BXRE-40E6500-B-83 BRIDGELUX
Виробник: BRIDGELUX
Category: White power LEDs - COB
Description: Power LED; COB; 46.8W; 4000K; 8044lm; 120°; Front: flat; CRImin: 80
Type of diode: power LED
LED version: COB
Power: 46.8W
Colour temperature: 4000K
Luminosity: 8044lm
Viewing angle: 120°
Front: flat
Dimensions: 28x28x1.65mm
Min. colour rendering index: 80
LED current: 950mA
Operating voltage: 49.2V DC
Manufacturer series: V22
Binning: 3SDCM
Thermal resistance: 0.07K/W
Light source efficiency: 172lm/W
Storage temperature: -40...105°C
Відгуки про товар
Написати відгук
Технічний опис BXRE-40E6500-B-83 BRIDGELUX
Description: V22B NEUTRAL WHITE LED ARRAY, Packaging: Tube, Color: White, Neutral, Size / Dimension: 28.00mm L x 28.00mm W, Type: Chip On Board (COB), Configuration: Square, Voltage - Forward (Vf) (Typ): 50.2V, Height: 1.65mm, Current - Test: 950mA, Viewing Angle: 120°, Lens Type: Flat, Current - Max: 3.5A, Lumens/Watt @ Current - Test: 187 lm/W, CCT (K): 4000K 3-Step MacAdam Ellipse, CRI (Color Rendering Index): 80, Light Emitting Surface (LES): 23.30mm Dia, Temperature - Test: 25°C, Luminous Flux @ Current/Temperature: 8937lm (Typ).
Інші пропозиції BXRE-40E6500-B-83
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
|---|---|---|---|---|---|
| BXRE-40E6500-B-83 | Виробник : Bridgelux |
Description: V22B NEUTRAL WHITE LED ARRAY Packaging: Tube Color: White, Neutral Size / Dimension: 28.00mm L x 28.00mm W Type: Chip On Board (COB) Configuration: Square Voltage - Forward (Vf) (Typ): 50.2V Height: 1.65mm Current - Test: 950mA Viewing Angle: 120° Lens Type: Flat Current - Max: 3.5A Lumens/Watt @ Current - Test: 187 lm/W CCT (K): 4000K 3-Step MacAdam Ellipse CRI (Color Rendering Index): 80 Light Emitting Surface (LES): 23.30mm Dia Temperature - Test: 25°C Luminous Flux @ Current/Temperature: 8937lm (Typ) |
товару немає в наявності |
