20021221-00010C4LF Amphenol ICC (FCI)
Виробник: Amphenol ICC (FCI)
Description: CONN HEADER SMD 10POS 1.27MM
Features: Pick and Place
Packaging: Tape & Reel (TR)
Connector Type: Header
Voltage Rating: 125VAC
Current Rating (Amps): 1A per Contact
Mounting Type: Surface Mount
Number of Positions: 10
Number of Rows: 2
Style: Board to Board
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Copper Alloy
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Insulation Height: 0.220" (5.60mm)
Shrouding: Shrouded - 4 Wall
Insulation Material: Thermoplastic
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.120" (3.05mm)
| Кількість | Ціна |
|---|---|
| 500+ | 48.13 грн |
| 1000+ | 44.13 грн |
| 1500+ | 42.89 грн |
| 2500+ | 38.82 грн |
| 3500+ | 37.91 грн |
Відгуки про товар
Написати відгук
Технічний опис 20021221-00010C4LF Amphenol ICC (FCI)
Description: CONN HEADER SMD 10POS 1.27MM, Features: Pick and Place, Packaging: Tape & Reel (TR), Connector Type: Header, Voltage Rating: 125VAC, Current Rating (Amps): 1A per Contact, Mounting Type: Surface Mount, Number of Positions: 10, Number of Rows: 2, Style: Board to Board, Operating Temperature: -55°C ~ 125°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Copper Alloy, Insulation Color: Black, Pitch - Mating: 0.050" (1.27mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 10.0µin (0.25µm), Contact Finish - Post: Tin, Part Status: Active, Contact Shape: Square, Insulation Height: 0.220" (5.60mm), Shrouding: Shrouded - 4 Wall, Insulation Material: Thermoplastic, Row Spacing - Mating: 0.050" (1.27mm), Contact Length - Mating: 0.120" (3.05mm).
Інші пропозиції 20021221-00010C4LF за ціною від 46.28 грн до 89.04 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 7000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 6000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 20000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 20000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
 |
20021221-00010C4LF | Виробник : AMPHENOL COMMUNICATIONS SOLUTIONS |
Category: Pin headers Description: Connector: pin strips; socket; male; PIN: 10; SMT; Minitek127®; 2x5 Type of connector: pin strips Manufacturer series: Minitek127® Mechanical mounting: on PCBs Electrical mounting: SMT Contact plating: gold-plated Contacts pitch: 1.27mm Connector: socket Number of pins: 10 Kind of package: cut from reel Family: FCI Kind of connector: male Connector pinout layout: 2x5 Spatial orientation: vertical |
на замовлення 997 шт: термін постачання 14-30 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 1000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
 |
20021221-00010C4LF | Виробник : Amphenol FCI |
Headers & Wire Housings 1.27x1.27mm BTB, Hdr Shrd, SMT, 10 Pos |
на замовлення 2319 шт: термін постачання 21-30 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : Amphenol ICC (FCI) |
Description: CONN HEADER SMD 10POS 1.27MM Features: Pick and Place Packaging: Cut Tape (CT) Connector Type: Header Voltage Rating: 125VAC Current Rating (Amps): 1A per Contact Mounting Type: Surface Mount Number of Positions: 10 Number of Rows: 2 Style: Board to Board Operating Temperature: -55°C ~ 125°C Contact Type: Male Pin Fastening Type: Push-Pull Number of Positions Loaded: All Termination: Solder Material Flammability Rating: UL94 V-0 Contact Material: Copper Alloy Insulation Color: Black Pitch - Mating: 0.050" (1.27mm) Contact Finish - Mating: Gold Contact Finish Thickness - Mating: 10.0µin (0.25µm) Contact Finish - Post: Tin Part Status: Active Contact Shape: Square Insulation Height: 0.220" (5.60mm) Shrouding: Shrouded - 4 Wall Insulation Material: Thermoplastic Row Spacing - Mating: 0.050" (1.27mm) Contact Length - Mating: 0.120" (3.05mm) |
на замовлення 4157 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 1000 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
 |
20021221-00010C4LF | Виробник : AMPHENOL ANYTEK |
Description: AMPHENOL ANYTEK - 20021221-00010C4LF - Stiftleiste, Board-to-Board, 1.27 mm, 2 Reihe(n), 10 Kontakt(e), Oberflächenmontage, gerade tariffCode: 85366930 rohsCompliant: Y-EX Kontaktüberzug: Vergoldete Kontakte hazardous: false rohsPhthalatesCompliant: YES Kontaktmaterial: Kupferlegierung isCanonical: Y usEccn: EAR99 Steckverbinderkragen: Mit Kragen Anzahl der Kontakte: 10Kontakt(e) euEccn: NLR Steckverbindersysteme: Board-to-Board Steckverbinder: PCB-Stiftleiste Produktpalette: FCI Minitek127 20021221 productTraceability: No Kontaktanschluss: Oberflächenmontage, gerade Anzahl der Reihen: 2Reihe(n) Rastermaß: 1.27mm SVHC: Lead (07-Nov-2024) |
на замовлення 235 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
на замовлення 3 шт: термін постачання 21-31 дні (днів) |
|||||||||||||||||
| 20021221-00010C4LF | Виробник : Burndy |
Conn Shrouded Header (4 Sides) HDR 10 POS 1.27mm Solder ST Top Entry SMD T/R |
на замовлення 370 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||||||
|
|
20021221-00010C4LF | Виробник : FCI |
Minitek127®, Wire to Board connector, Shrouded vertical header, Surface Mount, Double Row, 10 Positions, 1.27mm (0.500in) Pitch |
товару немає в наявності |
