Продукція > SUNON > EF50151BX-1B00U-A99
EF50151BX-1B00U-A99

EF50151BX-1B00U-A99 SUNON


pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960C2933660C7&compId=Product%2011.pdf?ci_sign=809b2ed67f97b20df0d8e4cef9e98e065ea96499 Виробник: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 9.17m3/h; 45.8dBA; ball
Enclosure material: thermoplastic
Current rating: 0.15A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 9.17m3/h
Noise level: 45.8dBA
Rotational rate/speed: 6200rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.8W
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
на замовлення 25 шт:

термін постачання 21-30 дні (днів)
Кількість Ціна
1+948.25 грн
10+837.60 грн
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис EF50151BX-1B00U-A99 SUNON

Category: DC12V Fans, Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 9.17m3/h; 45.8dBA; ball, Enclosure material: thermoplastic, Current rating: 0.15A, Supply voltage: 12V DC, Leads: leads x2, Operating voltage: 4.5...13.8V DC, Type of fan: DC, Fan dimensions: 51.6x51.7x15mm, Fan motor: brushless DC, Impeller material: thermoplastic, Flammability rating: UL94V-0, Insulation class: A, Kind of Bearing: ball, Fan efficiency: 9.17m3/h, Noise level: 45.8dBA, Rotational rate/speed: 6200rpm, Current and power consumption tolerance: ±15%, Power consumption: 1.8W, Lead length: 0.305m, Additional functions: autorestart, Kind of fan: blower, Min. insulation resistance: 10MΩ, Operating temperature: -10...70°C, кількість в упаковці: 1 шт.

Інші пропозиції EF50151BX-1B00U-A99 за ціною від 926.96 грн до 1660.80 грн

Фото Назва Виробник Інформація Доступність
Ціна
EF50151BX-1B00U-A99 EF50151BX-1B00U-A99 Виробник : SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960C2933660C7&compId=Product%2011.pdf?ci_sign=809b2ed67f97b20df0d8e4cef9e98e065ea96499 Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 9.17m3/h; 45.8dBA; ball
Enclosure material: thermoplastic
Current rating: 0.15A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 9.17m3/h
Noise level: 45.8dBA
Rotational rate/speed: 6200rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.8W
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
кількість в упаковці: 1 шт
на замовлення 25 шт:
термін постачання 14-21 дні (днів)
Кількість Ціна
1+1137.90 грн
10+1043.78 грн
50+926.96 грн
В кошику  од. на суму  грн.
EF50151BX-1B00U-A99 EF50151BX-1B00U-A99 Виробник : Sunon Fans Sunon%20DC%20Brushless%20Fan%20&%20Blower_(240-E).pdf Description: Thermal Products
Packaging: Bulk
Part Status: Active
Features: Auto Restart
Voltage - Rated: 12VDC
Size / Dimension: Rectangular/Rounded - 51.7mm L x 51.6mm H
Bearing Type: Ball
RPM: 6200 RPM
Air Flow: 5.4 CFM (0.151m³/min)
Width: 15.00mm
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Blower
Noise: 45.8dB(A)
Static Pressure: 0.970 in H2O (241.6 Pa)
Power (Watts): 1.8 W
на замовлення 3308 шт:
термін постачання 21-31 дні (днів)
Кількість Ціна
1+1588.44 грн
10+1253.80 грн
25+1149.41 грн
50+1008.23 грн
156+990.07 грн
В кошику  од. на суму  грн.
EF50151BX-1B00U-A99 EF50151BX-1B00U-A99 Виробник : Sunon Sunon_10192108_EF50151BX_1B00U_A99-1488843.pdf Blowers & Centrifugal Fans Blower, 50x50x15mm, 12VDC, 5.4CFM, 0.97"H2O, Ball, Wire, Auto Restart
на замовлення 208 шт:
термін постачання 21-30 дні (днів)
Кількість Ціна
1+1660.80 грн
10+1405.26 грн
25+1054.97 грн
50+1027.75 грн
В кошику  од. на суму  грн.
