857-401 WAGO
Виробник: WAGO
Category: Measuring Conv. and Signal Isolators
Description: Converter: signal separator/amplifier; for DIN rail mounting
Conform to the norm: DIN EN 61373; EN 50121-3-2; EN 61000-6-2; EN 61000-6-3; EN 61326-1
The programming method: DIP-SWITCH; PC
Mounting: for DIN rail mounting
IP rating: IP20
Type of converter: signal separator/amplifier
Operating temperature: -25...70°C
Body dimensions: 6x94x97.8mm
Supply voltage: 24V DC
Kind of input 1: 0...30V; ±10V; ±20mA
Kind of output 1: 0...5V; 0...10mA; 0...10V; 0...20mA; 1...5V; 2...10mA; 2...10V; 4...20mA
Additional functions: inputs / outputs / power supply galvanic insulation
Відгуки про товар
Написати відгук
Технічний опис 857-401 WAGO
Category: Measuring Conv. and Signal Isolators, Description: Converter: signal separator/amplifier; for DIN rail mounting, Conform to the norm: DIN EN 61373; EN 50121-3-2; EN 61000-6-2; EN 61000-6-3; EN 61326-1, The programming method: DIP-SWITCH; PC, Mounting: for DIN rail mounting, IP rating: IP20, Type of converter: signal separator/amplifier, Operating temperature: -25...70°C, Body dimensions: 6x94x97.8mm, Supply voltage: 24V DC, Kind of input 1: 0...30V; ±10V; ±20mA, Kind of output 1: 0...5V; 0...10mA; 0...10V; 0...20mA; 1...5V; 2...10mA; 2...10V; 4...20mA, Additional functions: inputs / outputs / power supply galvanic insulation.
Інші пропозиції 857-401 за ціною від 29449.94 грн до 29449.94 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна без ПДВ | ||
|---|---|---|---|---|---|---|---|
 |
857-401 | WAGO Corporation |
Description: ISOLATION AMPLIFIER; CURRENT AND Input Range (Additional): 0 ~ 100kOhm Input Range (Current, Voltage): ±20mA, 0 ~ 30V (Configurable) Output Range: 0 ~ 20mA, 0 ~ 10V (Configurable) Isolation: 2500V (Test) Input Type: Current, Voltage Voltage - Supply: 24VDC Termination Style: Spring Terminal Operating Temperature: -25°C ~ 70°C Type: Isolation Amplifier Mounting Type: DIN Rail Output Type: Current, Voltage Packaging: Bag |
на замовлення 7 шт: термін постачання 21-31 дні (днів) |
|
| 857-401 |
|
Виробник: WAGO Corporation
Description: ISOLATION AMPLIFIER; CURRENT AND
Input Range (Additional): 0 ~ 100kOhm
Input Range (Current, Voltage): ±20mA, 0 ~ 30V (Configurable)
Output Range: 0 ~ 20mA, 0 ~ 10V (Configurable)
Isolation: 2500V (Test)
Input Type: Current, Voltage
Voltage - Supply: 24VDC
Termination Style: Spring Terminal
Operating Temperature: -25°C ~ 70°C
Type: Isolation Amplifier
Mounting Type: DIN Rail
Output Type: Current, Voltage
Packaging: Bag
Description: ISOLATION AMPLIFIER; CURRENT AND
Input Range (Additional): 0 ~ 100kOhm
Input Range (Current, Voltage): ±20mA, 0 ~ 30V (Configurable)
Output Range: 0 ~ 20mA, 0 ~ 10V (Configurable)
Isolation: 2500V (Test)
Input Type: Current, Voltage
Voltage - Supply: 24VDC
Termination Style: Spring Terminal
Operating Temperature: -25°C ~ 70°C
Type: Isolation Amplifier
Mounting Type: DIN Rail
Output Type: Current, Voltage
Packaging: Bag
на замовлення 7 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1+ | 29449.94 грн |
