HFS-856 305 030 A 5543MM8030 H

HFS-856 305 030 A 5543MM8030 H INGUN

pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDE48AA60D6&compId=HFS-856-0022.pdf?ci_sign=f243b222f0344f1568e79f00dd296d39c38c5144 Виробник: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 0.8mm; 2A; Ø: 0.3mm
Blade tip shape: head 43; rounded
Manufacturer series: HFS-856
Test accessories features: outer conductor maximum current: 3A
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.3mm
Operational spring compression: 0.8mm
Maksimum spring compression: 2mm
Length: 36.2mm
Current rating: 2A
Spring compression force: 5.5N
Impedance: 50Ω
Contact material: CuBe
Max. frequency: 6GHz
Contact plating: gold-plated
товару немає в наявності
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис HFS-856 305 030 A 5543MM8030 H INGUN

Category: Contact Probes, Description: Test needle; Operational spring compression: 0.8mm; 2A; Ø: 0.3mm, Blade tip shape: head 43; rounded, Manufacturer series: HFS-856, Test accessories features: outer conductor maximum current: 3A, Mounting: screw-in, Type of test accessories: test needle, Operating temperature: -40...80°C, Tip diameter: 0.3mm, Operational spring compression: 0.8mm, Maksimum spring compression: 2mm, Length: 36.2mm, Current rating: 2A, Spring compression force: 5.5N, Impedance: 50Ω, Contact material: CuBe, Max. frequency: 6GHz, Contact plating: gold-plated.
