FTSH-125-01-L-DV-K-P-TR

FTSH-125-01-L-DV-K-P-TR Samtec Inc.

ftsh-1xx-xx-xxx-dv-xxx-xxx-x-xx-mkt.pdf
Виробник: Samtec Inc.
Description: CONN HEADER SMD 50POS 1.27MM
Contact Length - Mating: 0.120" (3.05mm)
Row Spacing - Mating: 0.050" (1.27mm)
Insulation Material: Liquid Crystal Polymer (LCP)
Shrouding: Unshrouded
Insulation Height: 0.099" (2.51mm)
Contact Shape: Square
Part Status: Active
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.050" (1.27mm)
Insulation Color: Black
Contact Material: Phosphor Bronze
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Male Pin
Operating Temperature: -55°C ~ 125°C
Style: Board to Board or Cable
Number of Rows: 2
Number of Positions: 50
Mounting Type: Surface Mount
Current Rating (Amps): 3.4A per Contact
Connector Type: Header, Cuttable
Features: Keying Shroud, Pick and Place
Packaging: Tape & Reel (TR)
на замовлення 900 шт:
термін постачання 21-31 дні (днів)
КількістьЦіна без ПДВ
450+354.80 грн
900+302.66 грн
Мінімальне замовлення: 450 шт
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис FTSH-125-01-L-DV-K-P-TR Samtec Inc.

Description: CONN HEADER SMD 50POS 1.27MM, Contact Length - Mating: 0.120" (3.05mm), Row Spacing - Mating: 0.050" (1.27mm), Insulation Material: Liquid Crystal Polymer (LCP), Shrouding: Unshrouded, Insulation Height: 0.099" (2.51mm), Contact Shape: Square, Part Status: Active, Contact Finish - Post: Tin, Contact Finish Thickness - Mating: 10.0µin (0.25µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.050" (1.27mm), Insulation Color: Black, Contact Material: Phosphor Bronze, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Male Pin, Operating Temperature: -55°C ~ 125°C, Style: Board to Board or Cable, Number of Rows: 2, Number of Positions: 50, Mounting Type: Surface Mount, Current Rating (Amps): 3.4A per Contact, Connector Type: Header, Cuttable, Features: Keying Shroud, Pick and Place, Packaging: Tape & Reel (TR).

Інші пропозиції FTSH-125-01-L-DV-K-P-TR за ціною від 347.67 грн до 519.03 грн

Фото Назва Виробник Інформація Доступність Ціна без ПДВ
FTSH-125-01-L-DV-K-P-TR FTSH-125-01-L-DV-K-P-TR Samtec Inc. ftsh-1xx-xx-xxx-dv-xxx-xxx-x-xx-mkt.pdf Description: CONN HEADER SMD 50POS 1.27MM
Features: Keying Shroud, Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Header, Cuttable
Current Rating (Amps): 3.4A per Contact
Mounting Type: Surface Mount
Number of Positions: 50
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Insulation Height: 0.099" (2.51mm)
Shrouding: Unshrouded
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.120" (3.05mm)
на замовлення 1263 шт:
термін постачання 21-31 дні (днів)
1+490.83 грн
10+457.47 грн
25+442.83 грн
50+386.89 грн
100+347.67 грн
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR FTSH-125-01-L-DV-K-P-TR SAMTEC ftsh-1xx-xx-xxx-dv-xxx-xxx-x-xx-mkt.pdf Category: Board-to-board connectors
Description: Connector: pin strips; socket; male; PIN: 50; vertical; SMT; 1.27mm
Contact plating: gold-plated
Electrical mounting: SMT
Connector pinout layout: 2x25
Type of connector: pin strips
Kind of package: reel
Kind of connector: male
Connector: socket
Spatial orientation: vertical
Connector variant: pick and place
Contacts pitch: 1.27mm
Number of pins: 50
на замовлення 10 шт:
термін постачання 14-30 дні (днів)
1+519.03 грн
10+449.55 грн
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR FTSH-125-01-L-DV-K-P-TR Samtec ftsh_smt.pdf Headers & Wire Housings High Reliability Header Strips
на замовлення 653 шт:
термін постачання 21-30 дні (днів)
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR SAMTEC 3126683.pdf Description: SAMTEC - FTSH-125-01-L-DV-K-P-TR - Stiftleiste, Board-to-Board, Wire-to-Board, 1.27 mm, 2 Reihe(n), 50 Kontakt(e)
tariffCode: 85366930
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Phosphorbronze
usEccn: EAR99
Steckverbinderkragen: Ohne Kragen
Anzahl der Kontakte: 50Kontakt(e)
euEccn: NLR
Steckverbindersysteme: Board-to-Board, Wire-to-Board
Steckverbinder: Stiftleiste
productTraceability: No
Kontaktanschluss: Oberflächenmontage
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 1.27mm
SVHC: No SVHC (21-Jan-2025)
на замовлення 3 шт:
термін постачання 21-31 дні (днів)
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR ftsh-1xx-xx-xxx-dv-xxx-xxx-x-xx-mkt.pdf
FTSH-125-01-L-DV-K-P-TR
Виробник: Samtec Inc.
Description: CONN HEADER SMD 50POS 1.27MM
Features: Keying Shroud, Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Header, Cuttable
Current Rating (Amps): 3.4A per Contact
Mounting Type: Surface Mount
Number of Positions: 50
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Insulation Height: 0.099" (2.51mm)
Shrouding: Unshrouded
Insulation Material: Liquid Crystal Polymer (LCP)
Row Spacing - Mating: 0.050" (1.27mm)
Contact Length - Mating: 0.120" (3.05mm)
на замовлення 1263 шт:
термін постачання 21-31 дні (днів)
КількістьЦіна без ПДВ
1+490.83 грн
10+457.47 грн
25+442.83 грн
50+386.89 грн
100+347.67 грн
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR ftsh-1xx-xx-xxx-dv-xxx-xxx-x-xx-mkt.pdf
FTSH-125-01-L-DV-K-P-TR
Виробник: SAMTEC
Category: Board-to-board connectors
Description: Connector: pin strips; socket; male; PIN: 50; vertical; SMT; 1.27mm
Contact plating: gold-plated
Electrical mounting: SMT
Connector pinout layout: 2x25
Type of connector: pin strips
Kind of package: reel
Kind of connector: male
Connector: socket
Spatial orientation: vertical
Connector variant: pick and place
Contacts pitch: 1.27mm
Number of pins: 50
на замовлення 10 шт:
термін постачання 14-30 дні (днів)
КількістьЦіна без ПДВ
1+519.03 грн
10+449.55 грн
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR ftsh_smt.pdf
FTSH-125-01-L-DV-K-P-TR
Виробник: Samtec
Headers & Wire Housings High Reliability Header Strips
на замовлення 653 шт:
термін постачання 21-30 дні (днів)
В кошику  од. на суму  грн.
FTSH-125-01-L-DV-K-P-TR 3126683.pdf
Виробник: SAMTEC
Description: SAMTEC - FTSH-125-01-L-DV-K-P-TR - Stiftleiste, Board-to-Board, Wire-to-Board, 1.27 mm, 2 Reihe(n), 50 Kontakt(e)
tariffCode: 85366930
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Phosphorbronze
usEccn: EAR99
Steckverbinderkragen: Ohne Kragen
Anzahl der Kontakte: 50Kontakt(e)
euEccn: NLR
Steckverbindersysteme: Board-to-Board, Wire-to-Board
Steckverbinder: Stiftleiste
productTraceability: No
Kontaktanschluss: Oberflächenmontage
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 1.27mm
SVHC: No SVHC (21-Jan-2025)
на замовлення 3 шт:
термін постачання 21-31 дні (днів)
В кошику  од. на суму  грн.
