KPS-PA440

Category: Meters and AC/DC Clamp Probes, Description: Meter: multifunction; digital,AC/DC pincers type; Øcable: 12mm, Type of meter: multifunction, Kind of meter: AC/DC pincers type; digital, Max. diameter of measured cable: 12mm, Kind of display used: LCD, Display parameters: (6000), DC current measuring range: 600µA; 1mA, AC current measuring range: 200A, Measuring instrument features: automatic power-off; contactless voltage detector; low battery indicator; work light, DC current measuring accuracy: ±(1% + 4 digit), AC current measuring accuracy: ±(3% + 3 digit), DC voltage measuring range: 600mV; 6V; 60V; 600V, DC voltage measuring accuracy: ±(0.7% + 3 digit), AC voltage measuring range: 6V; 60V; 600V, AC voltage measuring accuracy: ±(0.8% + 3 digit), Resistance measuring accuracy: ±(0.8%+3 digit); ±(1.2%+3 digit)@(6MΩ); ±(1.2%+3 digit)@(60MΩ), Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ, Capacitance measuring range: 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF, Capacitance measuring accuracy: ±(4%+ 5 digit), Frequency measuring range: 60Hz; 600Hz; 6kHz; 60kHz; 600kHz; 6MHz; 60MHz, Frequency measuring accuracy: ±(0.3%+3 digit), Temperature measuring range: -20...0°C; 0...400°C, Temperature measurement accuracy: ±(2% + 2 digit) @(0°C...400°C); ±(3% + 2 digit), Diode test: 3.2V, Test: circuit continuity; diodes, Dimensions: 201x65x43mm, Power supply: battery 6F22 9V x1, Measurement: AC current; AC voltage; capacitance; DC voltage; frequency; resistance; temperature, Conform to the norm: CAT III 600V; EN 61010, Illumination: yes.
