PMD2407PTB1-A.(2).F.GN SUNON
Виробник: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 70x70x25mm; 83.25m3/h; 45dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V
Fan dimensions: 70x70x25mm
Power consumption: 4.8W
Current rating: 0.19A
Fan efficiency: 83.25m3/h
Noise level: 45dBA
Kind of Bearing: ball bearing
Signal output: F type
Rotational rate/speed: 5100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x3
Operating temperature: -10...70°C
Cable length: 0.3m
Flammability rating: UL94V-0
Additional functions: Autorestart
Fan motor: brushless DC
Static pressure: 9.14mm H2O
Wire size: 24AWG
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 70x70x25mm; 83.25m3/h; 45dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V
Fan dimensions: 70x70x25mm
Power consumption: 4.8W
Current rating: 0.19A
Fan efficiency: 83.25m3/h
Noise level: 45dBA
Kind of Bearing: ball bearing
Signal output: F type
Rotational rate/speed: 5100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x3
Operating temperature: -10...70°C
Cable length: 0.3m
Flammability rating: UL94V-0
Additional functions: Autorestart
Fan motor: brushless DC
Static pressure: 9.14mm H2O
Wire size: 24AWG
на замовлення 194 шт:
термін постачання 21-30 дні (днів)
Кількість | Ціна без ПДВ |
---|---|
1+ | 887.93 грн |
10+ | 687.09 грн |
50+ | 645.87 грн |
Відгуки про товар
Написати відгук
Технічний опис PMD2407PTB1-A.(2).F.GN SUNON
Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 70x70x25mm; 83.25m3/h; 45dBA; ball bearing, Type of fan: DC, Kind of fan: axial, Supply voltage: 24V DC, Operating voltage: 10...27.6V, Fan dimensions: 70x70x25mm, Power consumption: 4.8W, Current rating: 0.19A, Fan efficiency: 83.25m3/h, Noise level: 45dBA, Kind of Bearing: ball bearing, Signal output: F type, Rotational rate/speed: 5100 (±10%)rpm, Current and power consumption tolerance: ±15%, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: lead x3, Operating temperature: -10...70°C, Cable length: 0.3m, Flammability rating: UL94V-0, Additional functions: Autorestart, Fan motor: brushless DC, Static pressure: 9.14mm H2O, Wire size: 24AWG, кількість в упаковці: 1 шт.
Інші пропозиції PMD2407PTB1-A.(2).F.GN за ціною від 775.04 грн до 1065.52 грн
