M80-5T10642ME Harwin Inc.

Description: DATAMATE J-TEK DIL MALE VERTICAL, Features: Keying Slot, Mating Flange, Mounting Flange, Mounting Hardware, Packaging: Tube, Connector Type: Header, Voltage Rating: 800VAC/DC, Current Rating (Amps): 2.2A, Mounting Type: Through Hole, Number of Positions: 6, Number of Rows: 2, Style: Board to Board or Cable, Operating Temperature: -55°C ~ 121°C, Contact Type: Male Pin, Fastening Type: Threaded, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.079" (2.00mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 29.5µin (0.75µm), Contact Finish - Post: Tin, Part Status: Active, Contact Shape: Circular, Contact Length - Post: 0.130" (3.30mm), Insulation Height: 0.220" (5.60mm), Shrouding: Shrouded - 4 Wall, Insulation Material: Polyphenylene Sulfide (PPS), Glass Filled, Row Spacing - Mating: 0.079" (2.00mm).
