SBS 1007 KNITTER-SWITCH
Виробник: KNITTER-SWITCH
Category: Dip-Switches
Description: Switch: DIP-SWITCH; OFF-ON; 0.025A/24VDC; Pos: 2; SMD; -40÷85°C
Manufacturer series: SBS
Mounting: SMD
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Mounting hole diameter: 18.72x6.2mm
Body dimensions: 18.72x6.2x3mm
DC contacts rating @R: 25mA / 24V DC
Max. contact resistance:: 50mΩ
Number of positions: 2
Stable positions number: 2
Operating Force: 10N
Mechanical durability: 2000 cycles
Body colour: black
Type of switch: DIP-SWITCH
Leads: flat pin
Contact plating: gold-plated
Illumination: none
Switching method: OFF-ON
Body material: PPS
| Кількість | Ціна без ПДВ |
|---|---|
| 3+ | 151.79 грн |
| 5+ | 116.91 грн |
| 10+ | 92.03 грн |
Відгуки про товар
Написати відгук
Технічний опис SBS 1007 KNITTER-SWITCH
Category: Dip-Switches, Description: Switch: DIP-SWITCH; OFF-ON; 0.025A/24VDC; Pos: 2; SMD; -40÷85°C, Manufacturer series: SBS, Mounting: SMD, Operating temperature: -40...85°C, Terminal pitch: 2.54mm, Mounting hole diameter: 18.72x6.2mm, Body dimensions: 18.72x6.2x3mm, DC contacts rating @R: 25mA / 24V DC, Max. contact resistance:: 50mΩ, Number of positions: 2, Stable positions number: 2, Operating Force: 10N, Mechanical durability: 2000 cycles, Body colour: black, Type of switch: DIP-SWITCH, Leads: flat pin, Contact plating: gold-plated, Illumination: none, Switching method: OFF-ON, Body material: PPS.
Інші пропозиції SBS 1007 за ціною від 97.03 грн до 189.08 грн
| Фото | Назва | Виробник | Інформація | Доступність | Ціна без ПДВ | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
SBS 1007 | Knitter-Switch |
Description: DIP SWITCH 18.72 MM Packaging: Tube Contact Finish: Gold Voltage Rating: 24VDC Current Rating (Amps): 25mA Mounting Type: Surface Mount Pitch: 0.100" (2.54mm), Full Circuit: SPST Operating Temperature: -40°C ~ 85°C Termination Style: Gull Wing Actuator Type: Slide (Standard) Height Above Board: 0.149" (3.78mm) Actuator Level: Flush, Recessed Washable: Yes Contact Material: Nickel Number of Positions: 7 |
на замовлення 250 шт: термін постачання 21-31 дні (днів) |
|
| SBS 1007 |
|
Виробник: Knitter-Switch
Description: DIP SWITCH 18.72 MM
Packaging: Tube
Contact Finish: Gold
Voltage Rating: 24VDC
Current Rating (Amps): 25mA
Mounting Type: Surface Mount
Pitch: 0.100" (2.54mm), Full
Circuit: SPST
Operating Temperature: -40°C ~ 85°C
Termination Style: Gull Wing
Actuator Type: Slide (Standard)
Height Above Board: 0.149" (3.78mm)
Actuator Level: Flush, Recessed
Washable: Yes
Contact Material: Nickel
Number of Positions: 7
Description: DIP SWITCH 18.72 MM
Packaging: Tube
Contact Finish: Gold
Voltage Rating: 24VDC
Current Rating (Amps): 25mA
Mounting Type: Surface Mount
Pitch: 0.100" (2.54mm), Full
Circuit: SPST
Operating Temperature: -40°C ~ 85°C
Termination Style: Gull Wing
Actuator Type: Slide (Standard)
Height Above Board: 0.149" (3.78mm)
Actuator Level: Flush, Recessed
Washable: Yes
Contact Material: Nickel
Number of Positions: 7
на замовлення 250 шт:
термін постачання 21-31 дні (днів)
| Кількість | Ціна без ПДВ |
|---|---|
| 2+ | 189.08 грн |
| 10+ | 144.69 грн |
| 25+ | 131.81 грн |
| 50+ | 115.17 грн |
| 100+ | 107.08 грн |
| 250+ | 97.03 грн |
