1023250 LAPP

pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA0C1B356C6EF20D6&compId=OL896P-1023229.pdf?ci_sign=6aaa169246dab88c8cf27345d81f62974132c870

Виробник: LAPP
Category: Cables for Power Chains - Unshielded
Description: Wire: mains; ÖLFLEX® CHAIN 896 P; 4G10mm2; PUR; black; stranded; Cu
Type of wire: mains
Kind of wire: ÖLFLEX® CHAIN 896 P
Cable structure: 4G10mm²
Wire insulation material: PUR
Insulation colour: black
Core structure: stranded
Kind of core: Cu
Operating temperature: -50...90°C
Core section: 10mm²
Number of cores: 4
Cable external diameter: 17mm
Rated voltage: 600V; 1kV
Core marking: black, numbered + ground wire
Shield structure: unshielded
CPR standard: E_ca
Flexibility class: 6
Earth core: yellow-green
Resistance to: mechanical stesses; most of oils; to weather conditions; UV rays
Cable application: automatics; indoor; mechanical engineering; outdoor; power chain
Kind of material: halogen free
Conform to the norm: CSA AWM I/II A/B FT1; C(uL) AWM I/II A/B FT1; UL 20234; UL E63634; VW-1
кількість в упаковці: 1 шт

товару немає в наявності

В кошику од. на суму грн.

Відгуки про товар

Написати відгук

Технічний опис 1023250 LAPP

Category: Cables for Power Chains - Unshielded, Description: Wire: mains; ÖLFLEX® CHAIN 896 P; 4G10mm2; PUR; black; stranded; Cu, Type of wire: mains, Kind of wire: ÖLFLEX® CHAIN 896 P, Cable structure: 4G10mm2, Wire insulation material: PUR, Insulation colour: black, Core structure: stranded, Kind of core: Cu, Operating temperature: -50...90°C, Core section: 10mm2, Number of cores: 4, Cable external diameter: 17mm, Rated voltage: 600V; 1kV, Core marking: black, numbered + ground wire, Shield structure: unshielded, CPR standard: Eca, Flexibility class: 6, Earth core: yellow-green, Resistance to: mechanical stesses; most of oils; to weather conditions; UV rays, Cable application: automatics; indoor; mechanical engineering; outdoor; power chain, Kind of material: halogen free, Conform to the norm: CSA AWM I/II A/B FT1; C(uL) AWM I/II A/B FT1; UL 20234; UL E63634; VW-1, кількість в упаковці: 1 шт.
