GKS-112 306 150 R 0805 M

GKS-112 306 150 R 0805 M INGUN

pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A09DED0C5920D6&compId=GKS-112-2714.pdf?ci_sign=46d29e8fe2bc1a190c00f4a3b6d02af296e3b707 Виробник: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 5A; CuBe; Ø: 1.5mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 5A
Contact material: CuBe
Contact plating: rhodium plated
Tip diameter: 1.5mm
Blade tip shape: serrated
Manufacturer series: GKS-112
Max. contact resistance:: 20mΩ
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: magnetic
Length: 38.8mm
Spring compression force: 0.8N
товару немає в наявності
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис GKS-112 306 150 R 0805 M INGUN

Category: Contact Probes, Description: Test needle; Spring compression: 4mm; 5.3mm; 5A; CuBe; Ø: 1.5mm, Type of test accessories: test needle, Operational spring compression: 4mm, Maksimum spring compression: 5.3mm, Current rating: 5A, Contact material: CuBe, Contact plating: rhodium plated, Tip diameter: 1.5mm, Blade tip shape: serrated, Manufacturer series: GKS-112, Max. contact resistance:: 20mΩ, Operating temperature: -40...80°C, Mounting: screw-in, Test accessories features: magnetic, Length: 38.8mm, Spring compression force: 0.8N.
