Продукція > INGUN > GKS-112 306 150 R 5005 M
GKS-112 306 150 R 5005 M

GKS-112 306 150 R 5005 M INGUN

GKS-112-2200.pdf
Виробник: INGUN
Category: Test Probes
Description: Test acces: test needle; -40÷80°C; 8A; Ø: 1.5mm; Contacts: CuBe; 5N
Mounting: screw-in
Operating temperature: -40...80°C
Contact material: CuBe
Manufacturer series: GKS-112
Current rating: 8A
Operational spring compression: 4mm
Length: 38.8mm
Test accessories features: magnetic
Tip diameter: 1.5mm
Max. contact resistance:: 20mΩ
Blade tip shape: serrated
Spring compression force: 5N
Type of test accessories: test needle
Contact plating: rhodium plated
Maksimum spring compression: 5.3mm
товару немає в наявності
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис GKS-112 306 150 R 5005 M INGUN

Category: Test Probes, Description: Test acces: test needle; -40÷80°C; 8A; Ø: 1.5mm; Contacts: CuBe; 5N, Mounting: screw-in, Operating temperature: -40...80°C, Contact material: CuBe, Manufacturer series: GKS-112, Current rating: 8A, Operational spring compression: 4mm, Length: 38.8mm, Test accessories features: magnetic, Tip diameter: 1.5mm, Max. contact resistance:: 20mΩ, Blade tip shape: serrated, Spring compression force: 5N, Type of test accessories: test needle, Contact plating: rhodium plated, Maksimum spring compression: 5.3mm.
