BCS-132-L-D-HE Samtec
| Кількість | Ціна |
|---|---|
| 1+ | 817.91 грн |
| 12+ | 745.20 грн |
| 30+ | 613.09 грн |
| 54+ | 590.74 грн |
| 102+ | 572.59 грн |
Відгуки про товар
Написати відгук
Технічний опис BCS-132-L-D-HE Samtec
Description: CONN RCPT 64POS 0.1 GOLD PCB R/A, Number of Rows: 2, Row Spacing - Mating: 0.100" (2.54mm), Insulation Height: 0.210" (5.33mm), Contact Length - Post: 0.125" (3.18mm), Contact Finish - Post: Tin, Contact Finish Thickness - Mating: 10.0µin (0.25µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.100" (2.54mm), Insulation Color: Black, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Female Socket, Operating Temperature: -55°C ~ 125°C, Style: Board to Board, Number of Positions: 64, Mounting Type: Through Hole, Right Angle, Current Rating (Amps): 4.6A per Contact, Voltage Rating: 475VAC, Connector Type: Receptacle, Packaging: Tube.
Інші пропозиції BCS-132-L-D-HE за ціною від 520.80 грн до 953.67 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BCS-132-L-D-HE | Samtec Inc. |
 Description: CONN RCPT 64POS 0.1 GOLD PCB R/ANumber of Rows: 2 Row Spacing - Mating: 0.100" (2.54mm) Insulation Height: 0.210" (5.33mm) Contact Length - Post: 0.125" (3.18mm) Contact Finish - Post: Tin Contact Finish Thickness - Mating: 10.0µin (0.25µm) Contact Finish - Mating: Gold Pitch - Mating: 0.100" (2.54mm) Insulation Color: Black Material Flammability Rating: UL94 V-0 Termination: Solder Number of Positions Loaded: All Fastening Type: Push-Pull Contact Type: Female Socket Operating Temperature: -55°C ~ 125°C Style: Board to Board Number of Positions: 64 Mounting Type: Through Hole, Right Angle Current Rating (Amps): 4.6A per Contact Voltage Rating: 475VAC Connector Type: Receptacle Packaging: Tube |
на замовлення 1494 шт: термін постачання 21-31 дні (днів) |
|
| BCS-132-L-D-HE |
|
Виробник: Samtec Inc.
Description: CONN RCPT 64POS 0.1 GOLD PCB R/A
Number of Rows: 2
Row Spacing - Mating: 0.100" (2.54mm)
Insulation Height: 0.210" (5.33mm)
Contact Length - Post: 0.125" (3.18mm)
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.100" (2.54mm)
Insulation Color: Black
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Female Socket
Operating Temperature: -55°C ~ 125°C
Style: Board to Board
Number of Positions: 64
Mounting Type: Through Hole, Right Angle
Current Rating (Amps): 4.6A per Contact
Voltage Rating: 475VAC
Connector Type: Receptacle
Packaging: Tube
Description: CONN RCPT 64POS 0.1 GOLD PCB R/A
Number of Rows: 2
Row Spacing - Mating: 0.100" (2.54mm)
Insulation Height: 0.210" (5.33mm)
Contact Length - Post: 0.125" (3.18mm)
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.100" (2.54mm)
Insulation Color: Black
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Female Socket
Operating Temperature: -55°C ~ 125°C
Style: Board to Board
Number of Positions: 64
Mounting Type: Through Hole, Right Angle
Current Rating (Amps): 4.6A per Contact
Voltage Rating: 475VAC
Connector Type: Receptacle
Packaging: Tube
на замовлення 1494 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна |
|---|---|
| 1+ | 953.67 грн |
| 10+ | 813.65 грн |
| 100+ | 709.35 грн |
| 500+ | 567.79 грн |
| 1000+ | 520.80 грн |
