Продукція > AMPHENOL ANYTEK > TJ2051560000G

TJ2051560000G AMPHENOL ANYTEK

Name: TJ2051560000G
Brand: AMPHENOL ANYTEK
SKU: 460270229-1
Price: 644948.7 UAH
Availability: BackOrder

pVersion=0046&contRep=ZT&docId=005056AB281E1EDFABC8949529C0C0D6&compId=TJ5.086.pdf?ci_sign=e220bc48a99a01c320845ef57e10247f57a01d0c

pVersion=0046&contRep=ZT&docId=005056AB281E1EDFB7AADCBA3BDF60DC&compId=TJ.pdf?ci_sign=9c656a9a94504bc7ffecf97a703e9135dad63f93

Виробник: AMPHENOL ANYTEK
Category: Pluggable terminal blocks
Description: Connector: pluggable terminal block; plug; female; 12A; 300V; 1x20
Type of connector: pluggable terminal block
Connector: plug
Kind of connector: female
Current rating: 12A
Rated voltage: 300V
Number of pins: 20
Spatial orientation: straight
Mechanical mounting: for cable
Electrical mounting: screw terminal
Contact plating: tinned
Colour: green
Flammability rating: UL94V-0
Body material: thermoplastic
Wire size: 24AWG...12AWG
Connector pinout layout: 1x20
Wire cross-section: 2.5mm²
Contacts pitch: 5.08mm
Locking system: friction lock
Operating temperature: -40...115°C
кількість в упаковці: 1 шт

товару немає в наявності

В кошику од. на суму грн.

Відгуки про товар

Написати відгук

Технічний опис TJ2051560000G AMPHENOL ANYTEK

Category: Pluggable terminal blocks, Description: Connector: pluggable terminal block; plug; female; 12A; 300V; 1x20, Type of connector: pluggable terminal block, Connector: plug, Kind of connector: female, Current rating: 12A, Rated voltage: 300V, Number of pins: 20, Spatial orientation: straight, Mechanical mounting: for cable, Electrical mounting: screw terminal, Contact plating: tinned, Colour: green, Flammability rating: UL94V-0, Body material: thermoplastic, Wire size: 24AWG...12AWG, Connector pinout layout: 1x20, Wire cross-section: 2.5mm2, Contacts pitch: 5.08mm, Locking system: friction lock, Operating temperature: -40...115°C, кількість в упаковці: 1 шт.

Інші пропозиції TJ2051560000G

Назва	Виробник	Інформація	Доступність	Ціна
TJ2051560000G	Виробник : Amphenol Anytek	Description: TERM BLOCK PLUG 20POS STR 5.08MM Features: Retention Latches (Non-Wire Side) Packaging: Bulk Color: Green Mounting Type: Free Hanging (In-Line) Number of Positions: 20 Pitch: 0.200" (5.08mm) Type: Plug, Female Sockets Operating Temperature: -40°C ~ 115°C Termination Style: Screw - Rising Cage Clamp Number of Levels: 1 Wire Gauge or Range - AWG: 12-24 AWG Wire Gauge or Range - mm²: 1-2.5mm² Positions Per Level: 20 Plug Wire Entry: 180° Contact Mating Finish: Tin Current - UL: 12 A Voltage - UL: 300 V	товару немає в наявності	В кошику од. на суму грн.
TJ2051560000G	Виробник : Amphenol Anytek	Pluggable Terminal Blocks TB PLU PLU UP/SIDE	товару немає в наявності	В кошику од. на суму грн.
TJ2051560000G	Виробник : AMPHENOL ANYTEK	Category: Pluggable terminal blocks Description: Connector: pluggable terminal block; plug; female; 12A; 300V; 1x20 Type of connector: pluggable terminal block Connector: plug Kind of connector: female Current rating: 12A Rated voltage: 300V Number of pins: 20 Spatial orientation: straight Mechanical mounting: for cable Electrical mounting: screw terminal Contact plating: tinned Colour: green Flammability rating: UL94V-0 Body material: thermoplastic Wire size: 24AWG...12AWG Connector pinout layout: 1x20 Wire cross-section: 2.5mm² Contacts pitch: 5.08mm Locking system: friction lock Operating temperature: -40...115°C	товару немає в наявності	В кошику од. на суму грн.
