Виробник: SONEL
Category: Luxmeters
Description: Light meter; 0,01÷19,99klx; USB; 0÷50°C; 170x80x40mm; ±5%
Type of meter: light meter
Kind of display used: LCD
Display parameters: 3,75 digit
Measuring range: 0,01...19,99klx
Kind of measured light: fluorescent; high-pressure sodium lamps (HPS); LED; standard
Dimensions: 170x80x40mm
Standard equipment: calibration certificate; hard case; USB cable
Measuring instrument features: HOLD function; MIN/MAX function; PEAK HOLD function
Illumination measuring accuracy: ±5%
Measurement memory: 99
Battery/ rechargeable battery: battery 6LF22 9V x1
Software: included
Interface: USB
Bargraph: yes
Illumination: yes
Operating temperature: 0...50°C

Виробник: SONEL
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD 5,6"; VAC: 0÷750V; VDC: 0÷750V
Type of meter: insulation resistance
Kind of display used: LCD 5,6"
Measurement: AC voltage; capacitance; DC voltage; insulation resistance; stepped increasing voltage (SV); temperature
Insulation resistance measuring accuracy: ±(3% + 10digit)
AC voltage measuring range: 0...750V
DC voltage measuring range: 0...750V
Capacitance measuring range: 0...999nF; 1...49.99µF
Capacitance measuring accuracy: ±(5%+ 5 digit)
Interface: Bluetooth; USB
Test voltage: 50V DC; 100V DC; 250V DC; 500V DC; 1kV DC; 2.5kV DC; 5kV DC; 10kV DC
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Measuring instrument features: automatic compensation of purious voltages; automatic power-off; autoranging; low battery indicator
Standard equipment: calibration certificate; soft case; test leads ( 3pcs.); USB cable
Power supply: rechargeable battery Li-Ion 14,8V x1
IP rating: IP67
Body dimensions: 390x308x172mm
Insulation resistance measuring ranges: 0...999kΩ; 9.99MΩ; 99.9MΩ; 999MΩ; 9.99GΩ; 99.9GΩ; 999GΩ; 9.99TΩ; 40TΩ
Battery/ rechargeable battery: rechargeable battery Li-Ion 14,8V x1
Illumination: yes
Weight with battery: 5.6kg

Виробник: SONEL
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; 0÷999nF,1÷49.99uF; IP67
Standard equipment: calibration certificate; soft case; test leads ( 3pcs.); USB cable
Conform to the norm: CAT IV 1000V; EN 61010
Type of meter: insulation resistance
IP rating: IP67
Kind of display used: LCD
Illumination: yes
Capacitance measuring range: 0...999nF; 1...49.99µF
Insulation resistance measuring ranges: 0...999kΩ; 9.99MΩ; 99.9MΩ; 999MΩ; 9.99GΩ; 99.9GΩ; 999GΩ; 9.99TΩ; 40TΩ
Body dimensions: 390x308x172mm
Insulation resistance measuring accuracy: ±(3% + 10digit)
Capacitance measuring accuracy: ±(5%+ 5 digit)
Test voltage: 50V DC; 100V DC; 250V DC; 500V DC; 1kV DC; 2.5kV DC; 5kV DC; 10kV DC; 15kV DC
Weight with battery: 6.3kg
Measurement: AC voltage; capacitance; DC voltage; insulation resistance; resistance; stepped increasing voltage (SV)
Measuring instrument features: automatic compensation of purious voltages; automatic power-off; autoranging; low battery indicator
Power supply: rechargeable battery Li-Ion 14,8V x1
Battery/ rechargeable battery: rechargeable battery Li-Ion 14,8V x1
Interface: Bluetooth; USB

Виробник: SONEL
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; R range: 199.9Ω,1999MΩ; IP67
Interface: Bluetooth
Type of meter: insulation resistance
IP rating: IP67
Kind of display used: LCD
Illumination: yes
Capacitance measuring range: 1...999nF; 1...9.99µF
Body dimensions: 200x100x60mm
Resistance measuring accuracy: ±(0.3%+3 digit)
DC voltage measuring accuracy: ±(2% + 2 digit)
AC voltage measuring accuracy: ±(2% + 2 digit)
Insulation resistance measuring accuracy: ±(3% + 8digit)
Capacitance measuring accuracy: ±(5%+ 10 digit)
Test voltage: 50V; 100V; 250V; 500V; 1kV
Resistance measuring range: 199.9Ω; 1999MΩ
DC voltage measuring range: 299.9V; 600V
AC voltage measuring range: 299.9V; 600V
Weight with battery: 600g
Standard equipment: 2 crocodile clips; 2 pointed electrodes; calibration certificate; soft case; test leads
Insulation resistance measuring ranges: 0.1MΩ...999.9kΩ; 9.999MΩ; 99.99MΩ; 999.9MΩ; 2GΩ; 5GΩ; 9.999GΩ
Measurement: AC voltage; capacitance; DC voltage; insulation resistance; resistance
Measuring instrument features: automatic power-off; autoranging; low battery indicator
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Power supply: battery LR6 AA 1,5V x4
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010

Виробник: SONEL
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; 0÷999nF,1÷49.99uF; IP67
Type of meter: insulation resistance
Kind of display used: LCD
Measurement: AC voltage; capacitance; DC voltage; insulation resistance; resistance
Insulation resistance measuring accuracy: ±(3% + 10digit)
Capacitance measuring range: 0...999nF; 1...49.99µF
Capacitance measuring accuracy: ±(5%+ 5 digit)
Interface: Bluetooth; USB
Test voltage: 250V DC; 500V DC; 1kV DC; 2.5kV DC; 5kV DC
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Measuring instrument features: automatic power-off; autoranging; low battery indicator
Standard equipment: 2 crocodile clips; 3 pointed electrodes; calibration certificate; soft case; test leads ( 3pcs.); USB cable
Power supply: rechargeable battery Li-Ion 14,8V x1
IP rating: IP67
Body dimensions: 390x308x172mm
Insulation resistance measuring ranges: 0...999kΩ; 9.99MΩ; 99.9MΩ; 999MΩ; 9.99GΩ; 99.9GΩ; 999GΩ; 9.99TΩ; 15TΩ
Battery/ rechargeable battery: rechargeable battery Li-Ion 14,8V x1
Illumination: yes
Weight with battery: 5.6kg

Виробник: SONEL
Category: Miliohmmeters
Description: Milli-ohm meter; LCD 5"; 800x480; ±(0.25%+2digit); IP67
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Interface: LAN; USB; WiFi
IP rating: IP67
Kind of display used: LCD 5"
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,2V x1
Power supply: rechargeable battery Li-Ion 7,2V x1
Touchpad: yes
Resistance measuring range: 0...999.9µΩ; 1...1.9999mΩ; 2...19.999mΩ; 20...199.99mΩ; 200...999.9mΩ; 1...1.9999Ω; 2...19.999Ω; 20...199.99Ω; 200...1999.9Ω
Test current: 1mA @ 200Ω...1999Ω; 10mA @ 20Ω...199.9Ω; 0.1A @ 0.2Ω...1.999Ω; 100mA @ 2Ω...19.99Ω; 1A @ 20mΩ...199.9mΩ; 10A @ 0Ω...19.9mΩ
Resistance measuring accuracy: ±(0.25%+2 digit)
Dimensions: 318x257x152mm
Standard equipment: 2 crocodile clips; calibration certificate; mains cable; soft case; temperature probe; test leads ( 4pcs.); USB cable
Display resolution: 800x480
Measurement: resistance
Measuring instrument features: auto and manual ranging; automatic detection of interfering voltage; automatic power-off; automatic temperature compensation
Type of meter: milli-ohm meter

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: appliance meter; LCD; VAC: 0÷500V; Interface: Bluetooth
Type of meter: appliance meter
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Interface: Bluetooth
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Kind of display used: LCD
Connectors for the country: Europe
Measuring instrument features: illuminated buttons
IP rating: IP67
Related items: WAADAAGT16C; WAADAAGT16P; WAADAAGT16T; WAADAAGT32C; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADATWR1J; WAADAWS03; WAADAWS04; WAFUTM6; WAKROBU20K02; WAKRORE20K02; WAKROYE20K02; WAPOZSZE4; WAPOZUCH1; WAPRZ1X2BUBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WAPRZ010REBB; WAPRZ015BUBBN; WAPRZ020REBB; WAPRZ030REBBSZ; WAPRZ005REBB; WASONBUOGB1; WASONG25; WASONREOGB1; WASONSP2M; WASONYEOGB1
Illumination: yes
AC voltage measuring range: 0...500V
Body dimensions: 220x102x60mm
Test voltage: 100V; 250V; 500V
Measurement memory: 10k
Insulation resistance measuring ranges: 0.1...99.9MΩ; 0.25...199.9MΩ; 500kΩ...599.9MΩ
Standard equipment: 2 crocodile clips; 3 pointed electrodes; adapter; calibration certificate; neckstrap; probe; soft case; test leads
Measurement: earthing resistance; insulation resistance; protective conductor resistance; RCD tripping current; RCD tripping time; short circuit loop impedance

Виробник: SONEL
Category: RCD Testers and Meters
Description: RCD; LCD; 10mA,15mA,30mA,100mA,300mA,500mA; VAC: 0÷500V; IP67
Standard equipment: crocodile clip x1; neckstrap; pointed electrode; soft case; test leads ( 3pcs.); WS-05 test adapter
Measurement: RCD tripping current; RCD tripping time
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x4
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Type of meter: RCD
IP rating: IP67
Illumination: yes
AC voltage measuring range: 0...500V
Test current: 10mA; 15mA; 30mA; 100mA; 300mA; 500mA
Dimensions: 220x98x58mm
Measurement memory: 990
Measuring instrument features: wireless communication with PC
RCD test: AC, A, B-type RCDs

Виробник: SONEL
Category: Earth Resistance Meter
Description: Meter: grounding resistance; LCD; 200mA; 0÷19.99kΩ; IP54; 25V,50V
Interface: Bluetooth; USB
Measurement: AC earthing resistance by means of 2-pole method; earthing resistance; ground resistivity; resistance (3-wire); resistance (4-wire)
Measuring instrument features: low battery indicator; measured values are save together with GPS coordinates
Battery/ rechargeable battery: rechargeable battery Ni-MH 4,8V 4200mAh x1
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Type of meter: grounding resistance
IP rating: IP54
Kind of display used: LCD
Power supply: rechargeable battery Ni-MH 4,8V 4,2Ah x1
Illumination: yes
Earthing resistance measuring range: 0...19.99kΩ
Test current: 200mA
Body dimensions: 228x223x75mm
Earthing resistance measuring accuracy: ±(2% + 2 digit)
Test voltage: 25V; 50V
Measurement memory: 990
Standard equipment: 2 crocodile clips; 25m long test lead (blue); 25m long test lead (red); 50m long test lead (yellow); a earth spike x4; cable for supplying from car lighter socket; calibration certificate; mains cable; neckstrap; soft case; test leads ( 2pcs.); USB cable

Виробник: SONEL
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; 3,5 digit (1999); VAC: 6÷1000V; 16÷400Hz
Type of tester: electrical
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Bandwidth for AC voltage measurements: 16...400Hz
Measuring instrument features: automatic power-off; built-in torch; indicates phase sequence; polarity identification; polarization indicator
Power supply: battery LR03 AAA 1,5V x2
Body dimensions: 275x82x36mm
Kind of display used: LCD
Continuity test: acoustic indication; optical indication; <400kΩ
DC voltage measuring range: 6...1000V
Weight without batteries: 267g
AC voltage measuring range: 6...1000V
RCD test: general purpose
Resistance measuring range: 1...1999Ω
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Illumination: yes
IP rating: IP65
Measurement: AC voltage; DC voltage; resistance
Display parameters: 3,5 digit (1999)

Виробник: SONEL
Category: Multimeters for Electrical Installations
Description: Meter: safety analyzer; LCD; RCD test: general purpose; USB,WiFi
Measuring instrument features: automatic or manual selection of measuring ranges; portable
Standard equipment: calibration certificate; mains cable; soft case; test lead; USB cable
Conform to the norm: DIN VDE 0701-0702; EN 60335-1; EN 60950
Software: included
RCD test: general purpose
Measurement: insulation resistance; leakage current; protective conductor resistance
IP rating: IP40
Kind of display used: LCD
Type of meter: safety analyzer
Plug variant: Uni-Schuko
Interface: USB; WiFi
Leakage current: 0.1...19.9mA
Ground cord resistance: 10mΩ...19.99Ω
Dimensions (W x H x D): 200x180x77mm
Supply voltage: 220/240V AC
Test: 1-phase DUTs
Insulation resistance measuring ranges: 0.25...99.99MΩ

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD,LCD 7"; Network: three-phase
IP rating: IP65
Interface: USB
Conform to the norm: CAT IV 300V; EN 61010
Kind of display used: LCD; LCD 7"
Type of meter: power quality analyser
Software: included
Kind of network: three-phase
Operating temperature: -20...55°C
Number of inputs: 4
Measurement memory: 1100
Measuring instrument features: 4 current inputs; built in 2GB microSD memory card
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; power factor; reactive electric energy; reactive power; THD
Standard equipment: case; crocodile clip x5; mains power supply adapter 100-240V AC; USB cable
Battery/ rechargeable battery: rechargeable battery Li-Ion 4,6V 6900mAh x1

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD 7"; Network: three-phase; IN: 5
IP rating: IP51
Interface: USB
Conform to the norm: CAT IV 600V; EN 61010
Kind of display used: LCD 7"
Type of meter: power quality analyser
Software: included
Kind of network: three-phase
Touchpad: yes
Number of inputs: 5
Display resolution: 800x480
Measuring instrument features: 4 current inputs
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; power factor; reactive electric energy; reactive power; THD; voltage and current unbalance
Standard equipment: cable for supplying from car lighter socket; calibration certificate; crocodile clip x5; current clamp F3Ax 4; mains cable; neckstrap; power supply AC 230V; soft case; test leads ( 5pcs.); USB cable
Battery/ rechargeable battery: rechargeable battery Li-Ion 11,1V 3400mAh x1

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD 7"; Network: three-phase; IN: 5
IP rating: IP51
Interface: USB
Conform to the norm: CAT IV 600V; EN 61010
Kind of display used: LCD 7"
Type of meter: power quality analyser
Software: included
Kind of network: three-phase
Touchpad: yes
Number of inputs: 5
Display resolution: 800x480
Measuring instrument features: 4 current inputs
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; power factor; reactive electric energy; reactive power; THD; voltage and current unbalance
Standard equipment: cable for supplying from car lighter socket; calibration certificate; crocodile clip x5; mains cable; neckstrap; power supply AC 230V; soft case; test leads ( 5pcs.); USB cable
Battery/ rechargeable battery: rechargeable battery Li-Ion 11,1V 3400mAh x1

Виробник: SONEL
Category: LAN and Telephone Networks Testers
Description: Meter: reflectometer; LCD; Detection: place of cable failure
Type of meter: reflectometer
Kind of display used: LCD
Detection: place of cable failure
Measuring resolution: 1%
Measuring range: 4km
Input impedance: 25Ω; 50Ω; 75Ω; 100Ω
Power supply: battery LR6 AA 1,5V x4
Operating temperature: -10...50°C
IP rating: IP54
Dimensions: 165x90x37mm
Standard equipment: 2 crocodile clips; neckstrap; soft case; test lead
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Illumination: yes
Display resolution: 128x64

Виробник: SONEL
Category: LAN and Telephone Networks Testers
Description: Meter: reflectometer; LCD TFT 3,5"; Resol: 1%; Range: 6km; -20÷70°C
Type of meter: reflectometer
Kind of display used: LCD TFT 3,5"
Detection: place of cable failure
Measuring resolution: 1%
Measuring range: 6km
Input impedance: 25Ω; 50Ω; 75Ω; 100Ω; 125Ω; 200Ω
Power supply: battery LR6 AA 1,5V x4
Operating temperature: -20...70°C
IP rating: IP67
Dimensions: 220x98x58mm
Measuring instrument features: cursor x2
Standard equipment: 2 crocodile clips; neckstrap; soft case; test lead
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Illumination: yes
Display resolution: 320x240

Виробник: SONEL
Category: Phase Sequence Indicators
Description: Tester: phase sequence; 120÷690VAC; Freq: 10÷70Hz; IP42
Conform to the norm: CAT III 600V; EN 61010
Power supply: from tested wiring system
IP rating: IP42
Type of tester: phase sequence
Body dimensions: 132x73x32mm
Operating frequency: 10...70Hz
Phase-to-phase voltage range for phase sequence indication: 120...690V AC; 120...690V AC
Weight without batteries: 162g
Standard equipment: crocodile clips; set of test leads (red, black and yellow)
Measuring instrument features: 760 V AC max. phase-to-phase operating voltage; indicates phase sequence; neon-LED display; operates in 10Hz...70Hz power systems; voltage indicator individual for each phase

Виробник: SONEL
Category: Phase Sequence Indicators
Description: Tester: phase sequence; 35÷690VAC; Freq: 10÷70Hz; IP42
Conform to the norm: CAT III 600V; EN 61010
Power supply: from tested wiring system
IP rating: IP42
Type of tester: phase sequence
Body dimensions: 130x72x31mm
Operating frequency: 10...70Hz
Phase-to-phase voltage range for phase sequence indication: 35...690V AC; 35...690V AC
Weight without batteries: 200g
Measuring instrument features: 760 V AC max. phase-to-phase operating voltage; indicates phase sequence; neon-LED display; operates in 10Hz...70Hz power systems; voltage indicator individual for each phase

Виробник: SONEL
Category: Phase Sequence Indicators
Description: Tester: phase sequence; 120÷690VAC; 2÷70Hz; IP42; -10÷45°C
Conform to the norm: CAT III 600V; EN 61010
Power supply: battery 6F22 9V x1
IP rating: IP42
Type of tester: phase sequence
Operating temperature: -10...45°C
Frequency measuring range: 2...70Hz
Phase-to-phase voltage range for phase sequence indication: 120...690V AC; 120...690V AC
Standard equipment: 3 pointed electrodes; crocodile clips; test leads
Measuring instrument features: 760 V AC max. phase-to-phase operating voltage; automatic power-off; can operate in 2Hz...70Hz wiring systems; detects magnetic fields; indicates phase sequence (direction of field rotation); indicates rotation direction of motors: by means of test leads in state without voltage, contactless during motor operation; neon-LED display
Optional equipment: adapter for three phase sockets; cover
Battery/ rechargeable battery: battery 6F22 9V x1

Виробник: SONEL
Category: Indicators, Voltage & Continuity Testers
Description: Tester: non-contact voltage detector; 90÷1000VAC; 50÷60Hz; IP54
Type of tester: non-contact voltage detector
Detected voltage range: 90...1000V AC
Frequency range of detectable voltage: 50...60Hz
Additional functions: white LED torch
Operating temperature: -10...50°C
Conform to the norm: CAT III 1000V; EN 61010
Power supply: battery LR03 AAA 1,5V x2
Measuring instrument features: optical and acoustic indication of detected voltage
IP rating: IP54
Length: 177mm
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2

Виробник: SONEL
Category: Indicators, Voltage & Continuity Testers
Description: Tester: non-contact voltage detector; 12÷1000VAC,100÷1000VDC
Type of tester: non-contact voltage detector
Detected voltage range: 0.012...1kV AC; 100...1000V DC
Frequency range of detectable voltage: 50...60Hz
Additional functions: white LED torch
Operating temperature: 0...50°C
Conform to the norm: CAT III 1000V; EN 61010
Power supply: battery LR03 AAA 1,5V x2
Measuring instrument features: optical and acoustic indication of detected voltage
Dimensions: 160x23x25mm
IP rating: IP67
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: solar power; Range: 100÷1400W/m2; ±(1%+2digit); IP65
Interface: LoRa (Long Range); USB
Body dimensions: 134x79x28mm
IP rating: IP65
Standard equipment: calibration certificate; mounting holder; power supply; soft case
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V 1300mAh x1
Temperature measuring range: -20...100°C
Temperature measurement resolution: 0.1°C
Temperature measurement accuracy: ±(1% + 2 digit)
Measurement memory: 5000
Measuring range: 100...1400W/m2
Measurement: inclination angle; insolation; temperature
Type of meter: solar power
Measuring instrument features: built-in compass; inclination sensor

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: solar power; Range: 100÷1400W/m2; ±(1%+2digit); IP65
Interface: LoRa (Long Range); USB
Body dimensions: 134x79x28mm
IP rating: IP65
Standard equipment: adapter; calibration certificate; mounting holder; power supply; soft case
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V 1300mAh x1
Temperature measuring range: -20...100°C
Temperature measurement resolution: 0.1°C
Temperature measurement accuracy: ±(1% + 2 digit)
Measurement memory: 5000
Measuring range: 100...1400W/m2
Measurement: inclination angle; insolation; temperature
Type of meter: solar power
Measuring instrument features: built-in compass; inclination sensor

Виробник: SONEL
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; colour,LCD 5,6"; VAC: 0÷1.5kV; IP65
Battery/ rechargeable battery: rechargeable batteryLi-Ion 10,8V 3,5Ah x1
Capacitance measuring accuracy: ±(5%+ 5 digit)
Power supply: rechargeable batteryLi-Ion 10,8V 3,5Ah x1
DC voltage measuring accuracy: ±(3% + 2 digit)
Standard equipment: calibration certificate; crocodile clips; pointed electrode; power supply; test leads; USB adapter; USB / USB C cable
Touchpad: yes
Body dimensions: 234x169x70mm
Kind of display used: colour; LCD 5,6"
Temperature measuring range: -40...99.9°C
DC voltage measuring range: 0...1.5kV
Weight with battery: 1.3kg
Measurement memory: 9999
AC voltage measuring range: 0...1.5kV
Insulation resistance measuring ranges: 0...999.9kΩ; 1Ω...2TΩ; 10Ω...99.99MΩ; 10Ω...99.99GΩ; 100Ω...999.9MΩ; 100Ω...999.9GΩ; 1...9.999MΩ; 1...9.999GΩ
Insulation resistance measuring accuracy: ±(3% + 20digit)
Interface: USB
Test voltage: 10V; 25V; 50V; 100V; 250V; 500V; 1kV; 2.5kV
Conform to the norm: CAT III 600V; CAT IV 600V; EN 61010
AC voltage measuring accuracy: ±(3% + 2 digit)
Type of meter: insulation resistance
IP rating: IP65
Measurement: AC voltage; capacitance; DC voltage; insulation resistance; resistance; temperature
Capacitance measuring range: 0...999nF; 1...9.99µF

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: appliance meter; LCD; VAC: 0÷500V; Interface: Bluetooth
Interface: Bluetooth
Kind of display used: LCD
Connectors for the country: Europe
RCD test: general purpose
Related items: WAADAAGT16C; WAADAAGT16P; WAADAAGT16T; WAADAAGT32C; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADATWR1J; WAADAWS01; WAADAWS05; WAFUTM6; WAKROBU20K02; WAKRORE20K02; WAKROYE20K02; WAPOZSZE4; WAPOZUCH1; WAPRZ1X2BUBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WAPRZ010REBB; WAPRZ020REBB; WAPRZ005REBB; WASONBUOGB1; WASONREOGB1; WASONSP2M; WASONYEOGB1
Measuring instrument features: illuminated buttons
IP rating: IP67
AC voltage measuring range: 0...500V
Body dimensions: 220x98x58mm
Measurement memory: 10k
Standard equipment: 2 pointed electrodes; calibration certificate; crocodile clip x1; neckstrap; soft case; test leads ( 3pcs.); WS-05 test adapter
Measurement: protective conductor resistance; RCD tripping current; RCD tripping time; short circuit loop impedance
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Type of meter: appliance meter
Battery/ rechargeable battery: battery LR6 AA 1,5V x4

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: appliance meter; LCD; VAC: 0÷500V; Interface: Bluetooth
Type of meter: appliance meter
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Interface: Bluetooth
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Kind of display used: LCD
Measuring instrument features: illuminated buttons
IP rating: IP67
Related items: WAADAAGT16C; WAADAAGT16P; WAADAAGT16T; WAADAAGT32C; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADATWR1J; WAADAWS03; WAADAWS04; WAFUTM6; WAKROBU20K02; WAKRORE20K02; WAKROYE20K02; WAPOZSZE4; WAPOZUCH1; WAPRZ1X2BUBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WAPRZ010REBB; WAPRZ015BUBBN; WAPRZ020REBB; WAPRZ030REBBSZ; WAPRZ005REBB; WASONBUOGB1; WASONG25; WASONREOGB1; WASONSP2M; WASONYEOGB1
Illumination: yes
AC voltage measuring range: 0...500V
Body dimensions: 220x102x60mm
Test voltage: 100V; 250V; 500V
Measurement memory: 10k
Insulation resistance measuring ranges: 0.1...99.9MΩ; 0.25...199.9MΩ; 500kΩ...599.9MΩ
Standard equipment: 2 crocodile clips; 3 pointed electrodes; adapter; calibration certificate; neckstrap; probe; soft case; test leads
Measurement: earthing resistance; insulation resistance; protective conductor resistance; RCD tripping current; RCD tripping time; short circuit loop impedance

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: appliance meter; colour,LCD 7"; Resolution: 800x480
Connectors for the country: Europe
Kind of display used: colour; LCD 7"
IP rating: IP51
Related items: WAADAAGT16C; WAADAAGT16P; WAADAAGT16T; WAADAAGT32C; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADAAISO25; WAADACS1; WAADACS5KV; WAADALP1KPL; WAADALP10AKPL; WAADALP10BKPL; WAADATWR1J; WAADAWS04; WAAKU15; WACEGC3OKR; WACEGN1BB; WAFUTL2; WAFUTL3; WAKROBL32K09; WAKROBU20K02; WAKRORE20K02; WAKROYE20K02; WAPOZSZEKPL; WAPRZ1X2BUBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WAPRZ1X8BLBB; WAPRZ1X8REBB; WAPRZ010REBB; WAPRZ015BUBBSZ; WAPRZ020REBB; WAPRZ025BUBBSZ; WAPRZ030REBBSZ; WAPRZ050YEBBSZ; WAPRZ005REBB; WAPRZLAD12SAM; WAPRZLAD230; WAPRZUSB; WASONBUOGB1; WASONG30; WASONG80; WASONPRS1PL; WASONREOGB1; WASONREOGB2; WASONSP2M; WASONYEOGB1; WAZACIMA1; WAZASZ7
Measuring instrument features: phase sequence indication
Measuring range: 0...399,9klx
Battery/ rechargeable battery: rechargeable battery Li-Ion 11,1V 3400mAh x1
Illumination: yes
Touchpad: yes
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Body dimensions: 288x223x75mm
Interface: Bluetooth; USB; WiFi
Type of meter: appliance meter
Test voltage: 10V; 50V; 100V; 250V; 500V; 1kV; 1.5kV; 2.5kV
Display resolution: 800x480
Standard equipment: calibration certificate; crocodile clips; mains cable; neckstrap; pointed electrode; power supply; soft case; test leads; USB cable
Insulation resistance measuring ranges: 10kΩ...9.99MΩ; 50kΩ...250MΩ; 100kΩ...500MΩ; 250kΩ...999MΩ; 500kΩ...2GΩ; 1MΩ...3GΩ; 1.5MΩ...5GΩ; 2.5MΩ...999GΩ
Measurement: earthing resistance; ground resistivity; illuminance; insulation resistance; protective conductor resistance; RCD tripping current; RCD tripping time; short circuit loop impedance

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: appliance meter; VAC: 0÷500V; ±(2%+3digit); IP51
Type of meter: appliance meter
AC voltage measuring range: 0...500V
Insulation resistance measuring ranges: 50kΩ...250MΩ; 100kΩ...500MΩ; 250kΩ...999MΩ; 500kΩ...2GΩ; 1MΩ...4.99GΩ
Standard equipment: adapter x3; calibration certificate; crocodile clips; current clamp; mains cable; microSD 4GB memory card; nylon strap; power supply; soft case; test adapter; test leads; test probe x1; USB cable
Conform to the norm: CAT IV 300V; CAT V 500V; EN 61010; PN EN 61326-1; PN EN 61326-2-2
IP rating: IP51
Related items: IRM-1-MPI; WAADAAC16; WAADAAGT16P; WAADAAGT16T; WAADAAGT32C; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADAAISO10C; WAADACPV; WAADALP1KPL; WAADALP10AKPL; WAADALP10BKPL; WAADAMC4; WAADAPVM1; WAADAWS03; WAADAWS04; WAAKU15; WACEGC3OKR; WACEGC4AOKR; WACEGC5AOKR; WACEGC6AOKR; WACEGC7AOKR; WACEGCPVOKR; WACEGF1AOKR; WACEGF2AOKR; WACEGF3AOKR; WACEGN1BB; WAFUTL2; WAFUTL3; WAFUTM13; WAKROBL20K01; WAKROBU20K02; WAKRORE20K02; WAKROYE20K02; WAPOZSZEKPL; WAPRZ1X2BLBB; WAPRZ1X2BUBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WAPRZ010REBB; WAPRZ015BUBBSZ; WAPRZ020REBB; WAPRZ025BUBBSZ; WAPRZ030REBBSZ; WAPRZ050YEBBSZ; WAPRZ005REBB; WAPRZLAD12SAM; WAPRZLAD230; WAPRZUSB; WASONBUOGB1; WASONG30; WASONG80V2; WASONREOGB1; WASONYEOGB1; WAZACIMA1; WAZASZ7
Measurement: active electric energy; active power; AC voltage; apparent electric energy; apparent power; earthing resistance; frequency; harmonics; illuminance; insolation; insulation resistance; RCD tripping current; RCD tripping time; reactive electric energy; reactive power; short circuit loop impedance; temperature; THD
Measuring instruments application: for solar panels; photovoltaics
Interface: Bluetooth; USB; WiFi
Body dimensions: 288x223x75mm
Connectors for the country: Europe
Earthing resistance measuring accuracy: ±(2% + 3 digit)
Test voltage: 50V; 100V; 250V; 500V; 1kV
Display resolution: 800x480
Touchpad: yes
Earthing resistance measuring range: 0...99.9kΩ
Kind of display used: LCD TFT 7"
RCD test: general purpose

Виробник: SONEL
Category: Power Quality Analyzers
Description: Meter: short circuit loop impedance; LCD; VAC: 0÷500V
IP rating: IP67
Kind of display used: LCD
Measuring instrument features: low-voltage measurement of continuity of circuit and resistance; measurement of resistance (RS) and reactance (XS) components.
Type of meter: short circuit loop impedance
Related items: WAADAAGT16C; WAADAAGT16P; WAADAAGT16T; WAADAAGT32C; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADAWS03; WAADAWS04; WAADAWS07; WAKROBU20K02; WAPROSONPE6; WAPRZ010REBB; WAPRZ020REBB; WAPRZ005REBB; WASONSP2M
Illumination: yes
AC voltage measuring range: 0...500V
Loop impedance measuring range: 130mΩ...1999Ω
Dimensions: 220x102x61mm
AC voltage measuring accuracy: ±(2% + 2 digit)
Loop impedance measuring accuracy: ±(5% + 3 digit)
Measurement memory: 990
Standard equipment: 2 pointed electrodes; adapter with UNI-schuko plug; calibration certificate; crocodile clip x1; soft case; test leads ( 3pcs.)
Measurement: AC voltage; short-circuit current; short circuit loop impedance
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Power supply: battery LR6 AA 1,5V x4
Interface: Bluetooth
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: short circuit loop impedance; VAC accuracy: ±(2%+2digit)
Measurement: AC voltage; short-circuit current; short circuit loop impedance
Power supply: rechargeable battery Li-Ion 7,2V 8,8Ah x1
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,2V 8800mAh x1
Conform to the norm: CAT IV 1000V; EN 61010
Interface: USB; WiFi
IP rating: IP67
Type of meter: short circuit loop impedance
AC voltage measuring range: 0...900V
Loop impedance measuring range: 7.2...1.999mΩ
Dimensions: 429x328x236mm
Loop impedance measuring accuracy: ±(2%% + 2mΩ)
AC voltage measuring accuracy: ±(2% + 2 digit)
Measurement memory: 990
Standard equipment: 2 pointed electrodes; calibration certificate; crocodile clip x2; mains cable; power supply AC 230V; soft case; test leads ( 2pcs.); USB cable
Measuring instrument features: measurement of resistance (RS) and reactance (XS) components.; measurement of very low short circuit loop impedances (with resolution 0,1 mΩ)

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: appliance meter; VAC accuracy: ±(2%+2digit); VAC: 0÷600V
Operating temperature: -10...40°C
Battery/ rechargeable battery: battery AA 1,5V x4; battery AAA 1,5V x2
Power supply: battery AA 1,5V x5; rechargeable battery Ni-MH AA 1,2V x4
DC voltage measuring accuracy: ±(0.5% + 2 digit)
Standard equipment: 3 crocodile clips; adapter; calibration certificate; current clamp; neckstrap; pointed electrode; soft case; test leads; test leads ( 3pcs.)
Current measuring resolution: 0.1A
Related items: WAADAMC4; WACEGCPVOKR; WAKROBL20K01; WAKRORE20K02; WAKROYE20K02; WAPRZ1X2BLBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WASONREOGB1
DC voltage measuring range: 0...1kV
AC current measuring accuracy: ±(5% + 2 digit)
Dimensions: 228x102x60mm
Measurement memory: 4059
AC voltage measuring range: 0...600V
Insulation resistance measuring ranges: 250kΩ...2MΩ; 0.25...5MΩ; 250kΩ...1GΩ; 500kΩ...9999MΩ
Interface: Bluetooth
Conform to the norm: IEC 61326-1; IEC 61326-2-2
AC voltage measuring accuracy: ±(2% + 2 digit)
Type of meter: appliance meter
Measurement: AC current; AC voltage; DC voltage; insulation resistance; power; short-circuit current
Measuring instruments application: for solar panels; photovoltaics
AC current measuring range: 0...400A
Storage temperature: -20...60°C

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: appliance meter; VAC accuracy: ±(2%+2digit); VAC: 0÷600V
Operating temperature: -10...40°C
Battery/ rechargeable battery: battery AA 1,5V x4; battery AAA 1,5V x2
Voltage measuring resolution: 0.1V DC
Power supply: battery AA 1,5V x5; rechargeable battery Ni-MH AA 1,2V x4
DC voltage measuring accuracy: ±(0.5% + 2 digit)
Standard equipment: 3 crocodile clips; adapter; calibration certificate; current clamp; neckstrap; pointed electrode; soft case; test lead x3
Current measuring resolution: 0.1A
Related items: WAADAAC16; WAADAAGT16P; WAADAAGT16T; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADAMC4; WACEGCPVOKR; WAFUTL4; WAKROBL20K01; WAKRORE20K02; WAKROYE20K02; WAPOZKEYMC4; WAPOZPAS6; WAPROREADER; WAPROSONPE6; WAPRZ1X2BLBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WASONBLOGB1; WASONREOGB1; WASONYEOGB1; WMPLIRM1; WMPLPVM1021
DC voltage measuring range: 0...1kV
AC current measuring accuracy: ±(5% + 2 digit)
Dimensions: 244x169x71mm
Measurement memory: 4059
Measuring range: 0,00kW...100,00kW
AC voltage measuring range: 0...600V
Insulation resistance measuring ranges: 250kΩ...2GΩ; 250kΩ...5GΩ; 500kΩ...9999MΩ
Interface: Bluetooth; LoRa (Long Range)
Conform to the norm: CAT III 1000V; IEC 61326-1; IEC 61326-2-2
AC voltage measuring accuracy: ±(2% + 2 digit)
Type of meter: appliance meter
IP rating: IP54
Measurement: AC current; AC voltage; DC voltage; insulation resistance; power; protective conductor resistance; short-circuit current
Measuring instruments application: for solar panels; photovoltaics
AC current measuring range: 0...400A
Storage temperature: -20...60°C

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: appliance meter; VAC accuracy: ±(2%+2digit); VAC: 0÷600V
Operating temperature: -10...40°C
Battery/ rechargeable battery: battery AA 1,5V x4; battery AAA 1,5V x2
Voltage measuring resolution: 0.1V DC
Power supply: battery AA 1,5V x5; rechargeable battery Ni-MH AA 1,2V x4
DC voltage measuring accuracy: ±(0.5% + 2 digit)
Standard equipment: 3 crocodile clips; adapter; calibration certificate; current clamp; IRM-1; mounting kit; neckstrap; pointed electrode; power supply; soft case; test lead x3
Current measuring resolution: 0.1A
Related items: WAADAAC16; WAADAAGT16P; WAADAAGT16T; WAADAAGT32P; WAADAAGT32T; WAADAAGT63P; WAADAMC4; WACEGCPVOKR; WAFUTL4; WAKROBL20K01; WAKRORE20K02; WAKROYE20K02; WAPOZKEYMC4; WAPOZPAS6; WAPOZUCHPV; WAPROREADER; WAPROSONPE6; WAPRZ1X2BLBB; WAPRZ1X2REBB; WAPRZ1X2YEBB; WASONBLOGB1; WASONREOGB1; WASONTPVC; WASONTPVCKPL; WASONYEOGB1; WAZACPV; WAZASZ24; WMPLIRM1; WMPLPVM1021
DC voltage measuring range: 0...1kV
AC current measuring accuracy: ±(5% + 2 digit)
Measurement memory: 4059
Measuring range: 0,00kW...100,00kW
AC voltage measuring range: 0...600V
Insulation resistance measuring ranges: 250kΩ...2GΩ; 250kΩ...5GΩ; 500kΩ...9999MΩ
Interface: Bluetooth; LoRa (Long Range)
Conform to the norm: CAT III 1000V; IEC 61326-1; IEC 61326-2-2
AC voltage measuring accuracy: ±(2% + 2 digit)
Type of meter: appliance meter
IP rating: IP54
Measurement: AC current; AC voltage; DC voltage; insulation resistance; power; protective conductor resistance; short-circuit current
Measuring instruments application: for solar panels; photovoltaics
AC current measuring range: 0...400A
Storage temperature: -20...60°C

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: appliance meter; VAC accuracy: ±(2%+6digit); VAC: 0÷1kV
Related items: CMP-1015-PV; IRM-1; WAADAUSBLORA; WAFUTL4; WAKROBL20K01; WAPRZ1X8BLIEC; WAPRZ1X8REBB; WAPRZUSB; WASONBLOGB2; WASONTPVCKPL; WAZASZ24
Type of meter: appliance meter
Conform to the norm: CAT III 600V; CAT III 1500VDC
Measuring instruments application: for solar panels; photovoltaics
Power supply: from tested wiring system; rechargeable battery Li-Ion 7,2V 9800mAh x1
IP rating: IP65
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,2V 9800mAh x1
Connection: RJ45; USB
Storage temperature: -20...60°C
Operating temperature: -10...45°C
AC current measuring range: 0...30A; 0...40A
AC voltage measuring range: 0...1kV
DC voltage measuring range: 0...1.5kV
Current measuring resolution: 10mA
Dimensions: 390x308x172mm
DC voltage measuring accuracy: ±(0.5% + 2 digit)
AC current measuring accuracy: ±(1% + 2 digit)
AC voltage measuring accuracy: ±(2% + 6 digit)
Test voltage: 250V; 500V; 1kV
Measurement memory: 9999
Insulation resistance measuring ranges: 250kΩ...200MΩ; 500kΩ...500MΩ; 1MΩ...1GΩ
Standard equipment: 1,8m long test lead (black); 1,8m long test lead (red); 2 crocodile clips; 2 pointed electrodes; 3m long test lead (blue); 3m long test lead (yellow); adapter; cable WAPRZ1X8BLIEC; manufacturer's calibration certificate; soft case; test lead; USB cable
Interface: Bluetooth; WiFi
Measurement: active power; AC voltage; DC voltage; frequency; insolation; insulation resistance; leakage current; resistance; short-circuit current; temperature

Виробник: SONEL
Category: PV and EVSE Testers and Meters
Description: Meter: appliance meter; VAC accuracy: ±(2%+6digit); VAC: 0÷1kV
Related items: CMP-1015-PV; IRM-1; WAADAUSBLORA; WAFUTL4; WAKROBL20K01; WAPRZ1X8BLIEC; WAPRZ1X8REBB; WAPRZUSB; WASONBLOGB2; WASONTPVCKPL; WAZASZ24
Type of meter: appliance meter
Conform to the norm: CAT III 600V; CAT III 1500VDC
Measuring instruments application: for solar panels; photovoltaics
Power supply: from tested wiring system; rechargeable battery Li-Ion 7,2V 9800mAh x1
IP rating: IP65
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,2V 9800mAh x1
Connection: RJ45; USB
Storage temperature: -20...60°C
Operating temperature: -10...45°C
AC current measuring range: 0...30A; 0...40A
AC voltage measuring range: 0...1kV
DC voltage measuring range: 0...1.5kV
Current measuring resolution: 10mA
Dimensions: 390x308x172mm
DC voltage measuring accuracy: ±(0.5% + 2 digit)
AC current measuring accuracy: ±(1% + 2 digit)
AC voltage measuring accuracy: ±(2% + 6 digit)
Test voltage: 250V; 500V; 1kV
Measurement memory: 9999
Insulation resistance measuring ranges: 250kΩ...200MΩ; 500kΩ...500MΩ; 1MΩ...1GΩ
Standard equipment: 1,8m long test lead (black); 2 crocodile clips; 2 pointed electrodes; 3m long test lead (blue); 3m long test lead (yellow); adapter; cable WAPRZ1X8BLIEC; clamp meter CMP-1015-PV; manufacturer's calibration certificate; power supply WAZASZ24; soft case; solar irradiance meter IRM-1; test lead; test probe WASONTPVCKPL; USB cable; WAADAUSBLORA adapter
Interface: Bluetooth; WiFi
Measurement: active power; AC voltage; DC voltage; frequency; insolation; insulation resistance; leakage current; resistance; short-circuit current; temperature

Виробник: SONEL
Category: Bags & Soft Cases
Description: Hard carrying case; black; plastic
Type of test accessories: hard carrying case
Colour: black
Material: plastic

Виробник: SONEL
Category: Bags & Soft Cases
Description: Hard carrying case; black; plastic
Type of test accessories: hard carrying case
Related items: MPI-540-ENG; MPI-540-PL; MPI-540PV-ENG; MPI-540PV-PL; MPI-540PVS-PL; MPI-540S-PL
Colour: black
Material: plastic

Виробник: SONEL
Category: Bags & Soft Cases
Description: Hard carrying case; black; plastic
Type of test accessories: hard carrying case
Related items: MPI-530IT-ENG; MPI-530IT-PL
Colour: black
Material: plastic

Виробник: SONEL
Category: Bags & Soft Cases
Description: Hard carrying case; black; plastic
Type of test accessories: hard carrying case
Related items: PQM-700-ENG; PQM-700-PL; PQM-710-ENG; PQM-710-PL; PQM-711-ENG; PQM-711-PL
Colour: black
Material: plastic
