10114830-10108LF Amphenol ICC (FCI)
Виробник: Amphenol ICC (FCI)
Description: CONN HEADER SMD R/A 8POS 1.25MM
Contact Finish - Post: Tin
Insulation Material: Liquid Crystal Polymer (LCP)
Shrouding: Shrouded - 4 Wall
Insulation Height: 0.134" (3.40mm)
Contact Shape: Rectangular
Part Status: Active
Contact Finish - Mating: Tin
Pitch - Mating: 0.049" (1.25mm)
Insulation Color: Natural
Contact Material: Phosphor Bronze
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Detent Lock
Contact Type: Male Pin
Operating Temperature: -40°C ~ 105°C
Style: Board to Cable/Wire
Number of Rows: 1
Number of Positions: 8
Mounting Type: Surface Mount, Right Angle
Current Rating (Amps): 1A
Voltage Rating: 125V
Connector Type: Header
Features: Solder Retention
Packaging: Tape & Reel (TR)
| Кількість | Ціна |
|---|---|
| 1300+ | 22.71 грн |
| 2600+ | 20.82 грн |
Відгуки про товар
Написати відгук
Технічний опис 10114830-10108LF Amphenol ICC (FCI)
Description: CONN HEADER SMD R/A 8POS 1.25MM, Contact Finish - Post: Tin, Insulation Material: Liquid Crystal Polymer (LCP), Shrouding: Shrouded - 4 Wall, Insulation Height: 0.134" (3.40mm), Contact Shape: Rectangular, Part Status: Active, Contact Finish - Mating: Tin, Pitch - Mating: 0.049" (1.25mm), Insulation Color: Natural, Contact Material: Phosphor Bronze, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Detent Lock, Contact Type: Male Pin, Operating Temperature: -40°C ~ 105°C, Style: Board to Cable/Wire, Number of Rows: 1, Number of Positions: 8, Mounting Type: Surface Mount, Right Angle, Current Rating (Amps): 1A, Voltage Rating: 125V, Connector Type: Header, Features: Solder Retention, Packaging: Tape & Reel (TR).
Інші пропозиції 10114830-10108LF за ціною від 21.95 грн до 60.37 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1011483010108LF | Виробник : AMPHENOL |
Category: Raster signal connectors 1,25mm Description: Connector: wire-board; plug; male; PIN: 8; Minitek; 1A; 125V; angled Type of connector: wire-board Connector: plug Kind of connector: male Number of pins: 8 Manufacturer series: Minitek Current rating: 1A Rated voltage: 0.125kV Spatial orientation: angled Contacts pitch: 1.25mm Contact plating: tinned Flammability rating: UL94V-0 Connector variant: shrouded Contact material: phosphor bronze Operating temperature: -40...105°C Body colour: natural Mechanical mounting: on PCBs Max. contact resistance:: 20mΩ Body material: thermoplastic Electrical mounting: SMT |
на замовлення 113100 шт: термін постачання 14-30 дні (днів) |
|
||||||||||||||||
|
|
10114830-10108LF | Виробник : Amphenol ICC (FCI) |
Description: CONN HEADER SMD R/A 8POS 1.25MM Contact Shape: Rectangular Part Status: Active Contact Finish - Post: Tin Contact Finish - Mating: Tin Pitch - Mating: 0.049" (1.25mm) Insulation Color: Natural Contact Material: Phosphor Bronze Material Flammability Rating: UL94 V-0 Termination: Solder Insulation Material: Liquid Crystal Polymer (LCP) Shrouding: Shrouded - 4 Wall Insulation Height: 0.134" (3.40mm) Number of Positions Loaded: All Fastening Type: Detent Lock Contact Type: Male Pin Operating Temperature: -40°C ~ 105°C Style: Board to Cable/Wire Number of Rows: 1 Number of Positions: 8 Mounting Type: Surface Mount, Right Angle Current Rating (Amps): 1A Voltage Rating: 125V Connector Type: Header Features: Solder Retention Packaging: Cut Tape (CT) |
на замовлення 3742 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
 |
10114830-10108LF | Виробник : Amphenol FCI |
Headers & Wire Housings FitMate 1.25, header, single row, right angle, SMT, tin plating, 8pos |
на замовлення 65 шт: термін постачання 21-30 дні (днів) |
|
||||||||||||||||
 |
10114830-10108LF | Виробник : AMPHENOL COMMUNICATIONS SOLUTIONS |
Description: AMPHENOL COMMUNICATIONS SOLUTIONS - 10114830-10108LF - Stiftleiste, Wire-to-Board, 1.25 mm, 1 Reihe(n), 8 Kontakt(e), Oberflächenmontage, abgewinkelt tariffCode: 85366930 rohsCompliant: YES Kontaktüberzug: Verzinnte Kontakte hazardous: false rohsPhthalatesCompliant: YES Kontaktmaterial: Phosphorbronze isCanonical: Y usEccn: EAR99 Steckverbinderkragen: Mit Kragen Anzahl der Kontakte: 8Kontakt(e) euEccn: NLR Steckverbindersysteme: Wire-to-Board Steckverbinder: PCB-Stiftleiste Produktpalette: FitMate 10114830 Series productTraceability: No Kontaktanschluss: Oberflächenmontage, abgewinkelt Anzahl der Reihen: 1Reihe(n) Rastermaß: 1.25mm SVHC: No SVHC (04-Feb-2026) |
на замовлення 1250 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
| 10114830-10108LF | Виробник : AFCI |
|
на замовлення 432 шт: термін постачання 14-28 дні (днів) |
