EX820A EXTECH

Category: Meters and AC Clamp Probes, Description: Meter: multifunction; digital,pincers type; LCD; (6000); True RMS, Type of meter: multifunction, Temperature measuring range: -20...760°C, Power supply: battery 6F22 9V x1, Measuring instrument features: automatic power-off; HOLD function; laser sight; low battery indicator; MIN/MAX function; PEAK HOLD function, Kind of display used: LCD, Measurement: AC current; AC voltage; capacitance; DC voltage; frequency; non-contact temeprature (IR); resistance; temperature, Dimensions: 270x110x50mm, Illumination: yes, True effective value measurement: True RMS, Non-contact temperature measuring range: -50...270°C, AC voltage measuring range: 0.1mV...1kV, DC voltage measuring range: 0.1mV...1kV, Capacitance measuring range: 1pF...40mF, Diode test: 1.5mA, Frequency measuring range: 1mHz...100kHz, Max. diameter of measured cable: 43mm, AC current measuring range: 100mA...1kA, Frequency measuring accuracy: ±(1.5%+2 digit), Resistance measuring range: 100mΩ...60Ω, AC current measuring accuracy: ±(2.5% + 8 digit)@600A; ±(2.8% + 5 digit)@1kA, AC voltage measuring accuracy: ±(1% + 10 digit) @600mV; ±(1.5% + 5 digit); ±(2% + 5 digit) @1kV, DC voltage measuring accuracy: ±(0.8% + 2 digit) @600mV; ±(1.5% + 2 digit); ±(2% + 2 digit) @1kV, Resistance measuring accuracy: ±(1%+4 digit)@(600Ω); ±(1.5%+2 digit); ±(2.5%+3 digit)@(6MΩ); ±(3.5%+5 digit)@(60MΩ), Non-contact temperature measuring accuracy: ±2% @ -20°C...270°C; ±2°C @ -20°C...270°C; ±5°C @ -50°C...-20°C, Capacitance measuring accuracy: ±(3%+ 5 digit); ±(4%+10 digit) @ 600µF; ±(4%+10 digit) @ 6mF; ±(5%+20 digit) @ 60nF; ±(5%+30 digit) @ 6nF; ±(10%+10 digit) @ 40mF, Optical resolution: 8:1, Display parameters: (6000), Continuity test: .
