GKS-112 207 130 A 1503

GKS-112 207 130 A 1503 INGUN

pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A09E451507C0D6&compId=GKS-112-2792.pdf?ci_sign=343cf9fcee78924e51d40ed432aceb204ae0ccb6 Виробник: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 5A; steel; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 5A
Contact material: steel
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: 3 point; sharp
Manufacturer series: GKS-112
Max. contact resistance:: 20mΩ
Operating temperature: -40...80°C
Mounting: push-in
Test accessories features: magnetic; self-cleaning
Length: 32.3mm
Spring compression force: 1.5N
