Продукція > METREL > Всі товари виробника METREL (10) > Сторінка 1 з 1

Виробник: METREL
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; I AC: 1mA÷1.2kA; 0.04÷5kHz; 600mm
Type of test accessories: AC current clamp adapter
AC current measuring range: 1mA...1.2kA
Dimensions: 220x120x48mm
Measurement: AC current
Battery/ rechargeable battery: none
Probe length: 600mm
Bandwidth for AC current measurements: 0.04...5kHz
Output signal: 1mA/1A
Attenuator: 1000:1
Cable/adapter structure: banana 4mm plug x2
Conform to the norm: CAT III 600V; EN 61010

Виробник: METREL
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; I AC: 200mA÷1.2kA; 0.04÷5kHz; 600mm
Type of test accessories: AC current clamp adapter
AC current measuring range: 200mA...1.2kA
Dimensions: 220x120x48mm
Measurement: AC current
Battery/ rechargeable battery: none
Probe length: 600mm
Bandwidth for AC current measurements: 0.04...5kHz
Output signal: 1mA/1A
Attenuator: 1000:1
Cable/adapter structure: banana 4mm plug x2
Conform to the norm: CAT III 600V; EN 61010

Виробник: METREL
Category: Insulation Resistance Meters
Description: Software
Type of test accessories: software
Standard equipment: CD; connection cable x2
Related items: METR-MI3201

Виробник: METREL
Category: PV and EVSE Testers and Meters
Description: Meter: test adapter kit; Equipment: case,test cable type 2; IP40
Operating temperature: 0...40°C
Conform to the norm: CAT II 300V; EN 61010
Test current: 13A
Max. input voltage: 400V
Colour: black
Standard equipment: case; test cable type 2
Test: CP: simulating various charging states; PP cable
Measuring instruments application: for electric vehicle charging station type 3
IP rating: IP40
Measuring instrument features: measuring terminals L1, L2, L3, N and PE; separate phase indication by 3 LED
Type of meter: test adapter kit
Dimensions (W x H x D): 200x100x70mm

Виробник: METREL
Category: PV and EVSE Testers and Meters
Description: Meter: test adapter kit; Equipment: case,test cable type 2; IP40
Type of meter: test adapter kit
Standard equipment: case; test cable type 2
Conform to the norm: CAT II 300V; EN 61010
Measuring instrument features: CP test: simulating various charging states; fault simulation of Diode short, PE-CP short and PE open; measuring terminals L1, L2, L3, N and PE; output BNC connector for CP signal monitoring; PP test : adapter simulate various current capabilities of charging cables; separate phase indication by 3 LED
IP rating: IP40
Measuring instruments application: for electric vehicle charging station type 3
Colour: black
Max. input voltage: 400V
Maximum current: 13A
Dimensions (W x H x D): 200x100x70mm
Test current: 267A
Operating temperature: 0...40°C

Виробник: METREL
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); VDC: 60mV,1kV; VAC: 60mV,1kV
Standard equipment: K-type thermocouple; test leads; user's manual
Kind of display used: LCD
Temperature measuring range: -50...1000°C
Capacitance measuring range: 60nF...3000µF
AC current measuring range: 600µA; 8A
DC current measuring range: 600µA; 8A
DC voltage measuring range: 60mV; 1kV
AC voltage measuring range: 60mV; 1kV
Dimensions (W x H x D): 80x161x50mm
Weight with battery: 340g
Frequency measuring range: 5...1MHz
Resistance measuring range: 600...60MΩ
Display parameters: (6000)
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature
Continuity test: acoustic indication
Measuring instrument features: autoranging; EF function - electrical field detecion; HOLD function
Power supply: battery LR03 AAA 1,5V x2
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Conform to the norm: CAT II 1000V; CAT III 600V; CAT IV 300V; EN 61010
Type of meter: digital multimeter
Test: diodes

Виробник: METREL
Category: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,AC/DC pincers type; Øcable: 26mm
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Power supply: battery LR03 AAA 1,5V x2
Standard equipment: case; test leads ( 2pcs.); user's manual
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Measuring instrument features: function; HOLD function; kWh - measures and records energy consumption in 1- and 3-phase systems with blanced load
Type of meter: multifunction
True effective value measurement: True RMS AC
Apparent power measurement: 0...600kVA
Reactive power measurement: 0...600kVAR
Dimensions: 189x78x40mm
Power factor measurement: 0.01...0.99
Max. diameter of measured cable: 26mm
Frequency measuring accuracy: ±(0.5%+4 digit)
DC voltage measuring accuracy: ±(0.5% + 5 digit)
AC voltage measuring accuracy: ±(0.5% + 5 digit)
AC current measuring accuracy: ±(1% + 5 digit)
Resistance measuring accuracy: ±(1%+6 digit)
Frequency measuring range: 5...500Hz
AC current measuring range: 40A; 400A; 600A
AC voltage measuring range: 600V
DC voltage measuring range: 600V
Resistance measuring range: 999.9Ω
Measurement: AC current; active power; AC voltage; apparent power; DC voltage; frequency; power factor; reactive power; resistance
Kind of meter: AC/DC pincers type; digital

Виробник: METREL
Category: Electrical Safety Testers
Description: Safety analyzer; 0.15÷19.99MΩ,20÷99.9MΩ,100÷199.9MΩ; 0÷50V
Touchpad: yes
Test current: 0A; 2A; 4A; 10A; 25A
Test voltage: 0...50V
Dimensions (W x H x D): 420x325x180mm
Supply voltage: 110/230V AC
Standard equipment: 7 crocodile clips; mains cable; RS232 cable; test probe x4; USB cable; user's manual
Insulation resistance measuring ranges: 0.15...19.99MΩ; 20...99.9MΩ; 100...199.9MΩ
Measurement: active power; apparent power; continuity; current (with current clamps); frequency; insulation resistance; leakage current; phase sequence; RCD tripping current; reactive power; short circuit loop impedance; touch voltage; votlage drop
Interface: Bluetooth; RS232 x2; USB
Conform to the norm: CAT II 300V; CAT III 300V; EN 61010-1; EN 61010-2-030; EN 61010-2-032; EN 61010-031; EN 61557
Kind of display used: colour; LCD 4,3"
Type of meter: safety analyzer

Виробник: METREL
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; 0.017÷199.9MΩ,999MΩ; ±(2%+3digit)
Type of meter: appliance meter
Kind of display used: LCD
Measurement: continuity; earthing resistance; insulation resistance; leakage current; phase sequence
Insulation resistance measuring ranges: 0.017...199.9MΩ; 999MΩ
Insulation resistance measuring accuracy: ±(2% + 3digit)
Interface: RS232; USB
Test voltage: 100V; 250V; 500V; 1kV
Pollution degree: 2
IP rating: IP42
Conform to the norm: CAT III 600V; EN 61010
Power supply: rechargeable battery Ni-MH AA 1,2V x6
Body dimensions: 230x103x115mm
Weight with battery: 1.32kg
Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x6
Measurement memory: 500
Illumination: yes

Виробник: METREL
Category: Electrical Safety Testers
Description: Safety analyzer; 0÷19.99MΩ,20÷199MΩ; Touchpad: yes; 99.9mA
Type of meter: safety analyzer
Insulation resistance measuring ranges: 0...19.99MΩ; 20...199MΩ
Kind of display used: colour; LCD 4,3"
Touchpad: yes
Test current: 99.9mA
Interface: Bluetooth; RS232 x4; USB
Measurement: continuity; insulation resistance; leakage current; residual voltage
Test voltage: 0...1.2kV
Conform to the norm: CAT II 300V; CAT II 600V; EN 61010-1; EN 61010-2-030; EN 61010-031; EN 61557
Supply voltage: 110/230V AC
Dimensions (W x H x D): 435x292x155mm
Standard equipment: accessory pouch; connection cable; crocodile clip x5; test leads; USB cable
