NY-12W-K FUJITSU
Виробник: FUJITSU
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; 5A; 5A/250VAC; PCB
Body dimensions: 20.1x5x17.5mm
Operating temperature: -40...90°C
Electrical life: 100000 cycles
Contact material: AgNi
Coil resistance: 1.2kΩ
Contacts configuration: SPST-NO
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Type of relay: electromagnetic
Relay variant: interface
Relay series: NY
Rated coil voltage: 12V DC
Coil power consumption: 120mW
Operate time: 10ms
Release time: 5ms
Switched voltage: max. 150V DC; max. 270V AC
Contact current max.: 5A
Contact resistance: 30mΩ
Mounting: PCB
Contact plating: gold-plated
Mechanical durability: 2000000 cycles
Terminal pitch: 7.62mm
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; 5A; 5A/250VAC; PCB
Body dimensions: 20.1x5x17.5mm
Operating temperature: -40...90°C
Electrical life: 100000 cycles
Contact material: AgNi
Coil resistance: 1.2kΩ
Contacts configuration: SPST-NO
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Type of relay: electromagnetic
Relay variant: interface
Relay series: NY
Rated coil voltage: 12V DC
Coil power consumption: 120mW
Operate time: 10ms
Release time: 5ms
Switched voltage: max. 150V DC; max. 270V AC
Contact current max.: 5A
Contact resistance: 30mΩ
Mounting: PCB
Contact plating: gold-plated
Mechanical durability: 2000000 cycles
Terminal pitch: 7.62mm
на замовлення 1472 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
3+ | 184.03 грн |
5+ | 155.1 грн |
8+ | 112.55 грн |
20+ | 106.38 грн |
500+ | 102.26 грн |
Відгуки про товар
Написати відгук
Технічний опис NY-12W-K FUJITSU
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; 5A; 5A/250VAC; PCB, Body dimensions: 20.1x5x17.5mm, Operating temperature: -40...90°C, Electrical life: 100000 cycles, Contact material: AgNi, Coil resistance: 1.2kΩ, Contacts configuration: SPST-NO, AC contacts rating @R: 5A / 250V AC, DC contacts rating @R: 5A / 30V DC, Type of relay: electromagnetic, Relay variant: interface, Relay series: NY, Rated coil voltage: 12V DC, Coil power consumption: 120mW, Operate time: 10ms, Release time: 5ms, Switched voltage: max. 150V DC; max. 270V AC, Contact current max.: 5A, Contact resistance: 30mΩ, Mounting: PCB, Contact plating: gold-plated, Mechanical durability: 2000000 cycles, Terminal pitch: 7.62mm, кількість в упаковці: 1 шт.
Інші пропозиції NY-12W-K за ціною від 122.71 грн до 481.95 грн
Фото | Назва | Виробник | Інформація |
Доступність |
Ціна без ПДВ | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
NY-12W-K | Виробник : FUJITSU |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; 5A; 5A/250VAC; PCB Body dimensions: 20.1x5x17.5mm Operating temperature: -40...90°C Electrical life: 100000 cycles Contact material: AgNi Coil resistance: 1.2kΩ Contacts configuration: SPST-NO AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Type of relay: electromagnetic Relay variant: interface Relay series: NY Rated coil voltage: 12V DC Coil power consumption: 120mW Operate time: 10ms Release time: 5ms Switched voltage: max. 150V DC; max. 270V AC Contact current max.: 5A Contact resistance: 30mΩ Mounting: PCB Contact plating: gold-plated Mechanical durability: 2000000 cycles Terminal pitch: 7.62mm кількість в упаковці: 1 шт |
на замовлення 1472 шт: термін постачання 7-14 дні (днів) |
|
|||||||||||||||||
NY-12W-K | Виробник : Fujitsu | Power Relay 12VDC 5A SPST-NO(20.1x5x17.5)mm THT |
на замовлення 1681 шт: термін постачання 21-31 дні (днів) |
|
|||||||||||||||||
NY-12W-K | Виробник : FCL Components | General Purpose Relays Power 5A 12VDC |
на замовлення 498 шт: термін постачання 154-163 дні (днів) |
|
|||||||||||||||||
NY12W-K | Виробник : NAIS | 07+ |
на замовлення 20000 шт: термін постачання 14-28 дні (днів) |
||||||||||||||||||
NY-12W-K Код товару: 44951 |
Реле Тип реле: Реле середньої потужності (5-20А) Струм макс.: 5 A |
товар відсутній
|
