Технічний опис HF118F/012-1Z1 HONGFA
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 10A; 10A/250VAC; PCB, Type of relay: electromagnetic, Contacts configuration: SPDT, Rated coil voltage: 12V DC, Contact current max.: 10A, AC contacts rating @R: 10A / 250V AC, DC contacts rating @R: 10A / 30V DC, Switched voltage: max. 125V DC; max. 440V AC, Relay variant: miniature, Mounting: PCB, Coil resistance: 620Ω, Coil voltage min.: 8.4V DC, Coil voltage max.: 18V DC, Operate time: 10ms, Body dimensions: 28.5x12.5x10.1mm, Release time: 5ms, Coil power consumption: 220mW, Operating temperature: -40...85°C, Contact resistance: 100mΩ, Contact material: AgNi, Terminal pitch: 3.2mm, кількість в упаковці: 1 шт.
Інші пропозиції HF118F/012-1Z1
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
|---|---|---|---|---|---|
|
HF118F/012-1Z1 Код товару: 133271
Додати до обраних
Обраний товар
|
Реле |
товару немає в наявності
|
|||
| HF118F/012-1Z1 | Виробник : Hongfa |
 Power Relay 12VDC 10A SPDT(28.5x10.1x12.5)mm THT |
товару немає в наявності |
||
 |
HF118F/012-1Z1 | Виробник : HONGFA RELAY |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 10A; 10A/250VAC; PCB Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 10A / 30V DC Switched voltage: max. 125V DC; max. 440V AC Relay variant: miniature Mounting: PCB Coil resistance: 620Ω Coil voltage min.: 8.4V DC Coil voltage max.: 18V DC Operate time: 10ms Body dimensions: 28.5x12.5x10.1mm Release time: 5ms Coil power consumption: 220mW Operating temperature: -40...85°C Contact resistance: 100mΩ Contact material: AgNi Terminal pitch: 3.2mm кількість в упаковці: 1 шт |
товару немає в наявності |
|
|
|
HF118F/012-1Z1 | Виробник : HONGFA RELAY |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 10A; 10A/250VAC; PCB Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 10A / 30V DC Switched voltage: max. 125V DC; max. 440V AC Relay variant: miniature Mounting: PCB Coil resistance: 620Ω Coil voltage min.: 8.4V DC Coil voltage max.: 18V DC Operate time: 10ms Body dimensions: 28.5x12.5x10.1mm Release time: 5ms Coil power consumption: 220mW Operating temperature: -40...85°C Contact resistance: 100mΩ Contact material: AgNi Terminal pitch: 3.2mm |
товару немає в наявності |
