Продукція > SUNON FANS > GF40282B1-1000U-ADP
GF40282B1-1000U-ADP

GF40282B1-1000U-ADP Sunon Fans

GF40282B1-1000U-ADP-D04176790G-01-0_Ref.pdf
Виробник: Sunon Fans
Description: FAN AXIAL 12V 40X28MM GR487
Features: Auto Restart
Packaging: Box
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Ball
RPM: 14600 RPM
Air Flow: 19.6 CFM (0.549m³/min)
Width: 28.00mm
Termination: 2 Wire Leads
Approval Agency: CCC, CE, cURus, TUV, UKCA
Fan Type: Tubeaxial
Noise: 52.8dB(A)
Static Pressure: 1.380 in H2O (343.7 Pa)
Power (Watts): 5.52 W
на замовлення 173 шт:
термін постачання 21-31 дні (днів)
КількістьЦіна без ПДВ
1+1518.00 грн
10+1177.10 грн
25+1072.09 грн
50+935.97 грн
150+890.68 грн
В кошику  од. на суму  грн.
Відгуки про товар
Написати відгук

Технічний опис GF40282B1-1000U-ADP Sunon Fans

Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 40x40x28mm; 26.84m3/h; 62.1dBA; ball; 28AWG, Wire size: 28AWG, Insulation class: A, Supply voltage: 24V DC, Flammability rating: UL94V-0, Current rating: 265mA, Static pressure: 27.18mm H2O, Fan efficiency: 26.84m3/h, Operating temperature: -10...70°C, Rotational rate/speed: 14600 (±10%)rpm, Enclosure material: thermoplastic, Kind of Bearing: ball, Fan motor: brushless DC, Leads: leads x2, Fan dimensions: 40x40x28mm, Min. insulation resistance: 10MΩ, Power consumption: 6.36W, Impeller material: thermoplastic, Type of fan: DC, Noise level: 62.1dBA, Additional functions: autorestart, Operating voltage: 8...27.6V DC, Kind of fan: axial.

Інші пропозиції GF40282B1-1000U-ADP

Фото Назва Виробник Інформація Доступність Ціна без ПДВ
GF40282B1-1000U-ADP GF40282B1-1000U-ADP Sunon GF40282B1_1000U_ADP_D04176790G_01_0_Ref.pdf DC Fans Axial Fan, 40x40x28mm, 24VDC, Ball, Auto Restart, GR487/Salt Fog, D04176790G-00
товару немає в наявності
В кошику  од. на суму  грн.
GF40282B1-1000U-ADP SUNON GF40282B1-1000U-ADP-D04176790G-01-0_Ref.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 26.84m3/h; 62.1dBA; ball; 28AWG
Wire size: 28AWG
Insulation class: A
Supply voltage: 24V DC
Flammability rating: UL94V-0
Current rating: 265mA
Static pressure: 27.18mm H2O
Fan efficiency: 26.84m3/h
Operating temperature: -10...70°C
Rotational rate/speed: 14600 (±10%)rpm
Enclosure material: thermoplastic
Kind of Bearing: ball
Fan motor: brushless DC
Leads: leads x2
Fan dimensions: 40x40x28mm
Min. insulation resistance: 10MΩ
Power consumption: 6.36W
Impeller material: thermoplastic
Type of fan: DC
Noise level: 62.1dBA
Additional functions: autorestart
Operating voltage: 8...27.6V DC
Kind of fan: axial
товару немає в наявності
 Мінімальне замовлення: 1050 шт
В кошику  од. на суму  грн.
GF40282B1-1000U-ADP GF40282B1_1000U_ADP_D04176790G_01_0_Ref.pdf
GF40282B1-1000U-ADP
Виробник: Sunon
DC Fans Axial Fan, 40x40x28mm, 24VDC, Ball, Auto Restart, GR487/Salt Fog, D04176790G-00
товару немає в наявності
В кошику  од. на суму  грн.
GF40282B1-1000U-ADP GF40282B1-1000U-ADP-D04176790G-01-0_Ref.pdf
Виробник: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 40x40x28mm; 26.84m3/h; 62.1dBA; ball; 28AWG
Wire size: 28AWG
Insulation class: A
Supply voltage: 24V DC
Flammability rating: UL94V-0
Current rating: 265mA
Static pressure: 27.18mm H2O
Fan efficiency: 26.84m3/h
Operating temperature: -10...70°C
Rotational rate/speed: 14600 (±10%)rpm
Enclosure material: thermoplastic
Kind of Bearing: ball
Fan motor: brushless DC
Leads: leads x2
Fan dimensions: 40x40x28mm
Min. insulation resistance: 10MΩ
Power consumption: 6.36W
Impeller material: thermoplastic
Type of fan: DC
Noise level: 62.1dBA
Additional functions: autorestart
Operating voltage: 8...27.6V DC
Kind of fan: axial
товару немає в наявності
Мінімальне замовлення: 1050 шт
В кошику  од. на суму  грн.
