KEW3128 KYORITSU

Category: Insulation Resistance Meters, Description: Meter: insulation resistance; LCD; VAC: 30÷600V; VDC: 30÷600V; IP64, Type of meter: insulation resistance, Kind of display used: LCD, Capacitance measuring range: 5nF...50µF, DC voltage measuring range: 30...600V, AC voltage measuring range: 30...600V, DC voltage measuring accuracy: ±(2% + 3 digit), AC voltage measuring accuracy: ±(2% + 3 digit), Power supply: rechargeable battery Ni-MH x1, Standard equipment: mains cable; test leads ( 4pcs.); test probe; USB cable, Measurement: AC current; AC voltage; capacitance; insulation resistance, Interface: USB, Weight without batteries: 9kg, Body dimensions: 330x410x180mm, Measuring instrument features: automatic power-off; diagnostic insulation tests: IR, PI, DAR, DD, SV, RAMP, Software: included, Illumination: yes, Insulation resistance measuring accuracy: ±(5% + 3 digits), Bargraph: yes, Test voltage: 500V; 1kV; 2.5kV; 5kV; 10kV; 12kV, Conform to the norm: CAT IV 600V; EN 61010, Leakage current: 5nA...2.4mA, Supply voltage: 100...240V AC, Insulation resistance measuring ranges: 500GΩ; 1TΩ; 2.5TΩ; 5TΩ; 35TΩ, IP rating: IP64, Pollution degree: 2, кількість в упаковці: 1 шт.
