Технічний опис MF40101V2-1000U-A99 Sunon
Category: DC12V Fans, Description: Fan: DC; axial; 12VDC; 40x40x10mm; 11.89m3/h; 20.6dBA; Vapo; 5800rpm, Operating temperature: -10...70°C, Current rating: 40mA, Static pressure: 3.05mm H2O, Related items: SR4-15.5, Fan efficiency: 11.89m3/h, Rotational rate/speed: 5800rpm, Enclosure material: thermoplastic, Kind of Bearing: Vapo, Fan motor: brushless DC, Leads: leads x2, Fan dimensions: 40x40x10mm, Min. insulation resistance: 10MΩ, Power consumption: 0.59W, Impeller material: thermoplastic, Type of fan: DC, Noise level: 20.6dBA, Additional functions: autorestart, Lead length: 0.3m, Operating voltage: 6...13.8V DC, Kind of fan: axial, Wire size: 26AWG, Supply voltage: 12V DC, Flammability rating: UL94V-0.
Інші пропозиції MF40101V2-1000U-A99 за ціною від 138.83 грн до 336.24 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна без ПДВ | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MF40101V2-1000U-A99 | SUNON |
 Category: DC12V FansDescription: Fan: DC; axial; 12VDC; 40x40x10mm; 11.89m3/h; 20.6dBA; Vapo; 5800rpm Operating temperature: -10...70°C Current rating: 40mA Static pressure: 3.05mm H2O Related items: SR4-15.5 Fan efficiency: 11.89m3/h Rotational rate/speed: 5800rpm Enclosure material: thermoplastic Kind of Bearing: Vapo Fan motor: brushless DC Leads: leads x2 Fan dimensions: 40x40x10mm Min. insulation resistance: 10MΩ Power consumption: 0.59W Impeller material: thermoplastic Type of fan: DC Noise level: 20.6dBA Additional functions: autorestart Lead length: 0.3m Operating voltage: 6...13.8V DC Kind of fan: axial Wire size: 26AWG Supply voltage: 12V DC Flammability rating: UL94V-0 |
на замовлення 2942 шт: термін постачання 14-30 дні (днів) |
|
||||||||||||
 |
MF40101V2-1000U-A99 | Sunon Fans |
Description: FAN AXIAL 40X10MM 12VDC WIRE Features: Auto Restart Packaging: Bulk Voltage - Rated: 12VDC Size / Dimension: Square - 40mm L x 40mm H Bearing Type: Vapo-Bearing™ RPM: 5800 RPM Air Flow: 7.0 CFM (0.196m³/min) Width: 10.00mm Weight: 0.035 lb (15.88 g) Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: cURus, TUV Fan Type: Tubeaxial Noise: 20.6dB(A) Static Pressure: 0.120 in H2O (29.9 Pa) Part Status: Active Power (Watts): 480 mW |
на замовлення 3497 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||
 |
MF40101V2-1000U-A99 | Sunon |
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 7CFM, 0.12"H2O, Vapo, 2xWire, Auto Restart |
на замовлення 3172 шт: термін постачання 21-30 дні (днів) |
В кошику од. на суму грн. | ||||||||||||
 |
MF40101V2-1000U-A99 | SUNON |
Description: SUNON - MF40101V2-1000U-A99 - DC FAN, VAPO, 40MM, 5800RPM, 12VDC tariffCode: 84145915 euEccn: NLR Stromanschluss: 2 Lead Wires rohsCompliant: YES hazardous: false rohsPhthalatesCompliant: YES Art des Lagers: Vapo Bearing Nennleistung: 480mW isCanonical: Y IP-Schutzart: - Luftstrom - m3/min: - Nennstrom: 40mA Außentiefe: 10mm Geräuschentwicklung: 20.6dBA Luftstrom - CFM: 7cu.ft/min SVHC: No SVHC (27-Jun-2024) Lüfterrahmen: Square Produktpalette: DC Brushless M Series productTraceability: No Rahmengröße: 40mm usEccn: EAR99 Versorgungsspannung, V DC: 12V Nenndrehzahl: 5800rpm directShipCharge: 25 |
на замовлення 39 шт: термін постачання 21-31 дні (днів) |
В кошику од. на суму грн. |
| MF40101V2-1000U-A99 |
|
Виробник: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 11.89m3/h; 20.6dBA; Vapo; 5800rpm
Operating temperature: -10...70°C
Current rating: 40mA
Static pressure: 3.05mm H2O
Related items: SR4-15.5
Fan efficiency: 11.89m3/h
Rotational rate/speed: 5800rpm
Enclosure material: thermoplastic
Kind of Bearing: Vapo
Fan motor: brushless DC
Leads: leads x2
Fan dimensions: 40x40x10mm
Min. insulation resistance: 10MΩ
Power consumption: 0.59W
Impeller material: thermoplastic
Type of fan: DC
Noise level: 20.6dBA
Additional functions: autorestart
Lead length: 0.3m
Operating voltage: 6...13.8V DC
Kind of fan: axial
Wire size: 26AWG
Supply voltage: 12V DC
Flammability rating: UL94V-0
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 11.89m3/h; 20.6dBA; Vapo; 5800rpm
Operating temperature: -10...70°C
Current rating: 40mA
Static pressure: 3.05mm H2O
Related items: SR4-15.5
Fan efficiency: 11.89m3/h
Rotational rate/speed: 5800rpm
Enclosure material: thermoplastic
Kind of Bearing: Vapo
Fan motor: brushless DC
Leads: leads x2
Fan dimensions: 40x40x10mm
Min. insulation resistance: 10MΩ
Power consumption: 0.59W
Impeller material: thermoplastic
Type of fan: DC
Noise level: 20.6dBA
Additional functions: autorestart
Lead length: 0.3m
Operating voltage: 6...13.8V DC
Kind of fan: axial
Wire size: 26AWG
Supply voltage: 12V DC
Flammability rating: UL94V-0
на замовлення 2942 шт:
термін постачання 14-30 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 2+ | 230.64 грн |
| 10+ | 205.70 грн |
| 50+ | 165.92 грн |
| 100+ | 147.29 грн |
| 200+ | 138.83 грн |
| MF40101V2-1000U-A99 |
|
Виробник: Sunon Fans
Description: FAN AXIAL 40X10MM 12VDC WIRE
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 5800 RPM
Air Flow: 7.0 CFM (0.196m³/min)
Width: 10.00mm
Weight: 0.035 lb (15.88 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: cURus, TUV
Fan Type: Tubeaxial
Noise: 20.6dB(A)
Static Pressure: 0.120 in H2O (29.9 Pa)
Part Status: Active
Power (Watts): 480 mW
Description: FAN AXIAL 40X10MM 12VDC WIRE
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Square - 40mm L x 40mm H
Bearing Type: Vapo-Bearing™
RPM: 5800 RPM
Air Flow: 7.0 CFM (0.196m³/min)
Width: 10.00mm
Weight: 0.035 lb (15.88 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: cURus, TUV
Fan Type: Tubeaxial
Noise: 20.6dB(A)
Static Pressure: 0.120 in H2O (29.9 Pa)
Part Status: Active
Power (Watts): 480 mW
на замовлення 3497 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 1+ | 336.24 грн |
| 10+ | 264.67 грн |
| 25+ | 242.00 грн |
| 50+ | 211.70 грн |
| 100+ | 197.05 грн |
| 400+ | 182.05 грн |
| MF40101V2-1000U-A99 |
|
Виробник: Sunon
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 7CFM, 0.12"H2O, Vapo, 2xWire, Auto Restart
DC Fans DC Axial Fan, 40x40x10mm, 12VDC, 7CFM, 0.12"H2O, Vapo, 2xWire, Auto Restart
на замовлення 3172 шт:
термін постачання 21-30 дні (днів)
| MF40101V2-1000U-A99 |
|
Виробник: SUNON
Description: SUNON - MF40101V2-1000U-A99 - DC FAN, VAPO, 40MM, 5800RPM, 12VDC
tariffCode: 84145915
euEccn: NLR
Stromanschluss: 2 Lead Wires
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Art des Lagers: Vapo Bearing
Nennleistung: 480mW
isCanonical: Y
IP-Schutzart: -
Luftstrom - m3/min: -
Nennstrom: 40mA
Außentiefe: 10mm
Geräuschentwicklung: 20.6dBA
Luftstrom - CFM: 7cu.ft/min
SVHC: No SVHC (27-Jun-2024)
Lüfterrahmen: Square
Produktpalette: DC Brushless M Series
productTraceability: No
Rahmengröße: 40mm
usEccn: EAR99
Versorgungsspannung, V DC: 12V
Nenndrehzahl: 5800rpm
directShipCharge: 25
Description: SUNON - MF40101V2-1000U-A99 - DC FAN, VAPO, 40MM, 5800RPM, 12VDC
tariffCode: 84145915
euEccn: NLR
Stromanschluss: 2 Lead Wires
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Art des Lagers: Vapo Bearing
Nennleistung: 480mW
isCanonical: Y
IP-Schutzart: -
Luftstrom - m3/min: -
Nennstrom: 40mA
Außentiefe: 10mm
Geräuschentwicklung: 20.6dBA
Luftstrom - CFM: 7cu.ft/min
SVHC: No SVHC (27-Jun-2024)
Lüfterrahmen: Square
Produktpalette: DC Brushless M Series
productTraceability: No
Rahmengröße: 40mm
usEccn: EAR99
Versorgungsspannung, V DC: 12V
Nenndrehzahl: 5800rpm
directShipCharge: 25
на замовлення 39 шт:
термін постачання 21-31 дні (днів)
