HT3013 HT INSTRUMENTS
Виробник: HT INSTRUMENTSCategory: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; pincers type; Øcable: 30mm; LCD; True RMS
Temperature measuring range: -20...760°C
Temperature measurement accuracy: ±(3% + 5°C)
IP rating: IP20
Kind of display used: LCD
Type of meter: multifunction
Kind of meter: pincers type
True effective value measurement: True RMS
Bargraph: yes
Illumination: yes
Operating temperature: 5...40°C
Capacitance measuring range: 40nF; 400nF; 4µF; 40µF; 400µF; 4mF
Max. diameter of measured cable: 30mm
Dimensions: 197x70x40mm
DC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
AC voltage measuring range: 400mV; 4V; 40V; 400V; 600V
DC voltage measuring accuracy: ±(0.8% + 2 digit)
AC voltage measuring accuracy: ±(1% + 10 digit)
Resistance measuring accuracy: ±(1%+5 digit)
Frequency measuring accuracy: ±(1.5%+2 digit)
Pollution degree: 2
AC current measuring range: 40A; 400A
AC current measuring accuracy: ±(2.5% + 8 digit)
DC current measuring accuracy: ±(2.5% + 5 digit)
Capacitance measuring accuracy: ±(3%+ 5 digit)
Frequency measuring range: 10Hz...100kHz
Continuity test: <50Ω
DC current measuring range: 40A; 400A
Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature
Standard equipment: adapter for connecting K-type probe to the meter; carrying case; K-type temperature probe; test leads ( 2pcs.); user's manual
Measuring instrument features: automatic power-off; autoranging; HOLD function; low battery indicator; PEAK function; REL function
Battery/ rechargeable battery: battery 6F22 9V x1
Power supply: battery 6F22 9V x1
Conform to the norm: CAT III 600V; EN 61010-1
Test: diodes
