HTMS-103-53-G-D Samtec Inc.
Виробник: Samtec Inc.
Description: CONN HDR .050" 20POS
Contact Finish - Post: Gold
Contact Finish Thickness - Mating: 10.0µin (0.25µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.050" (1.27mm)
Insulation Color: Black
Contact Material: Phosphor Bronze
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Male Pin
Operating Temperature: -55°C ~ 125°C
Style: Board to Board
Number of Rows: 2
Number of Positions: 6
Mounting Type: Through Hole
Current Rating (Amps): 5A per Contact
Connector Type: Header
Packaging: Bulk
Contact Length - Mating: 0.285" (7.24mm)
Row Spacing - Mating: 0.100" (2.54mm)
Insulation Material: Liquid Crystal Polymer (LCP)
Overall Contact Length: 0.505" (12.83mm)
Shrouding: Unshrouded
Insulation Height: 0.100" (2.54mm)
Contact Length - Post: 0.120" (3.05mm)
Contact Shape: Square
Part Status: Active
Відгуки про товар
Написати відгук
Технічний опис HTMS-103-53-G-D Samtec Inc.
Description: CONN HDR .050" 20POS, Contact Finish - Post: Gold, Contact Finish Thickness - Mating: 10.0µin (0.25µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.050" (1.27mm), Insulation Color: Black, Contact Material: Phosphor Bronze, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Male Pin, Operating Temperature: -55°C ~ 125°C, Style: Board to Board, Number of Rows: 2, Number of Positions: 6, Mounting Type: Through Hole, Current Rating (Amps): 5A per Contact, Connector Type: Header, Packaging: Bulk, Contact Length - Mating: 0.285" (7.24mm), Row Spacing - Mating: 0.100" (2.54mm), Insulation Material: Liquid Crystal Polymer (LCP), Overall Contact Length: 0.505" (12.83mm), Shrouding: Unshrouded, Insulation Height: 0.100" (2.54mm), Contact Length - Post: 0.120" (3.05mm), Contact Shape: Square, Part Status: Active.
Інші пропозиції HTMS-103-53-G-D за ціною від 49.86 грн до 112.42 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HTMS-103-53-G-D | Samtec |
Headers & Wire Housings Through-hole Micro Header |
на замовлення 85 шт: термін постачання 21-30 дні (днів) |
|
| HTMS-103-53-G-D |
|
Виробник: Samtec
Headers & Wire Housings Through-hole Micro Header
Headers & Wire Housings Through-hole Micro Header
на замовлення 85 шт:
термін постачання 21-30 дні (днів)
| Кількість | Ціна |
|---|---|
| 3+ | 112.42 грн |
| 50+ | 85.92 грн |
| 100+ | 66.69 грн |
| 500+ | 58.79 грн |
| 1000+ | 49.86 грн |
