Технічний опис 1711047 Phoenix Contact
Description: DFMC 1 5/15-ST-3 5-LR BK, Features: Ejector Latches, Push Button Actuated, Packaging: Bulk, Color: Black, Mounting Type: Free Hanging (In-Line), Number of Positions: 30, Pitch: 0.138" (3.50mm), Type: Plug, Female Sockets, Operating Temperature: -40°C ~ 100°C, Termination Style: Screw - Clamping Yoke (Tension Sleeve), Current - IEC: 8A, Number of Levels: 2, Wire Gauge or Range - AWG: 16-24 AWG, Wire Gauge or Range - mm²: 0.2-1.5mm², Positions Per Level: 15, Plug Wire Entry: 180°, Contact Mating Finish: Tin, Current - UL: 8 A, Voltage - IEC: 160 V, Voltage - UL: 300 V.
Інші пропозиції 1711047
| Фото | Назва | Виробник | Інформація | Доступність | Ціна |
|---|---|---|---|---|---|
| 1711047 | Phoenix Contact |
Description: DFMC 1 5/15-ST-3 5-LR BK Features: Ejector Latches, Push Button Actuated Packaging: Bulk Color: Black Mounting Type: Free Hanging (In-Line) Number of Positions: 30 Pitch: 0.138" (3.50mm) Type: Plug, Female Sockets Operating Temperature: -40°C ~ 100°C Termination Style: Screw - Clamping Yoke (Tension Sleeve) Current - IEC: 8A Number of Levels: 2 Wire Gauge or Range - AWG: 16-24 AWG Wire Gauge or Range - mm²: 0.2-1.5mm² Positions Per Level: 15 Plug Wire Entry: 180° Contact Mating Finish: Tin Current - UL: 8 A Voltage - IEC: 160 V Voltage - UL: 300 V |
товару немає в наявності |
Мінімальне замовлення: 50 шт В кошику од. на суму грн. |
| 1711047 |
Виробник: Phoenix Contact
Description: DFMC 1 5/15-ST-3 5-LR BK
Features: Ejector Latches, Push Button Actuated
Packaging: Bulk
Color: Black
Mounting Type: Free Hanging (In-Line)
Number of Positions: 30
Pitch: 0.138" (3.50mm)
Type: Plug, Female Sockets
Operating Temperature: -40°C ~ 100°C
Termination Style: Screw - Clamping Yoke (Tension Sleeve)
Current - IEC: 8A
Number of Levels: 2
Wire Gauge or Range - AWG: 16-24 AWG
Wire Gauge or Range - mm²: 0.2-1.5mm²
Positions Per Level: 15
Plug Wire Entry: 180°
Contact Mating Finish: Tin
Current - UL: 8 A
Voltage - IEC: 160 V
Voltage - UL: 300 V
Description: DFMC 1 5/15-ST-3 5-LR BK
Features: Ejector Latches, Push Button Actuated
Packaging: Bulk
Color: Black
Mounting Type: Free Hanging (In-Line)
Number of Positions: 30
Pitch: 0.138" (3.50mm)
Type: Plug, Female Sockets
Operating Temperature: -40°C ~ 100°C
Termination Style: Screw - Clamping Yoke (Tension Sleeve)
Current - IEC: 8A
Number of Levels: 2
Wire Gauge or Range - AWG: 16-24 AWG
Wire Gauge or Range - mm²: 0.2-1.5mm²
Positions Per Level: 15
Plug Wire Entry: 180°
Contact Mating Finish: Tin
Current - UL: 8 A
Voltage - IEC: 160 V
Voltage - UL: 300 V
товару немає в наявності
Мінімальне замовлення: 50 шт
