ETQ-P3M3R3YFP Panasonic Electronic Components
Виробник: Panasonic Electronic Components
Description: FIXED IND 3.3UH 5A 34.4 MOHM SMD
Packaging: Tape & Reel (TR)
Tolerance: ±20%
Package / Case: 2-SMD, J-Lead
Size / Dimension: 0.217" L x 0.197" W (5.50mm x 5.00mm)
Mounting Type: Surface Mount
Shielding: Shielded
Type: Drum Core, Wirewound
Operating Temperature: -40°C ~ 150°C
DC Resistance (DCR): 34.4mOhm Max
Ratings: AEC-Q200
Current - Saturation (Isat): 8.6A
Material - Core: Metal Composite
Inductance Frequency - Test: 100 kHz
Height - Seated (Max): 0.118" (3.00mm)
Inductance: 3.3 µH
Current Rating (Amps): 5 A
Description: FIXED IND 3.3UH 5A 34.4 MOHM SMD
Packaging: Tape & Reel (TR)
Tolerance: ±20%
Package / Case: 2-SMD, J-Lead
Size / Dimension: 0.217" L x 0.197" W (5.50mm x 5.00mm)
Mounting Type: Surface Mount
Shielding: Shielded
Type: Drum Core, Wirewound
Operating Temperature: -40°C ~ 150°C
DC Resistance (DCR): 34.4mOhm Max
Ratings: AEC-Q200
Current - Saturation (Isat): 8.6A
Material - Core: Metal Composite
Inductance Frequency - Test: 100 kHz
Height - Seated (Max): 0.118" (3.00mm)
Inductance: 3.3 µH
Current Rating (Amps): 5 A
на замовлення 3000 шт:
термін постачання 21-31 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
1000+ | 41.1 грн |
3000+ | 38.3 грн |
Відгуки про товар
Написати відгук
Технічний опис ETQ-P3M3R3YFP Panasonic Electronic Components
Description: FIXED IND 3.3UH 5A 34.4 MOHM SMD, Packaging: Tape & Reel (TR), Tolerance: ±20%, Package / Case: 2-SMD, J-Lead, Size / Dimension: 0.217" L x 0.197" W (5.50mm x 5.00mm), Mounting Type: Surface Mount, Shielding: Shielded, Type: Drum Core, Wirewound, Operating Temperature: -40°C ~ 150°C, DC Resistance (DCR): 34.4mOhm Max, Ratings: AEC-Q200, Current - Saturation (Isat): 8.6A, Material - Core: Metal Composite, Inductance Frequency - Test: 100 kHz, Height - Seated (Max): 0.118" (3.00mm), Inductance: 3.3 µH, Current Rating (Amps): 5 A.
Інші пропозиції ETQ-P3M3R3YFP за ціною від 34.38 грн до 95.02 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ETQ-P3M3R3YFP | Виробник : Panasonic Electronic Components |
Description: FIXED IND 3.3UH 5A 34.4 MOHM SMD Packaging: Cut Tape (CT) Tolerance: ±20% Package / Case: 2-SMD, J-Lead Size / Dimension: 0.217" L x 0.197" W (5.50mm x 5.00mm) Mounting Type: Surface Mount Shielding: Shielded Type: Drum Core, Wirewound Operating Temperature: -40°C ~ 150°C DC Resistance (DCR): 34.4mOhm Max Ratings: AEC-Q200 Current - Saturation (Isat): 8.6A Material - Core: Metal Composite Inductance Frequency - Test: 100 kHz Height - Seated (Max): 0.118" (3.00mm) Inductance: 3.3 µH Current Rating (Amps): 5 A |
на замовлення 3055 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||||||
ETQ-P3M3R3YFP | Виробник : Panasonic | Power Inductors - SMD PCC 3.3uH AEC-Q200 |
на замовлення 11 шт: термін постачання 21-30 дні (днів) |
|
|||||||||||||||||
ETQP3M3R3YFP | Виробник : PANASONIC |
Category: SMD power inductors Description: Inductor: wire; SMD; 3.3uH; 8.6A; 31.3mΩ; ±20%; 5.5x5x3mm; -40÷150°C Type of inductor: wire Mounting: SMD Inductance: 3.3µH Operating current: 8.6A Resistance: 31.3mΩ Tolerance: ±20% Body dimensions: 5.5x5x3mm Operating temperature: -40...150°C Manufacturer series: ETQP3M Conform to the norm: AEC Q200 кількість в упаковці: 1 шт |
товар відсутній |
||||||||||||||||||
ETQP3M3R3YFP | Виробник : PANASONIC |
Category: SMD power inductors Description: Inductor: wire; SMD; 3.3uH; 8.6A; 31.3mΩ; ±20%; 5.5x5x3mm; -40÷150°C Type of inductor: wire Mounting: SMD Inductance: 3.3µH Operating current: 8.6A Resistance: 31.3mΩ Tolerance: ±20% Body dimensions: 5.5x5x3mm Operating temperature: -40...150°C Manufacturer series: ETQP3M Conform to the norm: AEC Q200 |
товар відсутній |
