CLP-108-02-F-D-K-TR Samtec Inc.
Виробник: Samtec Inc.
Description: CONN RCPT 16POS 0.05 GOLD SMD
Number of Rows: 2
Row Spacing - Mating: 0.050" (1.27mm)
Insulation Height: 0.084" (2.14mm)
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 3.00µin (0.076µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.050" (1.27mm)
Insulation Color: Black
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Female Socket
Operating Temperature: -55°C ~ 125°C
Style: Board to Board
Number of Positions: 16
Mounting Type: Surface Mount
Current Rating (Amps): 3.3A per Contact
Voltage Rating: 240VAC, 330VDC
Connector Type: Receptacle
Features: Pick and Place
Packaging: Tape & Reel (TR)
Відгуки про товар
Написати відгук
Технічний опис CLP-108-02-F-D-K-TR Samtec Inc.
Description: CONN RCPT 16POS 0.05 GOLD SMD, Number of Rows: 2, Row Spacing - Mating: 0.050" (1.27mm), Insulation Height: 0.084" (2.14mm), Contact Finish - Post: Tin, Contact Finish Thickness - Mating: 3.00µin (0.076µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.050" (1.27mm), Insulation Color: Black, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Female Socket, Operating Temperature: -55°C ~ 125°C, Style: Board to Board, Number of Positions: 16, Mounting Type: Surface Mount, Current Rating (Amps): 3.3A per Contact, Voltage Rating: 240VAC, 330VDC, Connector Type: Receptacle, Features: Pick and Place, Packaging: Tape & Reel (TR).
Інші пропозиції CLP-108-02-F-D-K-TR за ціною від 98.72 грн до 240.81 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна |
||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
CLP-108-02-F-D-K-TR | Samtec Inc. |
Description: CONN RCPT 16POS 0.05 GOLD SMD Number of Rows: 2 Row Spacing - Mating: 0.050" (1.27mm) Insulation Height: 0.084" (2.14mm) Contact Finish - Post: Tin Contact Finish Thickness - Mating: 3.00µin (0.076µm) Contact Finish - Mating: Gold Pitch - Mating: 0.050" (1.27mm) Insulation Color: Black Material Flammability Rating: UL94 V-0 Termination: Solder Number of Positions Loaded: All Fastening Type: Push-Pull Contact Type: Female Socket Operating Temperature: -55°C ~ 125°C Style: Board to Board Number of Positions: 16 Mounting Type: Surface Mount Current Rating (Amps): 3.3A per Contact Voltage Rating: 240VAC, 330VDC Connector Type: Receptacle Features: Pick and Place Packaging: Cut Tape (CT) |
на замовлення 2373 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||
 |
CLP-108-02-F-D-K-TR | Samtec |
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch |
на замовлення 1223 шт: термін постачання 21-30 дні (днів) |
|
| CLP-108-02-F-D-K-TR |
|
Виробник: Samtec Inc.
Description: CONN RCPT 16POS 0.05 GOLD SMD
Number of Rows: 2
Row Spacing - Mating: 0.050" (1.27mm)
Insulation Height: 0.084" (2.14mm)
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 3.00µin (0.076µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.050" (1.27mm)
Insulation Color: Black
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Female Socket
Operating Temperature: -55°C ~ 125°C
Style: Board to Board
Number of Positions: 16
Mounting Type: Surface Mount
Current Rating (Amps): 3.3A per Contact
Voltage Rating: 240VAC, 330VDC
Connector Type: Receptacle
Features: Pick and Place
Packaging: Cut Tape (CT)
Description: CONN RCPT 16POS 0.05 GOLD SMD
Number of Rows: 2
Row Spacing - Mating: 0.050" (1.27mm)
Insulation Height: 0.084" (2.14mm)
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 3.00µin (0.076µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.050" (1.27mm)
Insulation Color: Black
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Female Socket
Operating Temperature: -55°C ~ 125°C
Style: Board to Board
Number of Positions: 16
Mounting Type: Surface Mount
Current Rating (Amps): 3.3A per Contact
Voltage Rating: 240VAC, 330VDC
Connector Type: Receptacle
Features: Pick and Place
Packaging: Cut Tape (CT)
на замовлення 2373 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна |
|---|---|
| 2+ | 229.11 грн |
| 10+ | 200.80 грн |
| 100+ | 176.89 грн |
| 500+ | 141.11 грн |
| CLP-108-02-F-D-K-TR |
|
Виробник: Samtec
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
Headers & Wire Housings Low Profile Dual-Wipe Socket, .050" Pitch
на замовлення 1223 шт:
термін постачання 21-30 дні (днів)
| Кількість | Ціна |
|---|---|
| 2+ | 240.81 грн |
| 50+ | 200.85 грн |
| 100+ | 146.35 грн |
| 500+ | 119.43 грн |
| 1200+ | 104.24 грн |
| 2400+ | 98.72 грн |
