TAO3104 OWON
Виробник: OWONCategory: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; 8bit; LCD TFT 8"; Ch: 4; 1Gsps
Type of oscilloscope: handheld oscilloscope
Band: 100MHz
Vertical resolution: 8bit
Kind of display used: LCD TFT 8"
Number of channels: 4
Sampling: 1Gsps
Memory record length: 40Mpts
Time base: 2n...1ks/div
Display resolution: 800x600
Trigger: CAN; falling-edge; I2C; pattern width; pulse; rising-edge; RS232/UART; runt; serial protocol; slope; SPI; timeout; video signal; window
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Trigger source: CH1; CH2; CH3; CH4
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Interface: LAN; USB device; USB Host
Input impedance: 1MΩ/15pF
Power supply: rechargeable battery Li-Ion 7,4V 8000mAh x1
Dimensions: 270x191x48mm
Measuring instrument features: advenced trigger and bus decoding function; mathematical functions: addition, subtraction, division, multiplication and FFT
Standard equipment: adapter AC; BNC adapter; extension module; mains cable; mounting holder; oscilloscope probe x4; probe adjust; USB micro cable
Manufacturer series: TAO3000
Software: LabVIEW
Measurement memory: 100
Touchpad: yes
Connectors for the country: Europe
на замовлення 4 шт:
термін постачання 21-30 дні (днів)
| Кількість | Ціна |
|---|---|
| 1+ | 37962.33 грн |
| 4+ | 33613.71 грн |
Відгуки про товар
Написати відгук
Технічний опис TAO3104 OWON
Category: Portable Oscilloscopes, Scopemeters, Description: Handheld oscilloscope; 100MHz; 8bit; LCD TFT 8"; Ch: 4; 1Gsps, Type of oscilloscope: handheld oscilloscope, Band: 100MHz, Vertical resolution: 8bit, Kind of display used: LCD TFT 8", Number of channels: 4, Sampling: 1Gsps, Memory record length: 40Mpts, Time base: 2n...1ks/div, Display resolution: 800x600, Trigger: CAN; falling-edge; I2C; pattern width; pulse; rising-edge; RS232/UART; runt; serial protocol; slope; SPI; timeout; video signal; window, Input coupling: AC, DC, GND, Trigger modes: automatic; normal; single, Trigger source: CH1; CH2; CH3; CH4, Rise time: ≤3.5ns, Input sensitivity: 1mV/div...10V/div, Interface: LAN; USB device; USB Host, Input impedance: 1MΩ/15pF, Power supply: rechargeable battery Li-Ion 7,4V 8000mAh x1, Dimensions: 270x191x48mm, Measuring instrument features: advenced trigger and bus decoding function; mathematical functions: addition, subtraction, division, multiplication and FFT, Standard equipment: adapter AC; BNC adapter; extension module; mains cable; mounting holder; oscilloscope probe x4; probe adjust; USB micro cable, Manufacturer series: TAO3000, Software: LabVIEW, Measurement memory: 100, Touchpad: yes, Connectors for the country: Europe, кількість в упаковці: 1 шт.
Інші пропозиції TAO3104 за ціною від 41887.85 грн до 66161.38 грн
| Фото | Назва | Виробник | Інформація |
Доступність |
Ціна | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
+12 |
TAO3104 | Виробник : OWON |
Category: Portable Oscilloscopes, Scopemeters Description: Handheld oscilloscope; 100MHz; 8bit; LCD TFT 8"; Ch: 4; 1Gsps Type of oscilloscope: handheld oscilloscope Band: 100MHz Vertical resolution: 8bit Kind of display used: LCD TFT 8" Number of channels: 4 Sampling: 1Gsps Memory record length: 40Mpts Time base: 2n...1ks/div Display resolution: 800x600 Trigger: CAN; falling-edge; I2C; pattern width; pulse; rising-edge; RS232/UART; runt; serial protocol; slope; SPI; timeout; video signal; window Input coupling: AC, DC, GND Trigger modes: automatic; normal; single Trigger source: CH1; CH2; CH3; CH4 Rise time: ≤3.5ns Input sensitivity: 1mV/div...10V/div Interface: LAN; USB device; USB Host Input impedance: 1MΩ/15pF Power supply: rechargeable battery Li-Ion 7,4V 8000mAh x1 Dimensions: 270x191x48mm Measuring instrument features: advenced trigger and bus decoding function; mathematical functions: addition, subtraction, division, multiplication and FFT Standard equipment: adapter AC; BNC adapter; extension module; mains cable; mounting holder; oscilloscope probe x4; probe adjust; USB micro cable Manufacturer series: TAO3000 Software: LabVIEW Measurement memory: 100 Touchpad: yes Connectors for the country: Europe кількість в упаковці: 1 шт |
на замовлення 4 шт: термін постачання 14-21 дні (днів) |
|
||||||
 |
TAO3104 | Виробник : Owon Technology Lilliput Electronics (USA) Inc |
Description: TABLET O-SCOPE, 4CH/100MHZ/8-BIT Packaging: Box Display Type: LCD - Color (Touch) Function: Record, Save, Recall Interface: LAN, USB Type: Handheld Voltage - Supply: 100 ~ 240VAC Sampling Rate (Per Second): 1G Voltage - Input (Max): CAT II 400V Channels: 4 Input Impedance: 1M Probe Type: Passive 10:1 (2) Part Status: Active Bandwidth: 100 MHz Rise Time (Typ): 3.5 ns |
на замовлення 45 шт: термін постачання 21-31 дні (днів) |
|
