40°C
IP rating: IP44
Manufacturer series: OHI
Installation length: 180mm
Medium temperature range: 2...95°C
Number of operation modes: 3
Head: 7.7m
Supply voltage frequency: 50Hz
Max. environment humidity: 95%
Pump efficiency: 142l/min
Power: 150/220/270W
Supply voltage: 230V AC
System pressure: max 1MPa
Hydraulic connection: 2" / 1 1/4"
Type of pump: circulation
Insulation class: F
Application: for the circulation of domestic hot water

Виробник: IBO
Category: Industrial Armature
Description: Controller for pump; 230VAC; 2.2kW
Supply voltage: 230V AC
Max motor power: 2.2kW
Additional functions: displaying the history of the last five failures in which the protective functions were active; display of cumulative pump operating time; dynamic LCD screen displaying the current pump operating status
Type of hydraulic accessories: controller for pump

Виробник: IBO
Category: Industrial Armature
Description: Controller for pump; 400VAC; 4kW
Supply voltage: 400V AC
Max motor power: 4kW
Additional functions: displaying the history of the last five failures in which the protective functions were active; display of cumulative pump operating time; dynamic LCD screen displaying the current pump operating status
Type of hydraulic accessories: controller for pump

Виробник: IBO
Category: Industrial Armature
Description: Controller for pump; 400VAC; 7.5kW
Supply voltage: 400V AC
Max motor power: 7.5kW
Additional functions: displaying the history of the last five failures in which the protective functions were active; display of cumulative pump operating time; dynamic LCD screen displaying the current pump operating status
Type of hydraulic accessories: controller for pump

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; IPML; 230VAC; IP44; Temp: 0÷40°C; Ins.class: B
Insulation class: B
Type of pump: circulation
IP rating: IP44
Operating temperature: 0...40°C
Medium temperature range: max 80°C
Installation length: 280mm
Head: 20m
Supply voltage frequency: 50Hz
Power: 1.1kW
Supply voltage: 230V AC
Pump efficiency: 300l/min
System pressure: max 0.6MPa
Manufacturer series: IPML

Виробник: IBO
Category: Industrial Armature
Description: 3-vay valve; 1"; max.10bar; max110°C
Operating pressure: max. 10bar
Medium temperature range: max 110°C
Thread: 1"
Type of hydraulic accessories: 3-vay valve

Виробник: IBO
Category: Industrial Armature
Description: Mixing valve actuator; IP42; central heating systems; 5W; 90°
Power consumption: 5W
Torque: max. 6Nm
Mechanical rotation angle: 90°
Operate time: 120s
Application: central heating systems
IP rating: IP42
Type of hydraulic accessories: mixing valve actuator

Виробник: IBO
Category: Industrial Armature
Description: Thermostatic mixing valve; 3/4"; 20÷43°C; domestic hot water
Type of hydraulic accessories: thermostatic mixing valve
Operating temperature: 20...43°C
Thread: 3/4"
Application: domestic hot water

Виробник: IBO
Category: Industrial Armature
Description: Thermostatic mixing valve; 3/4"; 35÷60°C; domestic hot water
Type of hydraulic accessories: thermostatic mixing valve
Operating temperature: 35...60°C
Thread: 3/4"
Application: domestic hot water

Виробник: IBO
Category: Industrial Armature
Description: 3-vay valve; 1 1/2"; max.10bar; max110°C
Operating pressure: max. 10bar
Medium temperature range: max 110°C
Thread: 1 1/2"
Type of hydraulic accessories: 3-vay valve

Виробник: IBO
Category: Industrial Armature
Description: Pump: circulation; 1/2"; 230VAC; IP44; Temp: 0÷40°C; 95%; 50Hz; 7W
Type of pump: circulation
Thread: 1/2"
Supply voltage: 230V AC
IP rating: IP44
Operating temperature: 0...40°C
Application: for the circulation of domestic hot water
Medium temperature range: 2...95°C
Max. environment humidity: 95%
Insulation class: F
Supply voltage frequency: 50Hz
Pump efficiency: 8.33l/min
Power: 7W
Head: 1.2m
System pressure: max 1MPa
Installation length: 110mm

Виробник: IBO
Category: Industrial Armature
Description: Vertical coupling; 1",3/4"; max.3bar; max95°C; Poles number: 1
Poles number: 1
Operating pressure: max. 3bar
Thread: 1"; 3/4"
Medium temperature range: max 95°C
Type of hydraulic accessories: vertical coupling

Виробник: IBO
Category: Industrial Armature
Description: Mixing valve actuator; IP42; central heating systems; 5W; 90°
Power consumption: 5W
Torque: max. 6Nm
Mechanical rotation angle: 90°
Operate time: 120s
Application: central heating systems
IP rating: IP42
Type of hydraulic accessories: mixing valve actuator
Additional functions: temperature sensor

Виробник: IBO
Category: Industrial Armature
Description: Vertical coupling; 1",3/4"; max.3bar; max95°C; Poles number: 1
Poles number: 1
Operating pressure: max. 3bar
Thread: 1"; 3/4"
Medium temperature range: max 95°C
Type of hydraulic accessories: vertical coupling

Виробник: IBO
Category: Industrial Armature
Description: Expansion vessel; 1"; 0÷45°C; Ø: 380mm; H: 550mm; 50l; 1.7bar±10%
Operating temperature: 0...45°C
Type of hydraulic accessories: expansion vessel
Height: 550mm
Diameter: 380mm
Pre-charge pressure: 1.7bar ±10%
Capacity: 50l
Thread: 1"
