FLUKE-289/EUR
Виробник: FLUKECategory: Portable digital multimeters
Description: Digital multimeter; colour,LCD TFT 2,2"; (50000); 320x240; IP54
Power supply: battery LR6 AA 1,5V x6
IP rating: IP54
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Measurement memory: 10k
Display resolution: 320x240
Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-5899A; POM-6173A; POM-7519A
Standard equipment: FLK-TL175 test leads; holder for probes
Measuring instrument features: HOLD function; information pushbutton activating the built-in help; low input impedance function (LoZ); low-pass filter for measuring drive parameters; low resistance measuring range (50Ω) for measuring motor windings resistance; MIN/MAX/MEDIUM function; possibility of displaying many readouts on single screen; quick registration of MIN/MAX values (250µs); TrendCapture data registration function
Type of meter: digital multimeter
Weight with battery: 871g
Optional equipment: FLK-C781 soft cover; FLK-IR3000FC; FLK-TLK287 accessory set; FLK-TLK289 accessory set
Continuity test: acoustic indication
Duty cycle factor: 1...99%
Duty cycle factor measurement accuracy: 0,2% per kHz + 0,1%
Pollution degree: 2
Temperature measurement resolution: 0.1°C
Conductance measurement: 10000000...50nS
Temperature measuring range: -200...1350°C
Manufacturer series: FOX
True effective value measurement: True RMS AC; True RMS AC+DC
Bargraph: 51 segm.
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Dimensions (W x H x D): 102x222x60mm
AC current measuring range: 0.01...500µA; 5mA; 50mA; 400mA; 5A; 10A; (20A <30s)
Resistance measuring range: 1mΩ...50Ω; 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ; 30MΩ; 50MΩ; 100MΩ; 500MΩ
DC current measuring range: 10nA...500µA; 5mA; 50mA; 400mA; 5A; 10A; 20A < 30s
DC voltage measuring range: 0.1µV...50mV; 500mV; 5V; 50V; 500V; 1kV
AC voltage measuring range: 0.1µV...50mV; 500mV; 5V; 50V; 500V; 1kV
Frequency measuring range: 1...99999mHz; 999.99Hz; 9.9999kHz; 99.999kHz; 999.99kHz
Capacitance measuring range: 1pF...1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF; 100mF
Diode test: 1mA @3.1V
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Software: Fluke Connect (FLK-IR3000FC)
Display parameters: (50000)
Frequency measuring accuracy: ±(0.005%+5 digit)
Capacitance measuring accuracy: ±(1%+ 5 digit)
AC current measuring accuracy: ±(0.6% + 5 digit)
DC voltage measuring accuracy: ±(0.025% + 2 digit)
DC current measuring accuracy: ±(0.15% + 2 digit)
AC voltage measuring accuracy: ±(0.4% + 20 digit)
Conductance measuring accuracy: ±(1% + 10digit)
Resistance measuring accuracy: ±(0.05%+2 digit)
Temperature measurement accuracy: ±(1% + 1°C)
Kind of display used: colour; LCD TFT 2,2"
на замовлення 27 шт:
термін постачання 21-30 дні (днів)
| Кількість | Ціна |
|---|---|
| 1+ | 72659.94 грн |
Відгуки про товар
Написати відгук
Технічний опис FLUKE-289/EUR FLUKE
Category: Portable digital multimeters, Description: Digital multimeter; colour,LCD TFT 2,2"; (50000); 320x240; IP54, Power supply: battery LR6 AA 1,5V x6, IP rating: IP54, Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010, Measurement memory: 10k, Display resolution: 320x240, Related items: FLK-80BK-A; FLK-80PJ-1; FLK-80PJ-9; FLK-80PJ-EXT; FLK-80PK-1; FLK-80PK-3A; FLK-80PK-8; FLK-80PK-9; FLK-80PK-11; FLK-80PK-22; FLK-80PK-24; FLK-80PK-25; FLK-80PK-26; FLK-80PK-27; FLK-80PR-60; FLK-80PT-EXT; FLK-80T-150UA; POM-5899A; POM-6173A; POM-7519A, Standard equipment: FLK-TL175 test leads; holder for probes, Measuring instrument features: HOLD function; information pushbutton activating the built-in help; low input impedance function (LoZ); low-pass filter for measuring drive parameters; low resistance measuring range (50Ω) for measuring motor windings resistance; MIN/MAX/MEDIUM function; possibility of displaying many readouts on single screen; quick registration of MIN/MAX values (250µs); TrendCapture data registration function, Type of meter: digital multimeter, Weight with battery: 871g, Optional equipment: FLK-C781 soft cover; FLK-IR3000FC; FLK-TLK287 accessory set; FLK-TLK289 accessory set, Continuity test: acoustic indication, Duty cycle factor: 1...99%, Duty cycle factor measurement accuracy: 0,2% per kHz + 0,1%, Pollution degree: 2, Temperature measurement resolution: 0.1°C, Conductance measurement: 10000000...50nS, Temperature measuring range: -200...1350°C, Manufacturer series: FOX, True effective value measurement: True RMS AC; True RMS AC+DC, Bargraph: 51 segm., Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; duty cycle; frequency; resistance; temperature, Dimensions (W x H x D): 102x222x60mm, AC current measuring range: 0.01...500µA; 5mA; 50mA; 400mA; 5A; 10A; (20A .
Інші пропозиції FLUKE-289/EUR за ціною від 79283.35 грн до 99758.43 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
FLUKE 289/EUR | Виробник : FLUKE |
Description: FLUKE - FLUKE 289/EUR - Multimeter, Industrie, Fluke 289, 50000 Zählwerte, TRMS, autom./manuelle Bereichswahl, 4.5-stellig tariffCode: 90303100 Messwert Gleichspannung, max.: 1kV Messwert Wechselspannung, max.: 1kV Messwert Widerstand, max.: 500Mohm Messwert Gleichstrom, max.: 10A rohsCompliant: YES hazardous: false rohsPhthalatesCompliant: TBA usEccn: 3A992.a Schritte: 50000 Herstellergewährleistung: Lebenslang euEccn: NLR Anzahl der Stellen: 4.8 DMM-Messverfahren: Echteffektivwert DMM-Funktionen: AC/DC-Strom, AC/DC-Spannung, Kapazität, Durchgang, Diode, Frequenz, Widerstand, Temperatur Produktpalette: 0 productTraceability: No Messwert Wechselstrom, max.: 10A Bereichswahl: Automatisch, manuell SVHC: No SVHC (15-Jun-2015) |
на замовлення 19 шт: термін постачання 21-31 дні (днів) |
|
||||||||
| FLUKE 289/EUR | Виробник : Fluke | True-Rms Industrial Logging Multimeter with Trend Capture |
на замовлення 3 шт: термін постачання 21-31 дні (днів) |
|
