JS-24MN-K FUJITSU
Виробник: FUJITSU
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Switched voltage: max. 150V DC; max. 400V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.35kΩ
Coil voltage min.: 16.8V DC
Coil voltage max.: 56.6V DC
Operate time: 10ms
Body dimensions: 29x10x12.5mm
Release time: 5ms
Coil power consumption: 400mW
Operating temperature: -40...85°C
Relay series: JS
Contact resistance: 100mΩ
Contact material: AgSnO2
Terminal pitch: 3.2mm
Contact plating: gold-plated
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Switched voltage: max. 150V DC; max. 400V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.35kΩ
Coil voltage min.: 16.8V DC
Coil voltage max.: 56.6V DC
Operate time: 10ms
Body dimensions: 29x10x12.5mm
Release time: 5ms
Coil power consumption: 400mW
Operating temperature: -40...85°C
Relay series: JS
Contact resistance: 100mΩ
Contact material: AgSnO2
Terminal pitch: 3.2mm
Contact plating: gold-plated
на замовлення 299 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
3+ | 152.61 грн |
5+ | 128.7 грн |
9+ | 88.31 грн |
24+ | 83.52 грн |
Відгуки про товар
Написати відгук
Технічний опис JS-24MN-K FUJITSU
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; PCB, Type of relay: electromagnetic, Contacts configuration: SPST-NO, Rated coil voltage: 24V DC, Contact current max.: 8A, AC contacts rating @R: 8A / 250V AC, DC contacts rating @R: 8A / 24V DC, Switched voltage: max. 150V DC; max. 400V AC, Relay variant: miniature, Mounting: PCB, Coil resistance: 2.35kΩ, Coil voltage min.: 16.8V DC, Coil voltage max.: 56.6V DC, Operate time: 10ms, Body dimensions: 29x10x12.5mm, Release time: 5ms, Coil power consumption: 400mW, Operating temperature: -40...85°C, Relay series: JS, Contact resistance: 100mΩ, Contact material: AgSnO2, Terminal pitch: 3.2mm, Contact plating: gold-plated, кількість в упаковці: 1 шт.
Інші пропозиції JS-24MN-K за ціною від 100.22 грн до 340.43 грн
