Технічний опис HR30-6PA-6S(71) Hirose
Description: HIROSE / HRS - HR30-6PA-6S(71) - Rundsteckverbinder, IP68, Sealed Circular Connector, HR30 Series, Kabelstecker, 6 Kontakt(e), tariffCode: 85366990, euEccn: NLR, rohsCompliant: YES, hazardous: false, rohsPhthalatesCompliant: YES, Kontaktmaterial: Phosphorbronze, Verschluss: -, isCanonical: Y, Steckverbinderüberzug: -, IP-Schutzart: IP67, IP68, Anzahl der Kontakte: 6Kontakt(e), SVHC: Imidazolidine-2-thione; (2-imidazoline-2-thiol) (23-Jan-2024), Kontaktüberzug: Gold, Steckverbinder: Sealed Circular Connector, Rundsteckverbinderkontakt: Lötbuchse, Rundsteckverbindergehäuse: Kabelstecker, Produktpalette: HR30 Series, productTraceability: No, usEccn: EAR99, Steckverbindermaterial: Gehäuse aus PPV (Polyphenylenvinylen).
Інші пропозиції HR30-6PA-6S(71) за ціною від 508.71 грн до 942.60 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна без ПДВ | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HR30-6PA-6S(71) | Hirose Electric Co Ltd |
 Description: CONN PLUG FMALE 6P GOLD SLDR CUPPrimary Material: Plastic Shell Material: Polybutylene Terephthalate (PBT) Part Status: Active Contact Finish - Mating: Gold Material Flammability Rating: UL94 V-0 Cable Opening: 0.138" ~ 0.169" (3.50mm ~ 4.30mm) Ingress Protection: IP67/IP68 - Dust Tight, Waterproof Termination: Solder Cup Fastening Type: Push-Pull Operating Temperature: -25°C ~ 85°C Shell Size - Insert: 6 Orientation: Keyed Number of Positions: 6 (Power) Mounting Type: Free Hanging (In-Line) Current Rating (Amps): 2A Voltage Rating: 100VAC, 140VDC Color: Black Connector Type: Plug, Female Sockets Features: Backshell, Strain Relief Packaging: Tray |
на замовлення 893 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||||
 |
HR30-6PA-6S(71) | HIROSE |
Category: HIROSE connectors Description: Connector: circular; push-pull; plug; PIN: 6; 2A; HR30; gold-plated Type of connector: circular Connector: plug Kind of connector: female Manufacturer series: HR30 Number of pins: 6 Current rating: 2A Mechanical mounting: for cable Electrical mounting: soldering Locking system: push-pull Max. wire diameter: 3.9mm Contact plating: gold-plated Spatial orientation: straight Wire size: 26AWG Rated voltage: 100V AC; 140V DC |
на замовлення 165 шт: термін постачання 14-30 дні (днів) |
|
||||||||||||||
 |
HR30-6PA-6S(71) | HIROSE / HRS |
Description: HIROSE / HRS - HR30-6PA-6S(71) - Rundsteckverbinder, IP68, Sealed Circular Connector, HR30 Series, Kabelstecker, 6 Kontakt(e) tariffCode: 85366990 euEccn: NLR rohsCompliant: YES hazardous: false rohsPhthalatesCompliant: YES Kontaktmaterial: Phosphorbronze Verschluss: - isCanonical: Y Steckverbinderüberzug: - IP-Schutzart: IP67, IP68 Anzahl der Kontakte: 6Kontakt(e) SVHC: Imidazolidine-2-thione; (2-imidazoline-2-thiol) (23-Jan-2024) Kontaktüberzug: Gold Steckverbinder: Sealed Circular Connector Rundsteckverbinderkontakt: Lötbuchse Rundsteckverbindergehäuse: Kabelstecker Produktpalette: HR30 Series productTraceability: No usEccn: EAR99 Steckverbindermaterial: Gehäuse aus PPV (Polyphenylenvinylen) |
на замовлення 298 шт: термін постачання 21-31 дні (днів) |
В кошику од. на суму грн. | ||||||||||||||
 |
HR30-6PA-6S(71) | Hirose Connector |
Circular Push Pull Connectors 6P PLUG SHELL SZ 6 FEMALE TERM SOLDER |
на замовлення 396 шт: термін постачання 21-30 дні (днів) |
В кошику од. на суму грн. |
| HR30-6PA-6S(71) |
|
Виробник: Hirose Electric Co Ltd
Description: CONN PLUG FMALE 6P GOLD SLDR CUP
Primary Material: Plastic
Shell Material: Polybutylene Terephthalate (PBT)
Part Status: Active
Contact Finish - Mating: Gold
Material Flammability Rating: UL94 V-0
Cable Opening: 0.138" ~ 0.169" (3.50mm ~ 4.30mm)
Ingress Protection: IP67/IP68 - Dust Tight, Waterproof
Termination: Solder Cup
Fastening Type: Push-Pull
Operating Temperature: -25°C ~ 85°C
Shell Size - Insert: 6
Orientation: Keyed
Number of Positions: 6 (Power)
Mounting Type: Free Hanging (In-Line)
Current Rating (Amps): 2A
Voltage Rating: 100VAC, 140VDC
Color: Black
Connector Type: Plug, Female Sockets
Features: Backshell, Strain Relief
Packaging: Tray
Description: CONN PLUG FMALE 6P GOLD SLDR CUP
Primary Material: Plastic
Shell Material: Polybutylene Terephthalate (PBT)
Part Status: Active
Contact Finish - Mating: Gold
Material Flammability Rating: UL94 V-0
Cable Opening: 0.138" ~ 0.169" (3.50mm ~ 4.30mm)
Ingress Protection: IP67/IP68 - Dust Tight, Waterproof
Termination: Solder Cup
Fastening Type: Push-Pull
Operating Temperature: -25°C ~ 85°C
Shell Size - Insert: 6
Orientation: Keyed
Number of Positions: 6 (Power)
Mounting Type: Free Hanging (In-Line)
Current Rating (Amps): 2A
Voltage Rating: 100VAC, 140VDC
Color: Black
Connector Type: Plug, Female Sockets
Features: Backshell, Strain Relief
Packaging: Tray
на замовлення 893 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1+ | 887.65 грн |
| 10+ | 726.22 грн |
| 25+ | 680.78 грн |
| 50+ | 608.36 грн |
| 100+ | 579.33 грн |
| 250+ | 543.08 грн |
| 500+ | 508.71 грн |
| HR30-6PA-6S(71) |
|
Виробник: HIROSE
Category: HIROSE connectors
Description: Connector: circular; push-pull; plug; PIN: 6; 2A; HR30; gold-plated
Type of connector: circular
Connector: plug
Kind of connector: female
Manufacturer series: HR30
Number of pins: 6
Current rating: 2A
Mechanical mounting: for cable
Electrical mounting: soldering
Locking system: push-pull
Max. wire diameter: 3.9mm
Contact plating: gold-plated
Spatial orientation: straight
Wire size: 26AWG
Rated voltage: 100V AC; 140V DC
Category: HIROSE connectors
Description: Connector: circular; push-pull; plug; PIN: 6; 2A; HR30; gold-plated
Type of connector: circular
Connector: plug
Kind of connector: female
Manufacturer series: HR30
Number of pins: 6
Current rating: 2A
Mechanical mounting: for cable
Electrical mounting: soldering
Locking system: push-pull
Max. wire diameter: 3.9mm
Contact plating: gold-plated
Spatial orientation: straight
Wire size: 26AWG
Rated voltage: 100V AC; 140V DC
на замовлення 165 шт:
термін постачання 14-30 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1+ | 942.60 грн |
| 10+ | 744.74 грн |
| 25+ | 705.41 грн |
| 50+ | 675.28 грн |
| 100+ | 646.83 грн |
| 150+ | 629.26 грн |
| HR30-6PA-6S(71) |
|
Виробник: HIROSE / HRS
Description: HIROSE / HRS - HR30-6PA-6S(71) - Rundsteckverbinder, IP68, Sealed Circular Connector, HR30 Series, Kabelstecker, 6 Kontakt(e)
tariffCode: 85366990
euEccn: NLR
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Phosphorbronze
Verschluss: -
isCanonical: Y
Steckverbinderüberzug: -
IP-Schutzart: IP67, IP68
Anzahl der Kontakte: 6Kontakt(e)
SVHC: Imidazolidine-2-thione; (2-imidazoline-2-thiol) (23-Jan-2024)
Kontaktüberzug: Gold
Steckverbinder: Sealed Circular Connector
Rundsteckverbinderkontakt: Lötbuchse
Rundsteckverbindergehäuse: Kabelstecker
Produktpalette: HR30 Series
productTraceability: No
usEccn: EAR99
Steckverbindermaterial: Gehäuse aus PPV (Polyphenylenvinylen)
Description: HIROSE / HRS - HR30-6PA-6S(71) - Rundsteckverbinder, IP68, Sealed Circular Connector, HR30 Series, Kabelstecker, 6 Kontakt(e)
tariffCode: 85366990
euEccn: NLR
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Phosphorbronze
Verschluss: -
isCanonical: Y
Steckverbinderüberzug: -
IP-Schutzart: IP67, IP68
Anzahl der Kontakte: 6Kontakt(e)
SVHC: Imidazolidine-2-thione; (2-imidazoline-2-thiol) (23-Jan-2024)
Kontaktüberzug: Gold
Steckverbinder: Sealed Circular Connector
Rundsteckverbinderkontakt: Lötbuchse
Rundsteckverbindergehäuse: Kabelstecker
Produktpalette: HR30 Series
productTraceability: No
usEccn: EAR99
Steckverbindermaterial: Gehäuse aus PPV (Polyphenylenvinylen)
на замовлення 298 шт:
термін постачання 21-31 дні (днів)
| HR30-6PA-6S(71) |
|
Виробник: Hirose Connector
Circular Push Pull Connectors 6P PLUG SHELL SZ 6 FEMALE TERM SOLDER
Circular Push Pull Connectors 6P PLUG SHELL SZ 6 FEMALE TERM SOLDER
на замовлення 396 шт:
термін постачання 21-30 дні (днів)
