HFS-810 303 150 A 9942 FS1M INGUN
Виробник: INGUNCategory: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 1.5mm
Manufacturer series: HFS-810
Contact material: CuBe
Blade tip shape: cone; head 42; inverted
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Operational spring compression: 2mm
Length: 43.2mm
Maksimum spring compression: 3.7mm
Flange diameter: 5.8mm
Spring compression force: 10N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 2GHz
кількість в упаковці: 1 шт
товару немає в наявності
Відгуки про товар
Написати відгук
Технічний опис HFS-810 303 150 A 9942 FS1M INGUN
Category: Contact Probes, Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 1.5mm, Manufacturer series: HFS-810, Contact material: CuBe, Blade tip shape: cone; head 42; inverted, Contact plating: gold-plated, Test accessories features: outer conductor maximum current: 10A, Mounting: screw-in, Type of test accessories: test needle, Operating temperature: -40...80°C, Tip diameter: 1.5mm, Operational spring compression: 2mm, Length: 43.2mm, Maksimum spring compression: 3.7mm, Flange diameter: 5.8mm, Spring compression force: 10N, Current rating: 3A, Impedance: 50Ω, Dielectric strength: 1.1kV, Max. frequency: 2GHz, кількість в упаковці: 1 шт.
