FTSH-109-01-F-DH Samtec

Name: FTSH-109-01-F-DH
Brand: Samtec
SKU: 3932751-4
Price: 672.9 UAH
Availability: InStock

Виробник: Samtec
Headers & Wire Housings High Reliability Header Strips, .050" pitch

на замовлення 116 шт:

термін постачання 21-30 дні (днів)

Кількість	Ціна
2+	336.45 грн
50+	271.58 грн
100+	200.11 грн
500+	178.04 грн
1000+	172.15 грн

Мінімальне замовлення: 2

В кошику од. на суму грн.

Відгуки про товар

Написати відгук

Технічний опис FTSH-109-01-F-DH Samtec

Description: CONN HEADER SMD R/A 18POS 1.27MM, Packaging: Bulk, Connector Type: Header, Cuttable, Current Rating (Amps): 3.4A per Contact, Mounting Type: Surface Mount, Right Angle, Number of Positions: 18, Number of Rows: 2, Style: Board to Board or Cable, Operating Temperature: -55°C ~ 125°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.050" (1.27mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 3.00µin (0.076µm), Contact Finish - Post: Tin, Contact Shape: Square, Insulation Height: 0.135" (3.43mm), Shrouding: Unshrouded, Insulation Material: Liquid Crystal Polymer (LCP), Row Spacing - Mating: 0.050" (1.27mm), Contact Length - Mating: 0.120" (3.05mm).

Інші пропозиції FTSH-109-01-F-DH

Фото	Назва	Виробник	Інформація	Доступність	Ціна
	FTSH-109-01-F-DH	Виробник : Samtec Inc.	Description: CONN HEADER SMD R/A 18POS 1.27MM Packaging: Bulk Connector Type: Header, Cuttable Current Rating (Amps): 3.4A per Contact Mounting Type: Surface Mount, Right Angle Number of Positions: 18 Number of Rows: 2 Style: Board to Board or Cable Operating Temperature: -55°C ~ 125°C Contact Type: Male Pin Fastening Type: Push-Pull Number of Positions Loaded: All Termination: Solder Material Flammability Rating: UL94 V-0 Contact Material: Phosphor Bronze Insulation Color: Black Pitch - Mating: 0.050" (1.27mm) Contact Finish - Mating: Gold Contact Finish Thickness - Mating: 3.00µin (0.076µm) Contact Finish - Post: Tin Contact Shape: Square Insulation Height: 0.135" (3.43mm) Shrouding: Unshrouded Insulation Material: Liquid Crystal Polymer (LCP) Row Spacing - Mating: 0.050" (1.27mm) Contact Length - Mating: 0.120" (3.05mm)	товару немає в наявності	В кошику од. на суму грн.
