Технічний опис SH1421-5241 Sanyo Denki
Description: STEP, F2, SQ.42, 0.9, , , BIPOLA, Packaging: Box, Voltage - Rated: 24VDC, Size / Dimension: Square - 1.654" x 1.654" (42.00mm x 42.00mm), Type: Hybrid, Operating Temperature: -10°C ~ 50°C, Termination Style: Wire Leads, Step Angle: 0.9°, Torque - Holding (oz-in / mNm): 32.57 / 230, Coil Type: Bipolar, Diameter - Shaft: 0.197" (5.00mm), Mounting Hole Spacing: 1.220" (31.00mm), Length - Shaft and Bearing: 0.945" (24.00mm), Part Status: Active, Current Rating (Amps): 2 A, Coil Resistance: 0.85 Ohms, Steps per Revolution: 400.0.
Інші пропозиції SH1421-5241
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна |
|---|---|---|---|---|---|
| SH1421-5241 | Виробник : SANYO DENKI |
 Category: Electric MotorsDescription: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 0,9°; 0.23Nm; 2A Type of motor: DC Kind of motor: 2-phase; bipolar; stepper Supply voltage: 24V DC Motors features: step 0,9° Nominal torque: 0.23Nm Current rating: 2A Body dimensions: 42x42x33mm Standard: NEMA 17 кількість в упаковці: 1 шт |
товару немає в наявності |
||
 |
SH1421-5241 | Виробник : Sanyo Denki SanMotion Products |
Description: STEP, F2, SQ.42, 0.9, , , BIPOLA Packaging: Box Voltage - Rated: 24VDC Size / Dimension: Square - 1.654" x 1.654" (42.00mm x 42.00mm) Type: Hybrid Operating Temperature: -10°C ~ 50°C Termination Style: Wire Leads Step Angle: 0.9° Torque - Holding (oz-in / mNm): 32.57 / 230 Coil Type: Bipolar Diameter - Shaft: 0.197" (5.00mm) Mounting Hole Spacing: 1.220" (31.00mm) Length - Shaft and Bearing: 0.945" (24.00mm) Part Status: Active Current Rating (Amps): 2 A Coil Resistance: 0.85 Ohms Steps per Revolution: 400.0 |
товару немає в наявності |
|
 |
SH1421-5241 | Виробник : SANMOTION |
Stepper Motors 2-Phase Step Motor, Single Shaft, 42mm, 0.9 Degree/Step, Bipolar, Leads, 0.23 Nm |
товару немає в наявності |
|
| SH1421-5241 | Виробник : SANYO DENKI |
Category: Electric Motors Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 0,9°; 0.23Nm; 2A Type of motor: DC Kind of motor: 2-phase; bipolar; stepper Supply voltage: 24V DC Motors features: step 0,9° Nominal torque: 0.23Nm Current rating: 2A Body dimensions: 42x42x33mm Standard: NEMA 17 |
товару немає в наявності |
