MTL 206 P KNITTER-SWITCH
Виробник: KNITTER-SWITCH
Category: Toggle Switches
Description: Switch: toggle; Pos: 3; DPDT; ON-OFF-ON; 6A/125VAC; 6A/6VDC; MTL
Manufacturer series: MTL
Body colour: black
Leads: flat pin
Contacts configuration: DPDT
Illumination: none
Switching method: ON-OFF-ON
Mounting: screw
Body material: plastic
Contact plating: silver plated
Type of switch: toggle
Operating temperature: -45...140°C
Terminal pitch: 4.3mm
Max. contact resistance:: 20mΩ
Body dimensions: 9.2x13x13mm
Mounting hole diameter: Ø6.4mm
Number of positions: 3
Stable positions number: 3
DC contacts rating @R: 6A / 6V DC
AC contacts rating @R: 6A / 125V AC
Mechanical durability: 200000 cycles
Відгуки про товар
Написати відгук
Технічний опис MTL 206 P KNITTER-SWITCH
Category: Toggle Switches, Description: Switch: toggle; Pos: 3; DPDT; ON-OFF-ON; 6A/125VAC; 6A/6VDC; MTL, Manufacturer series: MTL, Body colour: black, Leads: flat pin, Contacts configuration: DPDT, Illumination: none, Switching method: ON-OFF-ON, Mounting: screw, Body material: plastic, Contact plating: silver plated, Type of switch: toggle, Operating temperature: -45...140°C, Terminal pitch: 4.3mm, Max. contact resistance:: 20mΩ, Body dimensions: 9.2x13x13mm, Mounting hole diameter: Ø6.4mm, Number of positions: 3, Stable positions number: 3, DC contacts rating @R: 6A / 6V DC, AC contacts rating @R: 6A / 125V AC, Mechanical durability: 200000 cycles.
Інші пропозиції MTL 206 P за ціною від 737.55 грн до 2705.07 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MTL 206 P | Knitter-Switch |
Description: SWITCH TOGGLE 2-POLE ON OFF ON Packaging: Box Current Rating (Amps): 6A (AC), 4A (DC) Mounting Type: Panel Mount Circuit: DPDT Switch Function: On-Off-On Operating Temperature: -45°C ~ 140°C Termination Style: Solder Lug Illumination: Non-Illuminated Bushing Thread: M6 x 0.75 Actuator Length: 15.00mm Actuator Type: Locking Lever Panel Cutout Dimensions: Circular - 6.20mm Dia Voltage Rating - AC: 125 V Voltage Rating - DC: 30 V |
на замовлення 499 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||
 |
MTL206P | TE Connectivity / P&B |
Toggle Switches DP ON-OFF-ON LUG |
на замовлення 13 шт: термін постачання 21-30 дні (днів) |
|
||||||||||||
 |
MTL206P | TE Connectivity ALCOSWITCH Switches |
Description: SWITCH TOGGLE DPDT 6A 125V Features: Epoxy Sealed Terminals Packaging: Bulk Current Rating (Amps): 6A (AC), 4A (DC) Mounting Type: Panel Mount Circuit: DPDT Switch Function: On-Off-On Operating Temperature: -20°C ~ 80°C Termination Style: Solder Lug Illumination: Non-Illuminated Bushing Thread: 1/4-40 Actuator Length: 17.00mm Actuator Type: Locking Lever Panel Cutout Dimensions: Circular - 6.40mm Dia Voltage Rating - AC: 125 V Voltage Rating - DC: 28 V |
на замовлення 133 шт: термін постачання 21-31 дні (днів) |
|
||||||||||||
 |
MTL-206P | TE CONNECTIVITY - ALCOSWITCH |
Description: TE CONNECTIVITY - ALCOSWITCH - MTL-206P - SWITCH, TOGGLE, DPDT, 6A, 250V tariffCode: 85365080 rohsCompliant: Y-EX Schalteranschlüsse: Solder hazardous: false rohsPhthalatesCompliant: YES Kontaktstrom, max.: 6A Schalterfunktion: On-Off-On isCanonical: Y usEccn: EAR99 AC-Kontaktspannung, nom.: 250V euEccn: NLR DC-Kontaktspannung, nom.: 28V Beleuchtung: Non Illuminated Schaltermontage: Panel Mount Produktpalette: MT Green Series productTraceability: Yes-Date/Lot Code Kontaktkonfiguration: DPDT directShipCharge: 25 SVHC: To Be Advised |
на замовлення 44 шт: термін постачання 21-31 дні (днів) |
|
| MTL 206 P |
|
Виробник: Knitter-Switch
Description: SWITCH TOGGLE 2-POLE ON OFF ON
Packaging: Box
Current Rating (Amps): 6A (AC), 4A (DC)
Mounting Type: Panel Mount
Circuit: DPDT
Switch Function: On-Off-On
Operating Temperature: -45°C ~ 140°C
Termination Style: Solder Lug
Illumination: Non-Illuminated
Bushing Thread: M6 x 0.75
Actuator Length: 15.00mm
Actuator Type: Locking Lever
Panel Cutout Dimensions: Circular - 6.20mm Dia
Voltage Rating - AC: 125 V
Voltage Rating - DC: 30 V
Description: SWITCH TOGGLE 2-POLE ON OFF ON
Packaging: Box
Current Rating (Amps): 6A (AC), 4A (DC)
Mounting Type: Panel Mount
Circuit: DPDT
Switch Function: On-Off-On
Operating Temperature: -45°C ~ 140°C
Termination Style: Solder Lug
Illumination: Non-Illuminated
Bushing Thread: M6 x 0.75
Actuator Length: 15.00mm
Actuator Type: Locking Lever
Panel Cutout Dimensions: Circular - 6.20mm Dia
Voltage Rating - AC: 125 V
Voltage Rating - DC: 30 V
на замовлення 499 шт:
термін постачання 21-31 дні (днів)| Кількість | Ціна |
|---|---|
| 1+ | 1158.26 грн |
| 10+ | 970.84 грн |
| 25+ | 917.74 грн |
| 50+ | 825.10 грн |
| 100+ | 790.21 грн |
| 300+ | 737.55 грн |
| MTL206P |
|
Виробник: TE Connectivity / P&B
Toggle Switches DP ON-OFF-ON LUG
Toggle Switches DP ON-OFF-ON LUG
на замовлення 13 шт:
термін постачання 21-30 дні (днів)| Кількість | Ціна |
|---|---|
| 1+ | 2333.40 грн |
| 10+ | 2256.40 грн |
| 25+ | 1849.56 грн |
| 50+ | 1765.17 грн |
| 100+ | 1689.22 грн |
| 250+ | 1587.95 грн |
| MTL206P |
|
Виробник: TE Connectivity ALCOSWITCH Switches
Description: SWITCH TOGGLE DPDT 6A 125V
Features: Epoxy Sealed Terminals
Packaging: Bulk
Current Rating (Amps): 6A (AC), 4A (DC)
Mounting Type: Panel Mount
Circuit: DPDT
Switch Function: On-Off-On
Operating Temperature: -20°C ~ 80°C
Termination Style: Solder Lug
Illumination: Non-Illuminated
Bushing Thread: 1/4-40
Actuator Length: 17.00mm
Actuator Type: Locking Lever
Panel Cutout Dimensions: Circular - 6.40mm Dia
Voltage Rating - AC: 125 V
Voltage Rating - DC: 28 V
Description: SWITCH TOGGLE DPDT 6A 125V
Features: Epoxy Sealed Terminals
Packaging: Bulk
Current Rating (Amps): 6A (AC), 4A (DC)
Mounting Type: Panel Mount
Circuit: DPDT
Switch Function: On-Off-On
Operating Temperature: -20°C ~ 80°C
Termination Style: Solder Lug
Illumination: Non-Illuminated
Bushing Thread: 1/4-40
Actuator Length: 17.00mm
Actuator Type: Locking Lever
Panel Cutout Dimensions: Circular - 6.40mm Dia
Voltage Rating - AC: 125 V
Voltage Rating - DC: 28 V
на замовлення 133 шт:
термін постачання 21-31 дні (днів)| Кількість | Ціна |
|---|---|
| 1+ | 2510.36 грн |
| 10+ | 2085.59 грн |
| 25+ | 1966.18 грн |
| 50+ | 1764.51 грн |
| 100+ | 1687.21 грн |
| MTL-206P |
Виробник: TE CONNECTIVITY - ALCOSWITCH
Description: TE CONNECTIVITY - ALCOSWITCH - MTL-206P - SWITCH, TOGGLE, DPDT, 6A, 250V
tariffCode: 85365080
rohsCompliant: Y-EX
Schalteranschlüsse: Solder
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktstrom, max.: 6A
Schalterfunktion: On-Off-On
isCanonical: Y
usEccn: EAR99
AC-Kontaktspannung, nom.: 250V
euEccn: NLR
DC-Kontaktspannung, nom.: 28V
Beleuchtung: Non Illuminated
Schaltermontage: Panel Mount
Produktpalette: MT Green Series
productTraceability: Yes-Date/Lot Code
Kontaktkonfiguration: DPDT
directShipCharge: 25
SVHC: To Be Advised
Description: TE CONNECTIVITY - ALCOSWITCH - MTL-206P - SWITCH, TOGGLE, DPDT, 6A, 250V
tariffCode: 85365080
rohsCompliant: Y-EX
Schalteranschlüsse: Solder
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktstrom, max.: 6A
Schalterfunktion: On-Off-On
isCanonical: Y
usEccn: EAR99
AC-Kontaktspannung, nom.: 250V
euEccn: NLR
DC-Kontaktspannung, nom.: 28V
Beleuchtung: Non Illuminated
Schaltermontage: Panel Mount
Produktpalette: MT Green Series
productTraceability: Yes-Date/Lot Code
Kontaktkonfiguration: DPDT
directShipCharge: 25
SVHC: To Be Advised
на замовлення 44 шт:
термін постачання 21-31 дні (днів)| Кількість | Ціна |
|---|---|
| 1+ | 2705.07 грн |
| 5+ | 2638.62 грн |
| 10+ | 2569.70 грн |
| 25+ | 2286.34 грн |
