C4AQGBW5500P3JK KEMET
Виробник: KEMET
Description: CAP FILM 50UF 10% 450VDC RADIAL
Packaging: Bulk
Tolerance: ±10%
Features: Long Life, Low ESL
Package / Case: Radial - 4 Leads
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 125°C
Applications: Automotive; DC Link, DC Filtering
Lead Spacing: 1.476" (37.50mm)
Termination: PC Pins
Ratings: AEC-Q200
Dielectric Material: Polypropylene (PP), Metallized
Voltage Rating - DC: 450V
Height - Seated (Max): 1.465" (37.20mm)
Part Status: Active
Capacitance: 50 µF
ESR (Equivalent Series Resistance): 3.1 mOhms
Size / Dimension: 1.654" L x 1.102" W (42.00mm x 28.00mm)
Відгуки про товар
Написати відгук
Технічний опис C4AQGBW5500P3JK KEMET
Description: CAP FILM 50UF 10% 450VDC RADIAL, Packaging: Bulk, Tolerance: ±10%, Features: Long Life, Low ESL, Package / Case: Radial - 4 Leads, Mounting Type: Through Hole, Operating Temperature: -55°C ~ 125°C, Applications: Automotive; DC Link, DC Filtering, Lead Spacing: 1.476" (37.50mm), Termination: PC Pins, Ratings: AEC-Q200, Dielectric Material: Polypropylene (PP), Metallized, Voltage Rating - DC: 450V, Height - Seated (Max): 1.465" (37.20mm), Part Status: Active, Capacitance: 50 µF, ESR (Equivalent Series Resistance): 3.1 mOhms, Size / Dimension: 1.654" L x 1.102" W (42.00mm x 28.00mm).
Інші пропозиції C4AQGBW5500P3JK за ціною від 523.01 грн до 937.67 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
C4AQGBW5500P3JK | KEMET |
Category: THT Film Capacitors Description: Capacitor: polypropylene; DC-Link; 50uF; Uoper: 450VDC; 22.8A; THT Manufacturer series: C4AQ-P Kind of capacitor: DC-Link Type of capacitor: polypropylene Mounting: THT Operating temperature: -55...125°C Capacitance: 50µF ESR value: 3.1mΩ Terminal pitch: 37.5mm Body dimensions: 42x37x28mm Tolerance: ±10% Pulse resistance: 30V/μs Max. operating current: 22.8A Operating voltage: 450V DC Max. operating voltage: 450V DC Climate class: 55/105/56; IEC 60068-1 Conform to the norm: AEC-Q200 |
на замовлення 1 шт: термін постачання 14-30 дні (днів) |
|
||||||||||
 |
C4AQGBW5500P3JK | KEMET |
Film Capacitors 450V 50 uF 125C 10% 4 Pin LS=37.5 mm AEC-Q200 |
на замовлення 44 шт: термін постачання 21-30 дні (днів) |
|
| C4AQGBW5500P3JK |
|
Виробник: KEMET
Category: THT Film Capacitors
Description: Capacitor: polypropylene; DC-Link; 50uF; Uoper: 450VDC; 22.8A; THT
Manufacturer series: C4AQ-P
Kind of capacitor: DC-Link
Type of capacitor: polypropylene
Mounting: THT
Operating temperature: -55...125°C
Capacitance: 50µF
ESR value: 3.1mΩ
Terminal pitch: 37.5mm
Body dimensions: 42x37x28mm
Tolerance: ±10%
Pulse resistance: 30V/μs
Max. operating current: 22.8A
Operating voltage: 450V DC
Max. operating voltage: 450V DC
Climate class: 55/105/56; IEC 60068-1
Conform to the norm: AEC-Q200
Category: THT Film Capacitors
Description: Capacitor: polypropylene; DC-Link; 50uF; Uoper: 450VDC; 22.8A; THT
Manufacturer series: C4AQ-P
Kind of capacitor: DC-Link
Type of capacitor: polypropylene
Mounting: THT
Operating temperature: -55...125°C
Capacitance: 50µF
ESR value: 3.1mΩ
Terminal pitch: 37.5mm
Body dimensions: 42x37x28mm
Tolerance: ±10%
Pulse resistance: 30V/μs
Max. operating current: 22.8A
Operating voltage: 450V DC
Max. operating voltage: 450V DC
Climate class: 55/105/56; IEC 60068-1
Conform to the norm: AEC-Q200
на замовлення 1 шт:
термін постачання 14-30 дні (днів)
| Кількість | Ціна |
|---|---|
| 1+ | 906.08 грн |
| C4AQGBW5500P3JK |
|
Виробник: KEMET
Film Capacitors 450V 50 uF 125C 10% 4 Pin LS=37.5 mm AEC-Q200
Film Capacitors 450V 50 uF 125C 10% 4 Pin LS=37.5 mm AEC-Q200
на замовлення 44 шт:
термін постачання 21-30 дні (днів)
| Кількість | Ціна |
|---|---|
| 1+ | 937.67 грн |
| 10+ | 644.82 грн |
| 36+ | 560.02 грн |
| 108+ | 523.71 грн |
| 1008+ | 523.01 грн |
