BXRC-30G4000-B-73 BRIDGELUX
Виробник: BRIDGELUX
Category: White power LEDs - COB
Description: Power LED; COB; 30.5W; 3000K; 3745lm; 120°; Front: flat; Ø36.2mm
Colour temperature: 3000K
Power: 30.5W
Luminosity: 3745lm
Viewing angle: 120°
Dimensions: Ø36.2mm
LED current: 900mA
Light source efficiency: 123lm/W
Operating voltage: 33.9V DC
LED version: COB
Manufacturer series: VERO® 18
Min. colour rendering index: 90
Type of diode: power LED
Shape: round
Storage temperature: -40...105°C
Binning: 3-STEP
Thermal resistance: 0.15K/W
Front: flat
Відгуки про товар
Написати відгук
Технічний опис BXRC-30G4000-B-73 BRIDGELUX
Description: LED COB VERO 18 WM WH RND 3000K, Features: With Connector, Packaging: Tray, Luminous Flux @ Current/Temperature: 3745lm (Typ), Temperature - Test: 85°C, Light Emitting Surface (LES): 18.40mm Dia, CRI (Color Rendering Index): 90, CCT (K): 3000K 3-Step MacAdam Ellipse, Lumens/Watt @ Current - Test: 123 lm/W, Current - Max: 1.8A, Lens Type: Flat, Current - Test: 900mA, Height: 1.90mm, Voltage - Forward (Vf) (Typ): 33.9V, Configuration: Round, Type: Chip On Board (COB), Size / Dimension: 36.20mm Dia, Color: White, Warm.
Інші пропозиції BXRC-30G4000-B-73 за ціною від 537.85 грн до 625.81 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BXRC-30G4000-B-73 | Bridgelux |
Description: LED COB VERO 18 WM WH RND 3000K Features: With Connector Packaging: Tray Luminous Flux @ Current/Temperature: 3745lm (Typ) Temperature - Test: 85°C Light Emitting Surface (LES): 18.40mm Dia CRI (Color Rendering Index): 90 CCT (K): 3000K 3-Step MacAdam Ellipse Lumens/Watt @ Current - Test: 123 lm/W Current - Max: 1.8A Lens Type: Flat Current - Test: 900mA Height: 1.90mm Voltage - Forward (Vf) (Typ): 33.9V Configuration: Round Type: Chip On Board (COB) Size / Dimension: 36.20mm Dia Color: White, Warm |
на замовлення 155 шт: термін постачання 21-31 дні (днів) |
|
| BXRC-30G4000-B-73 |
|
Виробник: Bridgelux
Description: LED COB VERO 18 WM WH RND 3000K
Features: With Connector
Packaging: Tray
Luminous Flux @ Current/Temperature: 3745lm (Typ)
Temperature - Test: 85°C
Light Emitting Surface (LES): 18.40mm Dia
CRI (Color Rendering Index): 90
CCT (K): 3000K 3-Step MacAdam Ellipse
Lumens/Watt @ Current - Test: 123 lm/W
Current - Max: 1.8A
Lens Type: Flat
Current - Test: 900mA
Height: 1.90mm
Voltage - Forward (Vf) (Typ): 33.9V
Configuration: Round
Type: Chip On Board (COB)
Size / Dimension: 36.20mm Dia
Color: White, Warm
Description: LED COB VERO 18 WM WH RND 3000K
Features: With Connector
Packaging: Tray
Luminous Flux @ Current/Temperature: 3745lm (Typ)
Temperature - Test: 85°C
Light Emitting Surface (LES): 18.40mm Dia
CRI (Color Rendering Index): 90
CCT (K): 3000K 3-Step MacAdam Ellipse
Lumens/Watt @ Current - Test: 123 lm/W
Current - Max: 1.8A
Lens Type: Flat
Current - Test: 900mA
Height: 1.90mm
Voltage - Forward (Vf) (Typ): 33.9V
Configuration: Round
Type: Chip On Board (COB)
Size / Dimension: 36.20mm Dia
Color: White, Warm
на замовлення 155 шт:
термін постачання 21-31 дні (днів)| Кількість | Ціна |
|---|---|
| 1+ | 625.81 грн |
| 50+ | 580.87 грн |
| 100+ | 537.85 грн |
