HFS-810 358 080 A 6802 V2-00S INGUN
Виробник: INGUNCategory: Contact Probes
Description: Test needle; 3A; Contact plating: gold-plated; Contacts: CuBe
Operating temperature: -40...80°C
Length: 44mm
Contact material: CuBe
Dielectric strength: 1.1kV
Blade tip shape: cone
Type of test accessories: test needle
Tip diameter: 0.8mm
Test accessories features: outer conductor maximum current: 2A; self-cleaning
Manufacturer series: HFS-810
Spring compression force: 6.8N
Mounting: push-in
Contact plating: gold-plated
Max. frequency: 2GHz
Current rating: 3A
Impedance: 50Ω
кількість в упаковці: 1 шт
товару немає в наявності
Відгуки про товар
Написати відгук
Технічний опис HFS-810 358 080 A 6802 V2-00S INGUN
Category: Contact Probes, Description: Test needle; 3A; Contact plating: gold-plated; Contacts: CuBe, Operating temperature: -40...80°C, Length: 44mm, Contact material: CuBe, Dielectric strength: 1.1kV, Blade tip shape: cone, Type of test accessories: test needle, Tip diameter: 0.8mm, Test accessories features: outer conductor maximum current: 2A; self-cleaning, Manufacturer series: HFS-810, Spring compression force: 6.8N, Mounting: push-in, Contact plating: gold-plated, Max. frequency: 2GHz, Current rating: 3A, Impedance: 50Ω, кількість в упаковці: 1 шт.
