1939837 Phoenix Contact
Виробник: Phoenix Contact
Description: TERM BLOCK PLUG 11POS STR 7.62MM
Voltage - UL: 300 V
Voltage - IEC: 1 kV
Current - UL: 10 A
Contact Mating Finish: Tin
Plug Wire Entry: 180°
Positions Per Level: 11
Wire Gauge or Range - mm²: 0.2-2.5mm²
Wire Gauge or Range - AWG: 12-26 AWG
Number of Levels: 1
Current - IEC: 12A
Termination Style: Screwless - Push-In Spring
Type: Plug, Female Sockets
Pitch: 0.300" (7.62mm)
Number of Positions: 11
Mounting Type: Free Hanging (In-Line)
Color: Green
Features: Mating Flange, Retention Latches (Non-Wire Side)
Packaging: Bulk
Відгуки про товар
Написати відгук
Технічний опис 1939837 Phoenix Contact
Description: TERM BLOCK PLUG 11POS STR 7.62MM, Voltage - UL: 300 V, Voltage - IEC: 1 kV, Current - UL: 10 A, Contact Mating Finish: Tin, Plug Wire Entry: 180°, Positions Per Level: 11, Wire Gauge or Range - mm²: 0.2-2.5mm², Wire Gauge or Range - AWG: 12-26 AWG, Number of Levels: 1, Current - IEC: 12A, Termination Style: Screwless - Push-In Spring, Type: Plug, Female Sockets, Pitch: 0.300" (7.62mm), Number of Positions: 11, Mounting Type: Free Hanging (In-Line), Color: Green, Features: Mating Flange, Retention Latches (Non-Wire Side), Packaging: Bulk.
Інші пропозиції 1939837
| Фото | Назва | Виробник | Інформація | Доступність | Ціна |
|---|---|---|---|---|---|
 |
1939837 | Phoenix Contact |
Pluggable Terminal Blocks 11 Pos 7.62mm pitch Plug 24-12AWG Spring |
товару немає в наявності |
В кошику од. на суму грн. |
 |
1939837 | PHOENIX CONTACT |
Category: Pluggable terminal blocks Description: Connector: pluggable terminal block; plug; COMBICON M; 12A; 1kV Type of connector: pluggable terminal block Connector: plug Manufacturer series: COMBICON M Current rating: 12A Rated voltage: 1kV Number of pins: 11 Electrical mounting: push-in Contact plating: tinned Flammability rating: UL94V-0 Body material: PA Length: 25.6mm Body colour: green Contacts pitch: 7.62mm Locking system: threaded joint Height: 15mm Width: 93.42mm |
товару немає в наявності |
Мінімальне замовлення: 50 шт В кошику од. на суму грн. |
| 1939837 |
|
Виробник: Phoenix Contact
Pluggable Terminal Blocks 11 Pos 7.62mm pitch Plug 24-12AWG Spring
Pluggable Terminal Blocks 11 Pos 7.62mm pitch Plug 24-12AWG Spring
товару немає в наявності
В кошику
од. на суму грн.
| 1939837 |
|
Виробник: PHOENIX CONTACT
Category: Pluggable terminal blocks
Description: Connector: pluggable terminal block; plug; COMBICON M; 12A; 1kV
Type of connector: pluggable terminal block
Connector: plug
Manufacturer series: COMBICON M
Current rating: 12A
Rated voltage: 1kV
Number of pins: 11
Electrical mounting: push-in
Contact plating: tinned
Flammability rating: UL94V-0
Body material: PA
Length: 25.6mm
Body colour: green
Contacts pitch: 7.62mm
Locking system: threaded joint
Height: 15mm
Width: 93.42mm
Category: Pluggable terminal blocks
Description: Connector: pluggable terminal block; plug; COMBICON M; 12A; 1kV
Type of connector: pluggable terminal block
Connector: plug
Manufacturer series: COMBICON M
Current rating: 12A
Rated voltage: 1kV
Number of pins: 11
Electrical mounting: push-in
Contact plating: tinned
Flammability rating: UL94V-0
Body material: PA
Length: 25.6mm
Body colour: green
Contacts pitch: 7.62mm
Locking system: threaded joint
Height: 15mm
Width: 93.42mm
товару немає в наявності
Мінімальне замовлення: 50 шт
В кошику
од. на суму грн.
