Продукція > INGUN > T-097 305 060 180 100A1102MO-G
T-097 305 060 180 100A1102MO-G

T-097 305 060 180 100A1102MO-G INGUN

pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0D4EF012000D6&compId=T-097-0001.pdf?ci_sign=5070ebf8066d41e05c3b83d379f47438c2af8777 Виробник: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5mm; 3A; CuBe; gold-plated
Contact plating: gold-plated
Mounting: screw-in
Test accessories features: magnetic
Blade tip shape: rounded
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.6mm
Operational spring compression: 4mm
Maksimum spring compression: 5mm
Max. contact resistance:: 50mΩ
Length: 29.7mm
Spring compression force: 1.1N
Current rating: 3A
Manufacturer series: T-097
Contact material: CuBe
товару немає в наявності
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис T-097 305 060 180 100A1102MO-G INGUN

Category: Contact Probes, Description: Test needle; Spring compression: 4mm; 5mm; 3A; CuBe; gold-plated, Contact plating: gold-plated, Mounting: screw-in, Test accessories features: magnetic, Blade tip shape: rounded, Type of test accessories: test needle, Operating temperature: -40...80°C, Tip diameter: 0.6mm, Operational spring compression: 4mm, Maksimum spring compression: 5mm, Max. contact resistance:: 50mΩ, Length: 29.7mm, Spring compression force: 1.1N, Current rating: 3A, Manufacturer series: T-097, Contact material: CuBe.
