FKP1T003304B00JSSD WIMA
Виробник: WIMA
Description: FKP 1 330 PF 1600 VDC 5X11X18 PC
Tolerance: ±5%
Packaging: Bulk
Package / Case: Radial
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 105°C
Applications: Automotive; High Frequency, Switching; High Pulse, DV/DT
Lead Spacing: 0.591" (15.00mm)
Termination: PC Pins
Ratings: AEC-Q200
Dielectric Material: Polypropylene (PP), Metallized
Voltage Rating - AC: 650V
Voltage Rating - DC: 1600V (1.6kV)
Height - Seated (Max): 0.433" (11.00mm)
Capacitance: 330 pF
Size / Dimension: 0.709" L x 0.197" W (18.00mm x 5.00mm)
Відгуки про товар
Написати відгук
Технічний опис FKP1T003304B00JSSD WIMA
Category: THT Film Capacitors, Description: Capacitor: polypropylene; 330pF; Uoper: 1.6kVDC; 650VAC; 5x11x18mm, Capacitor application: for high current applications; high frequency circuits; impulse circuits, Kind of material: flame retardant, Capacitors features: low dielectric loss factor; self-healing feature, Type of capacitor: polypropylene, Mounting: THT, Flammability rating: UL94V-0, Operating temperature: -55...100°C, Capacitance: 0.33nF, Body dimensions: 5x11x18mm, Terminal pitch: 15mm, Tolerance: ±5%, Pulse resistance: 51kV/μs, Max. operating voltage: 650V AC; 1.6kV DC, Operating voltage: 1.6kV DC, Climate class: 55/100/56.
Інші пропозиції FKP1T003304B00JSSD
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
|---|---|---|---|---|---|
 |
FKP1T003304B00JSSD | Виробник : WIMA |
Film Capacitors 330pF 1.6KV 5% |
товару немає в наявності |
|
 |
FKP1T003304B00JSSD | Виробник : WIMA |
Category: THT Film Capacitors Description: Capacitor: polypropylene; 330pF; Uoper: 1.6kVDC; 650VAC; 5x11x18mm Capacitor application: for high current applications; high frequency circuits; impulse circuits Kind of material: flame retardant Capacitors features: low dielectric loss factor; self-healing feature Type of capacitor: polypropylene Mounting: THT Flammability rating: UL94V-0 Operating temperature: -55...100°C Capacitance: 0.33nF Body dimensions: 5x11x18mm Terminal pitch: 15mm Tolerance: ±5% Pulse resistance: 51kV/μs Max. operating voltage: 650V AC; 1.6kV DC Operating voltage: 1.6kV DC Climate class: 55/100/56 |
товару немає в наявності |
