BXRH-30S1001-B-73 BRIDGELUX
Виробник: BRIDGELUX
Category: White power LEDs - COB
Description: Power LED; COB; 12.4W; 3000K; 1101lm; 120°; Front: flat; 350mA
Type of diode: power LED
LED version: COB
Power: 12.4W
Colour temperature: 3000K
Luminosity: 1101lm
Viewing angle: 120°
Front: flat
LED current: 350mA
Min. colour rendering index: 98
Dimensions: 13.5x13.5x1.65mm
Operating voltage: 35.4V DC
Manufacturer series: Thrive
Binning: 3SDCM
Light source efficiency: 89lm/W
Thermal resistance: 0.36K/W
Storage temperature: -40...105°C
| Кількість | Ціна без ПДВ |
|---|---|
| 3+ | 172.30 грн |
| 5+ | 141.37 грн |
| 25+ | 122.74 грн |
| 105+ | 115.13 грн |
Відгуки про товар
Написати відгук
Технічний опис BXRH-30S1001-B-73 BRIDGELUX
Description: LED COB V6HD THRIVE WH SQ 3000K, Part Status: Active, Luminous Flux @ Current/Temperature: 1223lm (Typ), Temperature - Test: 25°C, Light Emitting Surface (LES): 6.60mm Dia, CRI (Color Rendering Index): 98 (Typ), CCT (K): 3000K 3-Step MacAdam Ellipse, Lumens/Watt @ Current - Test: 96 lm/W, Current - Max: 480mA, Lens Type: Flat, Viewing Angle: 120°, Current - Test: 350mA, Height: 1.63mm, Voltage - Forward (Vf) (Typ): 36.4V, Configuration: Square, Type: Chip On Board (COB), Size / Dimension: 13.50mm L x 13.50mm W, Color: White, Warm, Packaging: Tube.
Інші пропозиції BXRH-30S1001-B-73 за ціною від 129.33 грн до 279.28 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна без ПДВ | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BXRH-30S1001-B-73 | Bridgelux |
Description: LED COB V6HD THRIVE WH SQ 3000K Part Status: Active Luminous Flux @ Current/Temperature: 1223lm (Typ) Temperature - Test: 25°C Light Emitting Surface (LES): 6.60mm Dia CRI (Color Rendering Index): 98 (Typ) CCT (K): 3000K 3-Step MacAdam Ellipse Lumens/Watt @ Current - Test: 96 lm/W Current - Max: 480mA Lens Type: Flat Viewing Angle: 120° Current - Test: 350mA Height: 1.63mm Voltage - Forward (Vf) (Typ): 36.4V Configuration: Square Type: Chip On Board (COB) Size / Dimension: 13.50mm L x 13.50mm W Color: White, Warm Packaging: Tube |
на замовлення 760 шт: термін постачання 21-31 дні (днів) |
|
| BXRH-30S1001-B-73 |
|
Виробник: Bridgelux
Description: LED COB V6HD THRIVE WH SQ 3000K
Part Status: Active
Luminous Flux @ Current/Temperature: 1223lm (Typ)
Temperature - Test: 25°C
Light Emitting Surface (LES): 6.60mm Dia
CRI (Color Rendering Index): 98 (Typ)
CCT (K): 3000K 3-Step MacAdam Ellipse
Lumens/Watt @ Current - Test: 96 lm/W
Current - Max: 480mA
Lens Type: Flat
Viewing Angle: 120°
Current - Test: 350mA
Height: 1.63mm
Voltage - Forward (Vf) (Typ): 36.4V
Configuration: Square
Type: Chip On Board (COB)
Size / Dimension: 13.50mm L x 13.50mm W
Color: White, Warm
Packaging: Tube
Description: LED COB V6HD THRIVE WH SQ 3000K
Part Status: Active
Luminous Flux @ Current/Temperature: 1223lm (Typ)
Temperature - Test: 25°C
Light Emitting Surface (LES): 6.60mm Dia
CRI (Color Rendering Index): 98 (Typ)
CCT (K): 3000K 3-Step MacAdam Ellipse
Lumens/Watt @ Current - Test: 96 lm/W
Current - Max: 480mA
Lens Type: Flat
Viewing Angle: 120°
Current - Test: 350mA
Height: 1.63mm
Voltage - Forward (Vf) (Typ): 36.4V
Configuration: Square
Type: Chip On Board (COB)
Size / Dimension: 13.50mm L x 13.50mm W
Color: White, Warm
Packaging: Tube
на замовлення 760 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 2+ | 279.28 грн |
| 10+ | 198.24 грн |
| 100+ | 156.23 грн |
| 500+ | 129.33 грн |
